Product videos

Product highlights

• Alpine S-Series Mono Power Amplifier - S-A60M
• 400W RMS x 1 (4ohm, 14.4V < 1% THD+N)
• 600W RMS x 1 (2ohm, 14.4V < 1% THD+N)
• Remote bass knob compatible

Learn more about the sa60m

Product Highlights

• Alpine S-Series Mono Power Amplifier - S-A60M
• 400W RMS x 1 (4ohm, 14.4V < 1% THD+N)
• 600W RMS x 1 (2ohm, 14.4V < 1% THD+N)
• Remote bass knob compatible

Description

Authorized dealer

Product Details:

Alpine S-Series Mono Power Amplifier - S-A60M
RMS Power Output:

400W x 1 @ 4 Ohm (14.4V < 1% THD+N)
600W x 1 @ 2 Ohm (14.4V < 1% THD+N)

S/N ratio: >85dB (ref: 1W into 4 ohm), >105dB (ref: rated power into 4 ohm)
Remote bass knob compatible (requires RUX-KNOB.2, sold separately)
CTA-2006 compliant
THD+N ≤ 0.03% (ref 1W info 4 ohm)
Frequency Response: 10HZ-400Hz (+/- 3 dB)
Damping Factor: > 1000
variable low-pass filter (50-400 Hz, 24 dB/octave)
variable bass boost (0-12 dB at 50 Hz)
Speaker-level inputs (Speaker Wire to RCA Adapter Required)
Preamp Inputs
Improved heat sink and protection circuit design that eliminates thermal shut-down, for dependable music playback
Remote Sensing automatic turn-on when using speaker-level inputs
Approximate Weight: 11 lbs
Fuse Rating: fuse rating: 30A x 2
4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
Dimensions: 8” W x 8” H x 2.25” D
Authorized Internet Dealer
1-year Manufacturer's Warranty

Specifications & Details

Power Specifications - Subwoofer Channel

RMS Power @ 4 ohms

400 watts x 1 channel

RMS Power @ 2 ohms

600 watts x 1 channel

Power Specifications - Subwoofer Channel

Peak Power @ 4 ohm

800 watts x 1 channel

Peak Power @ 2 ohms

1200 watts x 1 channel

Amplifier Specifications

Series

S Series

Amplifier Class

Number of Channels

1 - Mono

Total Peak Power Output

1200 watts

Total RMS Power Output

600 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

Not Bridgeable

THD at Rated RMS Power

<1%%

Speaker Level Inputs

Yes

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)

Low-Pass Crossover Frequency

50 - 400 Hz

Bass Boost

0 - 12 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Fuse Rating

30A x 2

Total Fuse Rating

Strappable

Sonic Certified Amplifier

Not Tested

Amp Bluetooth Connectivity

Hi-Res Certified

What is in the box?

Paperwork

User manual
Warranty/Registration card

WITB: Amplifiers

Amplifier
Mounting screws (4)
Allen wrench

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer

Customer Ratings & Reviews

Rate or review product

Overall rating distribution

5 star		71%
4 star		29%
3 star		0%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		4.7
Value		4.7
Features		4.2
Design		4.7
Usability		4.7

Customer Reviews

Sort by:

Works perfect

Using it to power a 10inch alpine type s and it sounds amazing

By Anonymous on October 5, 2019 Checkmark Icon

Verified purchase

found this helpful.

Helpful? Report abuse

Smacks

Good amp For dual 12 set up I got in my car!

By Juan on May 30, 2020 Checkmark Icon

Verified purchase

found this helpful.

Helpful? Report abuse

Good entry level amplifier

This amp is basic when it comes to features, but outstanding when it comes to sound. I push mine pretty hard at 2ohm powering an older type R 10 inch in a ported enclosure that can handle up to 1000rms of power. It slams pretty hard, makes the sub really move, and provides a clean, punchy sound. Barely warms up pushing the power-hungry type R. If you powered 2 lower RMS subs with this amp like the Type S, you will have enough bass to rattle your trunk and mirrors with ease. I purchased the RUX-Knob with mine. Which I think is a must-have.

By Dennis on May 26, 2020

found this helpful.

Helpful? Report abuse

perfect value

being my first alpine amp, this has met my expectations and more. even though the amp's test card said 851 watts like several others I've seen on the net, which leads me to believe it may be generic although hand written, it seems to pack quite a punch. this amp has most of the features that you'd find in more expensive units. although it lacks high level speaker inputs it didn't bother me as I needed a line out converter anyway. I paired this with the infinity primus 1270b loaded enclosure and it has more than enough power to push it. my factory stereo was missing some hard hitting bass and the combo I chose definitely has me wanting to go places just to jam out. I'm considering getting another set for my other vehicle as well.

By Derek on July 29, 2022 Checkmark Icon

Verified purchase

found this helpful.

Helpful? Report abuse

Good small powered amp

Good priced amp but not as well as the 500 with high pass input built-in

By Music Man on September 8, 2022

found this helpful.

Helpful? Report abuse

Good small powered amp

Good priced amp but not as well as the 500 with high pass input built-in

By Music Man on September 8, 2022

found this helpful.

Helpful? Report abuse

By Tyson Cox Sunbelt on March 25, 2024 Checkmark Icon

Verified purchase

found this helpful.

Helpful? Report abuse
