Audiopipe APMB-6CF

200W 6" APMB Series Indoor/Outdoor Midrange Driver

Audiopipe
Shop all Audiopipe
Product videos
highlight-star-icon

• Peak Power: 200W • RMS Power: 100W
• Low Mid Frequency
• Mounting Depth: 2-9/10"
• 21 Oz. Magnet
• Carbon Fiber Cone
• Sensitivity: 89.6dB

Learn more about the apmb6cf

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28

Product Highlights


• Peak Power: 200W • RMS Power: 100W
• Low Mid Frequency
• Mounting Depth: 2-9/10"
• 21 Oz. Magnet
• Carbon Fiber Cone
• Sensitivity: 89.6dB

Description


Audiopipe brand icon

Authorized dealer

Pro Audio Quality in Your Car

The Audiopipe APMB series speakers were designed to produce pro audio quality sound in your car. These outstanding speakers thoughtfully engineered to handle significant amounts of amplified power, resulting in clean, crisp sound reproduction. Ideal for virtually any application, the APMB series is meant to let you take your music with you and show off your system in any kind of environment and each speaker in the series has it's own unique purpose. Hear more than just bass with the APMB series pro audio speakers!

Survive the Elements Durable Carbon Fiber Cone for Outdoor Use

Audiopipe want's you to be able to use your car's sound system in any kind of environment, and the 8CF Indoor/Outdoor speakers are perfect for showing your system off at the beach, park or any other outdoor setting. The lightweight, durable carbon fiber cone is designed for linear movement and to prevent cone fluctuation for the highest quality sound possible.

Classic Sound Dust Cap Sound Quality and Protection

Utilizing the classic dust cap design, the 8CF speaker retains the original shape and form of a loudspeaker while providing the overall most impressive and best sounding of all speaker types. The durable carbon fiber dust cap also keeps the internal components of your speaker free of dust and other sound diminishing particles, ensuring your sound will stay in peak form.


General Features:

  • 6" APMB Series Indoor/Outdoor Midrange Driver
  • Power Handling:
    • Peak: 200 watts
    • RMS: 100 watts
  • Low mid frequency loudspeaker
  • Loudspeaker design provides pro audio quality sound in your car
  • Carbon fiber cone allows you to open up your car and play music outdoors
    • Ideal for use at the beach, park or any other outdoor gathering
  • Corrugated surround
  • Classic dust cap design to protect the internal speaker components
  • Heavy duty 21 oz. magnet
  • Durable 1.3" KSV voice coil
  • 8 ohm impedance
  • Frequency Response: 46-18,000 Hz
  • Top-mount Depth: 2-9/10"
  • Mounting Diameter: 5-25/32"
  • Sensitivity: 89.6dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Specifications:

  • FS (Free Air Resonance): 85 Hz.
  • RE (DC Resistance): 6.0 ohm
  • Le (Voice Coil Inductance): 0.27 mH
  • QMS (Mechanical Q Value): 3.2
  • QES (Electrical Q Value): 0.76
  • QTS (Total Speaker Q Value): 0.52
  • VAS (Equivalent Compliance): 6.4 L (0.22 cu ft.)
  • Xmax (One-Way Linear Excursion): 2.5mm (0.1")
  • F3 (for Sealed Enclosure):
    • 0.5 cu ft.: 107 Hz
    • 0.8 cu ft.: 101 Hz
  • F3 (for Vented Enclosure):
    • 0.6 cu ft.: 80 Hz

Priced Per Speaker


Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

3
-19.05%

$339.99

List price $420.00

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Limited time!
DMX709S main

Kenwood eXcelon DMX709S

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

20
-33.50%

$399.00

List price $600.00

Limited time!
iLX-W670-M main

Alpine iLX-W670-M

6.75" Double DIN Touchscreen Digital Multimedia Receiver with iDataLink Maestro Support, Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

2
-30.01%

$349.95

List price $500.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00


Best selling similar products

PH654 small

Cerwin-Vega PH654

• 300 watts Peak Each, 150 watts RMS Each
• Polymide Horn Tweeters
• Treated Paper cone material
• Impedance: 4 ohm
• Sensitivity: 101 dB

(2)

$189.99

List price $227.99

CVP8 small

Cerwin-Vega CVP8 (Sold Individually)

• 350 watts Peak, 170 watts RMS
• Treated Paper cone material
• Impedance: 4 ohm
• Sensitivity: 95 dB

$49.99

List price $59.99

AP-M61SE Pro small

Deaf Bonce Apocalypse AP-M61SE Pro

• 300 watts Peak Each, 150 watts RMS Each
• Pressed Paper cone material
• Impedance: 4 ohm
• Sensitivity: 102.80 dB

$119.90

List price $143.99

PRO-X12MBASS small

DS18 PRO-X12MBASS (Sold individually)

• 1000 watts Peak Each, 500 watts RMS Each
• Paper cone material
• Impedance: 8 ohm
• Sensitivity: 96 dB

$131.95

List price $131.95

10MB800FT small

PRV Audio 10MB800FT

• 1600 watts Peak Each, 800 watts RMS Each
• Non-Pressed Paper cone material
• Impedance: 8 ohm
• Sensitivity: 99 dB

$129.91

List price $162.39

EPICPRO8X small

AudioControl EPICPRO8X

• 350 watts Peak Each, 250 watts RMS Each
• Paper cone material
• Impedance: 4 ohm
• Sensitivity: 99.2 dB

$129.00

List price $129.00

PRO-X6.4BMPK small

DS18 PRO-X6.4BMPK

• 500 watts Peak Each, 250 watts RMS Each
• 1" Aluminum Bullet super tweeters with ferrite magnets
• Non-Pressed Paper cone material
• Impedance: 4 ohm
• Sensitivity: 94 dB

(4)

$139.95

List price $139.95

HCCA64N small

Orion HCCA64N

• 1400 watts Peak Each, 350 watts RMS Each
• Non-Pressed Paper cone material
• Impedance: 4 ohm
• Sensitivity: 99 dB

$219.95

List price $263.99

VPRO65 small

NVX VPRO65 (Sold Individually)

• 450 watts Peak Each, 225 watts RMS Each
• 1" Aluminum Bullet tweeter
• Competition Grade Paper cone material
• Impedance: 4 ohm
• Sensitivity: 97 dB

(4)

$74.99

List price $82.99

CVMPCL8.0 small

Cerwin Vega CVMPCL8.0 (Sold Individually)

• 400 watts Peak Each, 200 watts RMS Each
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 95 dB

$139.99

List price $167.99

Specifications & Details


Speaker Specifications
Series
APMB Series
Priced Per
Each Speaker
Speaker Size
6"
Design
Mid-range
Woofer Composition
Carbon Fiber
Woofer Surround
Corrugated
Peak Power Handling
200 watts
RMS Power Handling
100 watts
Sensitivity
89.6 dB
Frequency Response
46 - 18000 Hz
Impedance (Per Voice Coil)
8 ohm
Top-Mount Depth (Mounting Depth)
2-9/10"
Cutout Dimensions
5-25/32"
General specifications
Speaker Grilles
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

APMB-6CF

Weight:

4.00lbs

Internal SKU:

apmb6cf

Internal Product ID:

81704
