Pioneer Premier AVIC-F90BT

Double DIN In-dash 5.8" TFT-LCD Touchscreen Monitor with Built-in GPS Navigation, Built-in Bluetooth, DVD, DivX, USB to iPod A/V Cable, SD Card and 3.5mm Aux Inputs

Shop all Pioneer
Product videos

In-dash DVD, DivX, CD, MP3 Receiver with Built-in GPS Navigation, iPod Direct Connection, and Bluetooth • 5.8" LCD Touchscreen display • 50W x 4 chan. Max • 20W x 4 chan. RMS • Intelligent and conversational voice command • 3 Sets of 4V preamp outputs • Sirius,XM,HD Radio Ready

Learn more about the avicf90bt

We apologize

This item has been discontinued

Product Highlights

In-dash DVD, DivX, CD, MP3 Receiver with Built-in GPS Navigation, iPod Direct Connection, and Bluetooth • 5.8" LCD Touchscreen display • 50W x 4 chan. Max • 20W x 4 chan. RMS • Intelligent and conversational voice command • 3 Sets of 4V preamp outputs • Sirius,XM,HD Radio Ready


Pioneer brand icon

Authorized dealer

We all know that the Pioneer AVIC-D3 was a great product. What could ever replace Pioneer's AVIC-D3? The feature-packed AVIC-F series in-dash navigation will certainly be this outstanding replacement and much, much more for many years to come!

Integration is a crucial element to the AVIC-F Series design, just like the old AVIC-D3. The front-panel is an entirely new look with a much more minimalistic and upgraded look. Users are given the choice of 32,768 customizable illumination colors, allowing this double DIN receiver to integrate into any dash seamlessly.

HDD Navigation
Where the AVIC-D3 failed, the AVIC-F units will triumph. The AVIC-D3's obsolete DVD-based GPS navigation system has been replaced by an all new hard drive based GPS software that holds over 12 million points of interest. No more shuffling navigation discs, no more stopping or pausing your music! Users will also experience a much smoother and faster response system while navigating since everything has already been preloaded onto the hard drive. In addition, the built-in navigation is at an "always-on" power state that is always ready to go when you are.

Bluetooth, iPod, USB, and... what more can you ask for? Oh yeah, Satellite and HD Radio!
The AVIC-F90BT, AVIC-F900BT, and the AVIC-F700BT all have built-in Bluetooth technology that allow users to make hands-free phone calls with caller ID and call status displayed on the screen. You won't have to buy any additional accessories or add-ons. It is also capable of controlling any iPod audio or video sources through its USB port that supports other media devices that contains AAC, MP3, and WMA files.

The AVIC-F units all feature an SD Card Reader, USB port and RCA audio/video auxiliary inputs. In addition, all AVIC-F series will be able to receive Sirius or XM Satellite Radio and HD Radio with additional accessories.

Conversational Voice Command
Last but not least is the unique voice control technology built-in each of the AVIC-F units. You can now control what music you want to play without even the push of a button. You could simply say "Play artist Chris Brown" and it will play all songs with that artist. In addition, you could likewise do the same for hands-free dialing. What's unique about the voice command feature is its ability to decipher pausing words or fill-in words such as "ummm, uhhh... the uhhhh..." It will still recognize names even if you say "Call uhhh Alison" If phonebook entry Alison has more than one number, the AVIC-F unit will ask "Found three numbers for Alison, which would you like to dial?" It's almost like a SCIFI movie or something from iRobot. This breakthrough feature will definitely impress you and everyone else riding in your car!

Special for the AVIC-F90BT and AVIC-F900BT
The AVIC-F90BT features the innovative built-in MSN Direct receiver which could display traffic information, movie times, weather, and much more! It is capable of receiving data for most major US cities and will display corresponding information on the screen. You'll never be late to a movie again, you'll always be able to avoid traffic jams, and you'll always know what to expect from the weather on your next road trip!

General Features:

  • In-dash DVD, DivX, CD, MP3 Receiver with Built-in GPS Navigation
  • iPod interface cable included for iPod controls, charging and playback
  • Built-in Bluetooth technology supports hands-free calling with a compatible Bluetooth phone
  • 5.8" LCD Touchscreen display
  • 32,768 Customizable illumination colors
  • CEA-2006 compliant amplifier
  • Power Output:
    • Peak: 50 watts x 4 channels
    • RMS: 22 watts x 4 channels
  • CD Text Display
  • MP3 ID3 Tag Display (Title/Artist/Album)
  • 1-year warranty

Playback and Audio Features:

