JL Audio 12TW3-D4 (Like New (Open Box))

400W RMS 12" TW3 Series Dual 4-ohm Shallow Subwoofer

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 3.5"
• Sensitivity: 84.11 dB

Learn more about the ls-12tw3d4-u9

We apologize

This item has been discontinued

Product Highlights


• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 3.5"
• Sensitivity: 84.11 dB

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


JL Audio 12TW3-D4

Building on the core technologies developed for the TW5 thin-line subwoofers, the TW3 series embodies a powerful combination of shallow mounting depth and long linear excursion capability. The result is a speaker that delivers big, impressive sub-bass performance in a compact form that works for those snug-fit installations. Thanks to the TW3 thin-line architecture, the deep, powerful and articulate JL Audio bass is now accessible in more applications than ever. The 10-inch subwoofers require only 3.25 inches of mounting depth, while the 12-inch models take just 3.50 inches.

An aluminum-alloy dust cap aids with heat dissipation, extending the speaker’s power handling range. A JL Audio logo adds a finishing accent to the dust cap’s rich satin black finish. Known for its durability, the TW3 series’ injection-molded, mica-filled polypropylene cone design offers impressive frequency response and deep, powerful bass reproduction with minimal distortion. Proprietary motor, suspension and cone modeling systems are used to achieve long, linear excursion capabilities with low distortion and powerful sound output. The result is tight, clean, articulate bass performance at all power levels.


Product Details:

  • 12" Dual 4 ohm TW3 Shallow Mount Series Subwoofer
  • Power Handling:
    • RMS: 400 watts
  • Mica Injected Polypropylene - MIPP Cone
  • Rubber Surround
  • Precision-built in USA
  • Very shallow mounting depth (3.25 / 3.50 Inches)
  • Aluminum-alloy dust cap and rear cap
  • Cast alloy frame
  • Patented “floating cone attach method” technology
  • “Concentric tube” architecture
  • Dynamic Motor Analysis system
  • Carefully engineered lead-wire design
  • 15.2 mm Xmax
  • Resonance Frequency (Fs): 26.46 Hz
  • Sensitivity: 84.11 dB
  • Recommended sealed box volume: 0.80 cubic feet
  • Recommended ported box volume: 0.95 cubic feet
  • Top-mount depth: 3.5"
  • Cutout diameter: 11.625"
  • Authorized Internet Dealer
  • Optional protective subwoofer grille (Sold Separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 12TW3-D4 (Like New (Open Box)) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 12TW3-D4 (Like New (Open Box)) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 12TW3-D4 (Like New (Open Box)) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 12TW3-D4 (Like New (Open Box)) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
TW3 Shallow Mount Series
Subwoofer Size
12"
RMS Power Handling
400 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Sensitivity
84.11 dB
Xmax (millimeters)
15.2 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mica Injected Polypropylene - MIPP
Woofer Surround
Rubber
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.80 cubic feet
Optimum Ported Box Volume
0.95 cubic feet
Top-Mount Depth (Mounting Depth)
3.5"
Cutout Diameter
11.625"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
26.46 Hz
Equivalent Compliance (Vas)
48.73 liters
Total Speaker Q Value (Qts)
0.531
Electrical Q Value (Qes)
0.558
Electrical Resistance of Voice Coil (Re)
9.280 ohm
Mechanical Q Value (Qms)
10.766
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

12TW3-D4-5

Weight:

16.90lbs

Internal SKU:

ls-12tw3d4-u9

Internal Product ID:

227541
