JL Audio 12W6v3-D4 - New (Damaged Packaging, Product A+)

600W RMS 12" W6v3 Series Dual 4-Ohm Subwoofer

JL Audio
Shop all JL Audio
Only 1 Left!
highlight-star-icon

• Injection-molded, mineral-filled polypropylene cone
• Large-diameter, progressive roll spider
• Rubber Surround
• Floating Cone Attach Method
• DMA Optimized Motor

Learn more about the 12w6v3d4_ob
Was $899.99 Details
Thanks , You Pay:

$683.00

 with warranty

Heads up

We confirm fitment and offer accessories for speakers. Please set your vehicle first if you would like to purchase more than one 12w6v3d4_ob.

Set your vehicle or Return to product page
shipping truck icon Free shipping in USA. Provide zip for delivery date.
Quantity
In Stock. Only 1 Left!
New, Damaged Packaging

Buy it now


Acima Logo

No Credit Option

Flexible Lease Payments

Early Purchase Options

Quick Approval Decision

Swoosh Icon Icon of Swoosh

For over 24 years, we've been your X-Factor – the team dedicated to having the biggest impact on your shopping experience!

Award winning icon
Award-Winning Service
Shipping icon
FREE Shipping Orders $49+
60 days return policy icon
60-Day Easy Returns
lowest price guarantee icon
Guaranteed Lowest Price
inHouseExpert
In-House Experts

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New:
A Open Box, Like New product is an apparently untouched product in perfect condition that includes all accessories and packaging. The original protective wrapping may be missing, but the original packaging is intact and pristine. There are absolutely no signs of wear on the item or installation. Instructions are included. Warranty details are included in the item description or comments. Item is suitable for presenting as a gift and savings should be abundant!

Product Features:

  • 12" W6v3 Series Subwoofer Driver
  • Power Handling:
    • RMS: 600 watts
  • Recommended Power Range: 200 - 600 watts
  • Impedance: Dual 4-Ohm
  • Injection-molded, mineral-filled polypropylene cone
  • Durable rubber surround
  • Large-diameter, progressive roll spider
  • Satin black cast alloy basket
  • Silver accent ring around cone
  • Customization trim ring
  • Floating-cone attach method
  • Massive forced-air-cooled aluminum alloy frame
  • Highly linear, DMA-Optimized motor system
  • Elevated frame cooling design
  • Patented pole-vent airflow control
  • Terminal jumper wire system
  • Engineered lead-wire design and attachments
  • Black Steel-Mesh Grille Insert Available: JL Audio SGR-12W6v2/v3
  • Precision-built in USA at JL Audio's Miramar, Florida factory
  • Mounting depth: 7.52 "
  • Cutout dimensions: 11.02 "
  • Free Air Resonance (Fs): 26.919 Hz
  • Sensitivity: 85.4 dB
  • Xmax: 19 mm
  • Reference Efficiency (no): 0.1100%
  • Frequency response: ~20 ~ 200 Hz
  • Matching Amplifiers:
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

PDF Icon Check out the JL Audio 12W6v3-D4 Owner's Manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 12W6v3-D4 - New (Damaged Packaging, Product A+) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 12W6v3-D4 - New (Damaged Packaging, Product A+) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 12W6v3-D4 - New (Damaged Packaging, Product A+) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 12W6v3-D4 - New (Damaged Packaging, Product A+) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W6 v3 Series
Subwoofer Size
12"
RMS Power Handling
600 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohms
Frequency Response
20 - 200 Hz
Sensitivity
85.4 dB
Xmax (millimeters)
19 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Butyl Rubber
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
1.00 cubic feet
Optimum Ported Box Volume
1.30 cubic feet
Top-Mount Depth (Mounting Depth)
7.52"
Cutout Diameter
11.02"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
26.919 Hz
Equivalent Compliance (Vas)
1.920 liters
Total Speaker Q Value (Qts)
0.463
Electrical Q Value (Qes)
0.487
Electrical Resistance of Voice Coil (Re)
6.493 ohms
Mechanical Q Value (Qms)
9.365
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

12W6v3-D4

Weight:

32.40lbs

Internal SKU:

12w6v3d4_ob

Internal Product ID:

165655

Customer Ratings & Reviews



5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
4.9
Value
4.8
Features
5
Design
5
Usability
5

Customer Photos & Videos


Customer Reviews

Sort by:

Loading...

Awesome sub

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

Sub sounds great of course.. I have it in a ported box @1.30 and is tuned @33hz.
PROS... it hit every bass note.. i also have it on a JL 500/1 ..can't go wrong with JL.
CONS ... PRICE... PRICE...PRICE

By Steven on June 16, 2023 Checkmark Icon Verified purchase

54

found this helpful.

Clear, powerful bass

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

These subs are amazing. I could finish the review there. I used to run two Kicker CVRs (as a first pair) but was sold on a pair of W6s after a demo by an audio retailer. I am running these with a Rockford T-1000 in a ported box, and stock radio (waiting for an interface kit on backorder), and these subs are monsters. I have to warn people before they sit in the backseat of my car (2014 Elantra) because these things HIT. You would think they were in the cab with you, and the SQ is unbelievably clean. I have friends with L7 SoloBarics, and while they might get louder, it sounds clangy and choppy. They are envious of how clean these W6s hit compared to the SoloBarics. Sure, they are a bit pricey, but any audiophile would be proud to own subs that sound like this. The only downside really is that when I run them at over +9 db, they shake the mirror and the sunglasses holder in my car loose. I really look forward to hearing them with the Excelon touchscreen that's going in. I'd like to hear the highs a bit more, but I'll probably have to tune the inside speakers for that.

