JL Audio 12W1v3-2 (Open Box, Like New)

300W RMS 12" W1v3 Series Single 2-ohm Car Subwoofer

JL Audio
Shop all JL Audio
highlight-star-icon


• RMS Power: 300 watts
• Impedance: Single 2 ohm
• Mica Injected Polypropylene - MIPP Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 5.41"
• Sensitivity: 85.9 dB

Learn more about the 12w1v32_obn

We apologize

This item has been discontinued

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)

JL Audio 12W1v3-2

300W RMS 12" W1v3 Series Single 2-ohm Car Subwoofer
Quantity: 1

Product Details:

  • 12" Single 2 ohm W1 v3 Series Subwoofer
  • Power Handling:
    • RMS: 300 watts
  • Mica Injected Polypropylene - MIPP Cone
  • Nitrile Butadiene Rubber NBR Surround
  • DMA Optimized Motor
  • Elevated Frame Cooling design
  • Patented FCAM technology
  • Vented Reinforcement Collar (VRC) composite structure
  • 11 mm Xmax
  • Frequency Response: 22 - 200 Hz
  • Resonance Frequency (Fs): 26.55 Hz
  • Sensitivity: 85.9 dB
  • Recommended sealed box volume: 1.10 cubic feet
  • Recommended ported box volume: 1.60 cubic feet
  • Top-mount depth: 5.41"
  • Cutout diameter: 11.0625"
  • Authorized Internet Dealer
  • JL Audio SGRU-12 subwoofer grille optional (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 12W1v3-2 (Open Box, Like New) Subwoofer

Mono Amp

Wiring Guide to Wire 2 JL Audio 12W1v3-2 (Open Box, Like New) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 12W1v3-2 (Open Box, Like New) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 12W1v3-2 (Open Box, Like New) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W1 v3 Series
Subwoofer Size
12"
RMS Power Handling
300 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
2 ohm
Frequency Response
22 - 200 Hz
Sensitivity
85.9 dB
Xmax (millimeters)
11 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mica Injected Polypropylene - MIPP
Woofer Surround
Nitrile Butadiene Rubber NBR
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
1.10 cubic feet
Optimum Ported Box Volume
1.60 cubic feet
Top-Mount Depth (Mounting Depth)
5.41"
Cutout Diameter
11.0625"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
26.55 Hz
Equivalent Compliance (Vas)
2.544 liters
Total Speaker Q Value (Qts)
0.521
Electrical Q Value (Qes)
0.554
Electrical Resistance of Voice Coil (Re)
2.210 ohm
Mechanical Q Value (Qms)
8.731
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

12W1V32_OBN

Weight:

14.32lbs

Internal SKU:

12w1v32_obn

Internal Product ID:

224015
