MB Quart DS1-204

400W 8" Discus Series Dual 4-ohm Shallow Mount Car Subwoofer

MB Quart
Shop all MB Quart
Product videos
highlight-star-icon

• 200W RMS
• Top-mount depth: 2.80"
• Polypropylene cone and dust cap
• UV Rubber surround
• 2" Dual Voice Coil
• Stamp-cast deep drawn steel basket
• Durable heavy textured powder coat

Learn more about the ds1204

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
R14X2 main

Rockford Fosgate Prime R14X2

120W Peak (60W RMS) 4” Prime Series 2 Way Coaxial 4-ohm Speakers

14
C1-100ct main

JL Audio C1-100ct

120W RMS 1" C1 Series 8-ohm Component Dome Tweeters

9

Product Highlights


• 200W RMS
• Top-mount depth: 2.80"
• Polypropylene cone and dust cap
• UV Rubber surround
• 2" Dual Voice Coil
• Stamp-cast deep drawn steel basket
• Durable heavy textured powder coat

Description


MB Quart brand icon

Authorized dealer

General Features:

  • 8" Discus Series Dual 4-ohm Shallow Mount Car Subwoofer
  • Power Handling:
    • Peak: 400 watts
    • RMS: 200 watts
  • Polypropylene cone and dust cap
  • UV Rubber surround
  • 2" Dual Voice Coil
  • All new design based on popular RLP shallow subs
  • Stamp-cast deep drawn steel basket
  • Durable heavy textured powder coat
  • Vented aluminum voice coil former
  • Optimized for sealed enclosures
  • Nickel plated spring terminals
  • Hardware concealing rubber gasket trim
  • Top-mount depth: 2.80"
  • Cutout diameter: 7.24"
  • Sensitivity: 81 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • Priced Individually

Check out the MB Quart DS1-204 Quick Start Guide

Subwoofer Wiring Guide


Wiring Guide to Wire 1 MB Quart DS1-204 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 MB Quart DS1-204 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 MB Quart DS1-204 Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 MB Quart DS1-204 Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Loading...
CVP8 main

Cerwin-Vega CVP8 (Sold Individually)

350W Peak (170W RMS) 8" CVPRO Series Pro Full Range 4-ohm Speaker

-16.67%

$49.99

List price $59.99

TS-A1081F main

Pioneer TS-A1081F

460W Peak (100W RMS) 4” A Series 2-way 4-ohm Coaxial Car Speakers

3
-18.18%

$90.00

List price $110.00

DB402 main

Polk Audio DB402 (DB 402)

270W Peak (90W RMS) 4" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

4
-9.99%

$90.00

List price $99.99

DMDX8 main

Diamond Audio DMDX8

390W Peak (130W RMS) 8" DMDX Series 2-Way Cocentric Coaxial Car Speakers

AP-W81AC main

Deaf Bonce Apocalypse AP-W81AC

1200W Peak (600W RMS) 8" Apocalypse Series 4-ohm Midbass Car Speakers

EPICPRO8X main

AudioControl EPICPRO8X

700W Peak (500W RMS) 8" Epic Pro Series Pro Audio Midrange 4-ohm Speakers

H80C main

Cerwin-Vega H80C

900W Peak (300W RMS) 8" HED Series 2 Way Component 4-ohm Speaker System

-16.67%

$219.99

List price $263.99

CVMPCL8.0 main

Cerwin Vega CVMPCL8.0 (Sold Individually)

400W Peak (200W RMS) 8" Stroker Pro Series Full Range 4-ohm Speakers

-16.67%

$139.99

List price $167.99

C1-400x main

JL Audio C1-400x

70W RMS 4" C1 Series 2 Way Coaxial 4-ohm Car Speakers

8
S2-S80C main

Alpine S2-S80C

520W Peak (170W RMS) 8" S-Series Hi-Res 2-Way Component Car Speakers

1
-17.26%

$239.95

List price $290.00


Best selling similar products

47KBRW8 small

Kicker 47KBRW8 ReFLEX™

• 8" ReFLEX™ Passive Radiator
• Rubber covered plastic Cone
• Rubber Surround

(1)

$49.99

List price $59.99

VCW82v3 small

NVX VCW82 Version 3 (VCW82v3)

