JBL GX502 - Open Box, Good Condition (Used)

270W Peak (90W RMS) 5.25" 2-Way GX Series Coaxial Car Speakers - Pair Open Box Complete (Good, Used)

JBL
Shop all JBL
highlight-star-icon

• Peak Power: 270W
• RMS Power: 90W
• Plus One polypropylene cone
• Mounting Depth: 2.25"
• Rubber speaker surround & Balanced dome tweeter

Learn more about the LS-gx502-obc5

We apologize

This item has been discontinued

Description


JBL brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Looks divine. Sounds delicious.

Head's are going to turn when they hear the sound that pumps through the JBL GX Series speakers. But get in and "whoa!" they look incredible. Designed to fit most factory specs, the GX series flaunt a new HARMAN-proprietary tweeter deflector, they're individually voiced, and have three-ohm voice coils for optimal power distribution. Add Plus One woofer cones, edge-driven soft dome tweeters and an ogle-worthy design, and you've got a speaker that does much more than deliver killer sound.

Plus One Woofer Cones

Harman's patented (US patent #7,548,631) Plus One polypropylene cones provide more overall speaker-cone area than other cones in its class — the result is higher sensitivity, increased low frequency output and greater musical character.

Edge-Driven Soft Dome Tweeter

Soft dome tweeters deliver a smooth high-frequency response and an increased power handling for highs and mids, which equates to more lifelike sound from vocals, cymbals, brass instruments and pianos.

Frequency Response Up to 21kHz

Hear what you've been missing — the JBL GX Series offers a frequency response that delivers the full-range response associated with exceptional sound.

Affordable Pricing

The JBL GX Series are all designed to give audio enthusiasts more boom for the buck — while they maintain a conservative price point, there is never a compromise in sound.

Three-ohm DCR Voice Coils

The majority of factory-speaker wiring is so thin that it can't draw the necessary power for great sound. With low-impedance, three-ohm voice coils, the GX Series speakers can pull more power from the amplifier, which means a clearer, richer sound for the listener.

HARMAN-Proprietary Tweeter Deflector

Acting as a waveguide, the tweeter deflector allows for an angled, rotating speaker, which optimizes the off-axis sound performance. Because all cars are designed differently, this allows impeccable sound to travel throughout all locations in the cabin.

OEM-Level Reliability Testing

JBL tests every speaker design to the same rigid specifications as the automakers, subjecting them to extreme conditions that would break lesser speakers. We freeze them, bake them, shake them, blast them with ultraviolet light and drive them at full power for days to make sure your audio investment lasts for years.

Individually Voiced

For most brands, off-the-shelf speakers and a cursory approval of frequency response curves are good enough. That's not the case with JBL. We don't only listen to our speakers against the competition — we voice them against each other to ensure each line has the consistent JBL sound signature that's known and sought out by those who care about their audio. This is just part of an extensive development process undertaken by some of the best transducer engineers in the world to provide the finest listening experience at any price point.



Item Condition - Open Box, Good Condition:
A Good Open Box used product shows wear from consistent use, but it remains in good condition and works perfectly. It may be marked, have identifying markings on it, or show other signs of previous use or installation. Original packaging, paperwork or protective wrapping may be missing or not included in its entirety. Warranty details are included in the item description or comments.

General Features:

  • 5.25" 2-Way GX Series Coaxial Car Loudspeakers
  • Power Handling:
    • Peak: 270 watts per pair / 135 watts each
    • RMS: 90 watts per pair / 45 watts each
  • Recommended power range: 5 - 45 watts RMS per channel
  • Plus One polypropylene cone
  • Rubber speaker surround
  • Balanced dome tweeter
  • 2.3 ohm Nominal impedance
  • Frequency Response: 65 - 21,000 Hz
  • Top-mount Depth: 2.25"
  • External Diameter: 5.125"
  • Cutout Diameter: 4.75"
  • Total Depth: 2.88" (top of tweeter)
  • Sensitivity (2.8V/m) : 91 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Priced Per Pair



PROP 65 WARNING: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer or birth defects or other reproductive harm. Wash hands after handling. For more information, visit www.P65Warnings.ca.gov

Specifications & Details


Speaker Specifications
Series
GX Series
Priced Per
Pair
Speaker Size
5-1/4"
Design
2-way Coaxial
Tweeter Design
Soft Dome
Tweeter Size
1"
Tweeter Composition
Mylar
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Peak Power Handling
135 watts
RMS Power Handling
45 watts
Sensitivity
91 dB
Frequency Response
65 - 21,000 Hz
Impedance (Per Voice Coil)
2.3 ohm
Shallow Mount Installation
No
Top-Mount Depth (Mounting Depth)
2.25"
Cutout Dimensions
4.75"
General specifications
Speaker Grilles
Yes
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

JBL

Model Number:

GX502-2

Weight:

3.79lbs

Internal SKU:

LS-gx502-obc5

Internal Product ID:

136901