By JQueezy on August 3, 2014

57

found this helpful.

12W6. High Price, High Quality

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

I have owned this subwoofer for 6 years now and it is still going. I'm very impressed since I have ran it on many 12 hour long trips. I feel that I abuse this thing. Hours of Dubstep and how my brother in-law puts it, "Speaker murder." I am running it off a JL 500/1v2 at 2ohms and it is placed in a ported box with 1.5cubic feet tuned to 31hrz just as recommended.

I was surprised that it hits the high notes pretty good and destroys your chest with the low notes. Many people look for LOUD woofers and think that is 'good bass' or 'sound' quality. This sub is loud but it is so impressively clearly! I love when people tell me there subs are louder. Yea maybe 5-10db, but I hear their's bottoming out and distortion filled.

The excursion really helps keep this thing cool and the quality build is meant to last. It is a lot of money up front for one sub but over the coarse of 6 years, not so bad. I would definitely purchase again IF I could afford the money upfront at that point in time. As of now, I'm 6 years in and its still experiencing 'speaker murder' by my favorite DJs.

ps: I know 12's can get a little slopping and can get behind on notes. I was shocked to hear this thing punch 16th note bass sequences. Every note clear and precise. Amazing.

Running: 5001v2 on 1 12w6v2, 400/4v2 on c2650s with Clean Sweep sound processor.

Pros: Amazing sound quality through the full range. Quality build. Made in U.S.A. You only need one.

Cons: Box size (if your worried about cargo space), Upfront price, your fiancé will think its to loud, and hearing loss.

By Greg on April 22, 2014

59

found this helpful.

Worth Every Penny!!

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

This sub is really expensive so it might turn a lot of people away. But for those looking for high quality stuff that isnt going to crap out once you turn your volume up, jl is the way to go. In terms of performance this sub gets really loud in the custom ported box i have for it. it sounds like two 13 w1's in a sealed box loud wise. it carries farther so it seems louder and it reproduces notes on a level on its own. the lows are as deep and as clear as you're gonna get and it hits every note subs are supposed to. my subs take a toll because i use them for every day use and i like my music to pound. i have this sub wired at eight ohms hooked to a rockford 1000 bdcp with the gain at five and it takes it like a champ and performs like the hype says it should.

By Joseph on August 7, 2013

51

found this helpful.

Best price anywhere

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

I took the open box option and got this sub for $549 ... I could not believe I was buying the 12 for the price of the size 10 version! Prior to Sonic Electronix I was looking at JL directly as well as other well known options and the prices were all near original retail. Then I started looking at used private sellers but I know that certain high dollar things just need to be new in order to know you are getting your money worth. Damn glad I kept searching and stumbled across this site. Item arrived on time as promised and I found zero flaws. Everything was in the original box including decals and warning labels. If this is how every open box item comes I’d always buy open box items from Sonic Electronix. It’s like they just opened the box, looked at it, and closed the box. The money saved went towards a ported box built to spec. I haven’t installed the sub yet because I’m still collecting items. I wanted to secure this sub and build around it otherwise I may have ended up settling for less on a sub selection. I’m pretty stoked, great site, I’ve already recommended it to several people, and buying more from here to build my system.

By Michael on October 29, 2020 Checkmark Icon Verified purchase

29

found this helpful.

Just get it!

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

This is the rare occasion when an expensive, top of the line item is worth the extra money. I downsized from a 15 in a 3.5cuft ported box in a car to two of these in a 2cuft sealed box in a truck. There’s no comparison! The 15 wasn’t a jl product but my goodness the diff is unreal. Had two 12” Audiofrog subs, gs not go, in my truck before this and I just wasted my money on those. Just buy these and end your search for good sq with high output.

By maurice on October 19, 2020 Checkmark Icon Verified purchase

29

found this helpful.

WOW!

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

This thing is a BEAST. It doesn't get much better than this sub. Great quality and sound.

By cj on January 21, 2020 Checkmark Icon Verified purchase

28

found this helpful.

Clean hard hitting Bass, One sub is all you need!

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

I have had the 10W0, 12W1, 12W3 and now the 12W6. This is by far the best sounding hardest hitting sub I've owned. First be sure to give it a full 600 watts to get the best sound. I was using a JL XD600.1v2 and it sounded OK, but I knew it could be better. I mated it with a Kicker KXa800.1 and boy the bass was pounding my back and ringing my ears! All you need is one of these subs in a Spec 1.3 cubic foot ported box (built my own) and this subs hits hard, go lows and plays for hrs.. People says JL is over rated and expensive. The only other sub I've heard that sound this good were 2 Cerwin Vega 12's and that was back in 1998.

By Anonymous on July 26, 2019

27

found this helpful.

JL Audio 12W6v3-D4

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

Ive heard w7s i've owned the w3v3 but this 12w6v3 is better then both imo rubber surrounds dead accurate even ported and it doesn't require a lot of power to get loud the w7 is louder and more forceful but thats it the w6v3 plays cleaner more accurate and has deep low bass it's an amazing sub and it's worth the price

By Anonymous on June 22, 2018

27

found this helpful.

Awesome company

The following review is for 12W6v3-D4, which is a part of the bundle you are viewing.

Great product; it was worth EVERY penny spent. Sonicelectronix is worth every dollar they charge. Great products at great prices, you can't go wrong!

By Janell on October 3, 2015 Checkmark Icon Verified purchase

28

found this helpful.