  • Playback of DVD, DVD+R/RW, DVD-R/RW, DivX, CD, CD-R, CD-RW, AAC, MP3, and WMA
  • SuperTuner IIID with 18FM/6AM presets
  • DTS and Dolby Digital encoding capable
  • EEQ (3-band parametric equalizer with 5 curves)
  • Intelligent and conversational voice command capable media browsing and playback controls

Expandability Options:

  • 3 Sets of 4V preamp outputs (front, rear and subwoofer)
  • SIRIUS or XM Satellite Radio Ready: A subscription is required for service as well as purchase of either the Pioneer SIRIUS Satellite Radio Package or Pioneer XM Radio Package
    • Note: New Pioneer models such as the AVIC-F Series are not compatible with older TERK XM Satellite Radio components
  • HD Radio Ready: Pioneer GEX-P10HD HD Radio tuner required and sold separately
  • Bluetooth Ready: Built-in Bluetooth technology with integrated microphone and voice command controls and dialing
  • iPod interface cable included for iPod controls, charging and playback
  • iPod direct connection through USB with included Pioneer CD-IU230V iPod adapter
    • Compatible iPods using Direct Connection:
      • iPod Video: 5th Generation
      • iPod Classic
      • iPod Touch
      • iPod Nano: All models
  • Information Connectivity: Built-in MSN Direct Tuner for traffic updates, movie times, weather, and more!
  • Steering Wheel Control Ready: PAC SWI-PSv1 required and sold separately
  • Front-panel auxiliary input: SD Card and 3.5mm (headphone jack) allows connection to portable media storage and devices such as MP3 players, etc.
  • Rear auxiliary input: USB and RCA Audio/Video Input
  • Backup Camera Ready: Pioneer ND-BC2 standard backup camera or Pioneer ND-BC20PA backup camera with Parking Assistant are required and sold separately
  • CD Changer controls

Navigation Features:

  • 12 Million points of interest
  • Built-in TeleAtlas map database, covering all US states, Canada, Alaska, and Hawaii
  • Text-to-speech technology
  • 3D Landmark icon displays
  • Receives traffic information, weather forecasts, gas prices, and even movie times while navigating through MSN Direct technology
  • POI creator interface (allow users to set their own POI location)
  • "Always-on" Navigation with no need for navigation discs
For more info check out the Pioneer AVIC-F90BT blog post.

Product history:

Pioneer AVIC-F90BT thumbnail
(newest, current model)
Pioneer AVIC-D3 thumbnail
(previous model, replaced by Pioneer Premier AVIC-F90BT)

This item is currently not eligible for our low price guarantee. This may be due to supply constraints, manufacturer restrictions, or another reason. We're always here to help you get the best price possible so give us a call or email today. Our experts will do their best to build the system that works for you within the rules.

Specifications & Details

In-Dash Receiver Specifications
Receiver Size
Double DIN
Anti-Theft Security
Detachable Controls
Wireless Remote
Peak Power Output
50 watts x 4 channel
RMS Power Output
22 watts x 4 channel
Preamp RCA Outputs
3 Sets (6-channel)
Dedicated Subwoofer Preamp RCA Output
Preamp Voltage
4 volts
Built-In Equalizer
EEQ - 3 Band Parametric EQ
Display Type
TFT-LCD Display
Expandability Features
Audio/Video (Rear)
Auxiliary (Front)
Backup Camera
Memory Card Slot
Steering Wheel Control Compatible
Yes (Accessory required and sold separately)
AM/FM Tuner
FM Presets
AM Presets
Navigation Features
Map Database
Tele Atlas
Complete 50 USA
Map Dimensional Display
Points of Interest
12 Million
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Model Number:




Internal SKU:


Internal Product ID:


Product and How-to Videos

Customer Ratings & Reviews

5 star
4 star
3 star
2 star
1 star


Customer Reviews

Sort by:


Pioneer Naav

A decent unit, but still quite a few bugs to be worked out. Pioneer has just released a software/map update that supposedly is going to fix a lot of the lingering issues, however, because it also contains a map update (which I don't need-my unit is less than five months old), Pioneer is forcing us to spend another $60 to get this update (which should have been free and available separately from the map update). Bad business on Pioneer's part. I won't buy from them again.

By Jill on August 18, 2009


found this helpful.

