Rockford Fosgate R2SD4-12
250W 12" Prime Stage 2 Shallow Mount Dual 4 ohm Subwoofer
Quantity: 2
Key Benefits
- 12" Dual 4 ohm Shallow Mount Prime Stage 2 Series Subwoofer
- Power Handling:
- Peak: 1000 watts per pair / 500 watts
- RMS: 500 watts per pair / 250 watts each
- CEA-2031 Compliant
- Klippel Verified
- Shallow Motor Assembly
- 12 AWG compression terminals
- Optimized for sealed enclosures
- Mica injected polypropylene cone
- StampCast basket with integrated spider venting
- Linear spider with embedded 16 AWG tinsel leads
- Unique low profile "inset" design, high excursion woofer
- High density compressed half-roll sealed poly-foam surround
- Proprietary attached tear & fatigue resistant poly-cotton spider
- Suited for sealed enclosure applications, capable for use in vented boxes as well
- Optimized motor magnetics with extended pole and bumped vented backplate
- Fatigue resistant and reduced strain "stitched on" flexible lead wire design
- Multi-point high-temp/high-strength neck joint bonding technique
- High temp copper voice coil with aluminum former
- All metal compression input terminal assembly
- Semi-flexible PVC integrated trim ring
- Heavy guage stamped steel frame
- Mounting Depth: 3.602"
- Cutout Diameter: 11.25"
- Magnet Weight: 51.0 oz
- Frequency Response: 43 - 250 Hz
- Xmax: 10 mm
- Sensitivity: 85 dB @ 1 watt / 1 meter
- Recommended Ported Enclosure: 1.79ft³ @40.0Hz
- Recommended Sealed Enclosure: 0.90ft³ @44.1Hz
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
 |
 |
Priced Individually
Check out the Rockford Fosgate R2SD4-12 Owner's Manual
Check out the Rockford Fosgate R2SD4-12 Data Sheet
Image Dynamics Q600.1
Tested at 622W RMS on our Amp Dyno! (Rated 600W by Image Dynamics) High Fidelity Q Series Monoblock Car Amplifier
Quantity: 1
- Q Series Monoblock Car Amplifier
- RMS Power Rating (14.4V):
- 4 ohm: 250 watts x 1 chan.
- 2 ohm: 400 watts x 1 chan.
- 1 ohm: 600 watts x 1 chan.
- Sonic Electronix Certified Power Rating*:
- 4 ohm: 258 watts x 1 chan.
- 2 ohm: 415 watts x 1 chan.
- 1 ohm: 622 watts x 1 chan.
- Optically isolated MOSFET power supply
- LED power indicator
- Variable bass boost (0 to +12 dB bass boost at 45 Hz)
- Soft Start Turn-on
- Mono channel operation
- Remote bass level included
- Bridgeable Capability
- Bi-Polar High-current output devices
- Auxiliary full range output
- Two-layer PC Board with heavy 2 oz copper
- Massive ground planes and precision caps
- 5-Way System Protection circuitry
- Heavy duty aluminum alloy heatsink for extreme heat dissipation
- Nickel-plated RCA level inputs
- Nickel-plated screw terminals
- Input sensitivity: 200mV - 6V
- Variable low-pass filter (50-250 Hz, 12 dB/octave)
- Variable subsonic filter (15-45 Hz, 12 dB/octave)
- Frequency response: 10-20,000 Hz
- Signal-to-Noise ratio: 98dB
- Dimensions: 17-3/4"L x 8-1/2"W x 2-1/4"H
- 4-gauge power and ground wiring is recommended for installation.
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
*The Sonic Electronix Certified Power Ratings listed are based on a test of a specific sample amplifier. Actual power ratings may slightly vary between amps.
NVX XKIT42
100% Copper, 2-Chan. True Spec 4 Gauge Amp Installation Kit w/RCA Interconnect & 40 ft Speaker Cable
Quantity: 1
General Features:
- 4 Gauge 2-Channel X-Series Complete Amplifier Installation Kit
- Designed specifically for car audio systems up to 1000 watts RMS
- Premium power and ground wire provides optimal power transfer
- Made from silver-tinned 100% virgin copper for a pure uninterrupted transfer of power and signal
- Audio Interconnect RCA cables are made with twisted-pair technology for noise reduction
- Solid Brass and satin-chromed ANL/Mini-ANL Fuse holder offers ideal protection for high powered systems
- True-to-Gauge cables/wires meet or exceed the industry standard of copper required for the gauge size
- Strand Count: 1862
- BC-5W2 Compliant
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
Kit includes:
- 20 ft. (6.1 meters) Frosted Blue 4 gauge power wire with seamless crimp ring terminal
- 3 ft. (.91 meters) Frosted Black 4 gauge ground wire with seamless crimp ring terminal
- 20 ft. (6.1 meters) Clear 18 gauge remote lead wire
- 40 ft. (12.2 meters) Frosted Black/Blue 16 gauge speaker wire
- One 16 ft. (5 meters) 2-channel twisted construction RCA interconnect Cable (NVX XIV25)
- One NVX XMANL04 ANL/Mini-ANL Fuse Holder with 100 amp Mini-ANL fuse
- One Black rubber firewall grommet
- Two 4 Gauge Nickel Plated spade terminals
- Four 18 Gauge Spade terminal
- Two 18 Gauge Red butt connectors
- Four 16 Gauge quick disconnect
- Five 16 Gauge Nickel Plated spade terminals
- Ten 6" Black zip ties
