See all parts that fit your 2008 LS460

Diamond Audio D6 1000.2

1000W Max, D6 Series 2-Channel Amplifier (D61000.2)

Diamond Audio
Shop all Diamond Audio
Product videos
highlight-star-icon

D6 Series 2-Channel Class A/B Car Amplifier • 250W x 2 Chan. @ 4 ohm • 500W x 2 Chan. @ 2 ohm • 1000W x 1 Chan. Bridged • LED Power Indicators • Supports Daisy Chaining • Aluminum Alloy Heatsink • Tuned Bass EQ

Learn more about the d610002

We apologize

This item has been discontinued


Loading...
82-8146 main

Metra 82-8146

6x9" Speaker Bracket for select 2002-2024 vehicles from Toyota, Subaru, Lexus

31
-46.07%

$19.95

List price $36.99

Lowest price in 30 days
H7694 main

Cerwin Vega H7694

800W Peak (150W RMS) 6x9" HED Series 4-Way Coaxial 4-ohm Speakers

32
-25.93%

$79.99

List price $107.99

S2-S40 main

Alpine S2-S40

280W Peak (90W RMS) 4" S-Series Hi-Res 2-Way Coaxial 4-ohm Car Speakers

2
-15.42%

$109.95

List price $130.00

CVP69 main

Cerwin-Vega CVP69 (Sold Individually)

300W Peak (150W RMS) 6x9" CVPRO Series Pro Full Range 4-ohm Speaker

1
-16.67%

$49.99

List price $59.99

XED1T main

Cerwin-Vega XED1T

1000W Peak (90W RMS) 1” XED Series 4-ohm Piezo Dome Tweeters

19
-16.67%

$29.99

List price $35.99

Product Highlights


D6 Series 2-Channel Class A/B Car Amplifier • 250W x 2 Chan. @ 4 ohm • 500W x 2 Chan. @ 2 ohm • 1000W x 1 Chan. Bridged • LED Power Indicators • Supports Daisy Chaining • Aluminum Alloy Heatsink • Tuned Bass EQ

Description


Introducing the Diamond Audio D6 amplifier. Capable of powering up to 2 channels of audio signal with its MOSFET power supply. This amp has all the standard features that you will find on the standard amplifiers, but many more. Consider the daisy-chaining capabilities. Consider the panel mounted RCA jacks. Consider the 30% more aluminum in a 20% smaller heat sink. Consider the Diamond Audio quality. When looking for a solid amplifier to get the job done, look at the Diamond Audio D6 amplifiers. You are sure to be impressed.

  • Diamond Audio D6 Series 2-Channel Class A/B Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 250 watts x 2 Chan.
    • 2 ohm: 500 watts x 2 Chan.
    • Bridged, 4 ohm: 1000 watts x 1 Chan.
  • MOSFET power supply
  • Power On and Protection LED power indicators
  • Tuned Bass EQ (0-18 dB bass boost)
  • 2/1 Channel operation
  • Pass-thru line output for daisy chaining amplifiers together
  • Thermal, short circuit, and overload protection
  • Chassis mounted ATC/ATO type automotive fuses
  • Heavy duty aluminum alloy heatsink for heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Variable high-pass filter (30-500 Hz, 12 dB/octave)
  • Variable low-pass filter (30-500 Hz, 24 dB/octave)
  • Frequency response: 20-20,000 Hz
  • Versatile for either full range or subwoofers
  • Dimensions: 19-5/8"L x 9-5/8"W x 3"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 1-year SonicElectronix.com warranty

Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

SXE-6926S main

Alpine SXE-6926S

280W Peak (90W RMS) 6x9” SXE Series 2-way 4-ohm Coaxial Speakers

13
-20.84%

$56.99

List price $71.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
250 watts x 2 channel
RMS Power @ 2 ohms
500 watts x 2 channel
Bridged RMS Power
1000 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
2-Channel
Total RMS Power Output
1000 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.02%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
20 - 500 Hz
Low-Pass Crossover Frequency
30 - 500 Hz
Bass Boost
0 - 18 dB
Remote bass/level controller
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

D6-1000.2

Weight:

12.00lbs

Internal SKU:

d610002

Internal Product ID:

15814

Product and How-to Videos