Great Product, did not experience the flaws of others

I was a bit guarded when I purchased this item, it's sold as Pioneer and Premier with a few minor differences. Yes it is at time a bit slow at responding to commands. Don't buy it for VR (Voice Recognition) as that aspect is over rated. It does work but not to the extend that one would expect or see on ads from Pioneer. Most units should now hat the 2.0 firmware upgrade, if you don't have this be sure to visit Pioneer and download it. I was disappointed with the MSN as it only works in the city you register the unit. Thus if you travel you won't get full use of this function. The signal is first rate and drives my speakers clearly. While it sounds great using the built in amp I used a Premier 4 channel class D amp to drive my front and rear separates. Sound quality is excellent. IPOD functions well but you'll need to use Itunes to have Album work displayed, other programs such as Media Monkey seem to have tagging problems and don't allow Album work to show on this unit. CDs and DVDs look excellent on the screen. Most back up cameras will also work well with this unit. I choose to have the BU camera come on when ever the car is in reverse. I don't like the shinny black finish and would prefer the non shinny look which comes on the non-DVD CD only unit. While you can use the same harness as a Pioneer D3 which this unit replaces you'll have to change a few of the wires. The GPS antenna is also different and that will need to be re-routed. HD radio works well when it works but don't get your hopes up if you want to change from Sat radio as HD does not work that well all the time, especially in fringe areas.

By Bob on May 12, 2009


found this helpful.

great head unit but.......

I own this head unit. I like some things about this unit but the second input is in the front and input one must be used for the iPod. I have a iPod and the pioneer XDV-P6 and unlike what you may read on some web sites it is not Compatible with this unit. This unit only has a ibus input and need the data video input to be Compatible. so I had to used a mini jack input on the front to use my i pod and my dvd changer!! so no clean install!! I also have the Pioneer GEX-P10HD and you will need a splitter to also use your msn direct!! The antenna must be connected for your msn to work but you also need that for you HD radio!! Also the msn needs to stay connected for some of its data and when you shut your car you shut off you msn direct so you must wait when you start you car to get that data!! The Garmin msn is better! More data better loading time and better options on the unit!! This is a great unit if your looking for just nav and ipod but if you want more get the upgrade!!

By david on January 25, 2009


found this helpful.

Tons Of Features

So this head unit was easier to install then I thought! Great features and sound quality. iPod function is amazing. Screen is clear and responsive once you get the hang of it. Navigation is easy and fun to play with. Bluetooth is a must and comes with it! The only thing I do not like is the display of the time. I'm always needing to look at the clock and its displayed so small on the screen....other than that great unit!

By Matthew on February 12, 2009


found this helpful.

F90BT Product Review

Great product!!! Installation was a breeze after spending the time reviewing the installation manual. All components working as specified. Love the voice recognition cell phone function. I would recommend this GPS and the price was Great!!

By Merlin on August 3, 2009


found this helpful.

Major disappointment

Great idea, but horrible execution. Miserable user interface. Tons of lag when using map features, HD radio add-on is disgracefully bad (both sensitivity and UI), annoying beeps that can't be turned off.. basically everyone who gets in my car makes fun of my radio after trying to use it for 2 minutes.

I've owned a number of Pioneer products in my life, and they were all great. Not this one.


By D on June 14, 2009


found this helpful.


Just received this unit in the mail yesterday from Sonic Electronix. I got it installed last night in my 2007 Ford F-150. This unit is great on the features... Spent 2 hours playing with it last night. I did the move the pin around in the harness mod so the video/nav works while driving. Only things I don't like are 1) little slow on bootup (much better with the 2.0 upgrade) , 2) Not real crazy about the look of the unit from the front (especially on the left side) 3) All the rca's hanging out the back of the unit makes shoving it in the dash a little tight (could be a nightmare on some cars) Other than that unit works great! Cheap as heck too in my opinion ($650) If you looking for some flash with function for your dash, this is a definite buy!

By James M on January 6, 2009


found this helpful.


I strongly recommend this head unit. I have it in a Lincoln Mark LT with components and it sounds great. More than that though, is the incredible flexibility, capability, and fantastic ipod interface. I even had to send the unit back in for a reinstall of the OS and still give it 5 thumbs up. Two years parts and Labor can't be beat!

By Dwight on April 21, 2009


found this helpful.

Great product at a great price.

I have had my in dash navigation system for over 6 months now and I think it was the absolute best product I could have bought. The navigation works perfect and the built in I-pod controls are great. Very easy to set up and use. Installation is a bit more involved than your average cd player, but someone with reasonable electronics experience should have no trouble. I would not reccomend a first time car stereo installer try it on their own though. Great product for a great price and fast delivery from the company. I would buy it again in a heartbeat.

By Kevin on March 21, 2009


found this helpful.


I replaced a Valor in dash dvd/nav with this. What a difference. The boot time can be slightly annoying at times. It has features I have yet to use. The navigation product is pretty accurate and has a lot to offer.

By greg on July 24, 2009


found this helpful.