• Peak Power: 1300 watts
• RMS Power: 650 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• High Roll Foam Surround with black nylon stitching
• Mount depth: 5.31"
• Sensitivity: 83 dB (1W/1m)

(12)

$169.99

List price $203.99

R2-W8D2 small

Alpine R2-W8D2

• Peak Power: 1000 watts
• RMS Power: 350 watts
• Impedance: Dual 2 ohm
• Kevlar Reinforced Pulp Paper Cone
• High-Amplitude Multi-Roll (HAMR) Surround
• Mount depth: 4.56"
• Sensitivity: 83.6 dB

$239.95

List price $360.00

Specifications & Details


Subwoofer Specifications
Series
Discus Series
Subwoofer Size
8"
Peak Power Handling
400 watts
RMS Power Handling
200 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2"
Frequency Response
not specified by manufacture
Sensitivity
81 dB
Xmax (millimeters)
8.20 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Optimum Sealed Box Volume
0.50 cubic feet
Top-Mount Depth (Mounting Depth)
2.80"
Cutout Diameter
7.24"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
44.65 Hz
Equivalent Compliance (Vas)
10.71 liters
Total Speaker Q Value (Qts)
0.940
Electrical Q Value (Qes)
1.113
Electrical Resistance of Voice Coil (Re)
7.13 ohm
Mechanical Q Value (Qms)
6.011
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

DS1-204

Weight:

5.00lbs

Internal SKU:

ds1204

Internal Product ID:

94844

Product and How-to Videos


Customer Ratings & Reviews


MB Quart DS1-204 thumbnail image

5 star
83%
4 star
8%
3 star
8%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

great prices

Recommend!
Shallow mounting & 200 watts RMS which perfectly matches my front stage amp output. Using it as midbass (@2ohms) on custom front door pods that also has 2 Z-line 6 1/2 components running actively & they bump. Currently running from 50hz-180hz.

By Chad on June 14, 2020 Checkmark Icon Verified purchase

6 found this helpful


Nice sub

This little beast will fill a big truck with bass its not hard-core punchy bass, more a perfect balance bass. It hits hard but its pleasant and doesn't need much space.

By Freeman on October 14, 2020

3 found this helpful


Perfect fit for a 2002 Suburban replacment sub

The 14 year old factory sub (non-Bose) was thoroughly rotted out and effectively just making noise. After looking around for a shallow mount DVC 8" sub I selected the MBQuart based on price, design, and construction. Many online sources for how to get the sub out so I won't elaborate on that. I found how to wire the MBQuart to be 2ohm impedance, removed the old sub, and the MBQuart fit the stock sub box perfectly. The sound is much improved, especially coupled with a new HU and front speakers. Also, don't forget to implement the "amplifier" bypass when upgrading the front speakers to get full range from the new fronts.

By mikehd on February 8, 2016 Checkmark Icon Verified purchase

2 found this helpful


Great Speaker for the Price

I have been very happy with the quality of this speaker. I run a small box in the back of my Jeep wrangler and this has great sound. Just enough bass paired with a 300 watt amp. I had the set up for about 2 month now and runs very well. I drive about hour and half combined to and from work . Pandora rocking both ways and the top down. No problems even with the 90 degree heat so far.

By TJ on June 27, 2016

1 found this helpful


By Brian on May 18, 2024 Checkmark Icon Verified purchase


Nice shallow mount subwoofer

Installed this subwoofer in a 2018 Colorado. With very limited space. Subwoofer performance is great for an 8” sub.

By Anonymous on August 16, 2018


Great sound quality!

The subwoofer fit my 2000 Chevy Suburban with no modifications other than drilling holes for screws and puts out a lot of bass. Very pleased!!!

By Anonymous on August 14, 2018


MB Quart DS1-204

Installed 2 of these under the rear seat of my 2004 Tundra in a sealed box and the hit really good, there perfect for tight places and when there paired together you can get good bass tones, I had 2 pioneer shallow 8" woofers in my old truck and these sound just as good and are a way better price.

By Anonymous on June 20, 2018


MB Quart DS1-204

Perfect fit replaced oem powerfull strong bass for size slimness

By Anonymous on May 16, 2018


Great Value

Very nice 8” sub for the price and RMS - Good Quality

By Kyle on March 10, 2018
