JBL Club A1000 (AMPCBA1000AM) (Open Box, Good)

200W Peak (1000W RMS) Class D Club Series Compact Monoblock Amplifier with Bass Remote

JBL
Shop all JBL
highlight-star-icon

• 600 watts x 1 channel @ 4 ohm
• 1000 watts x 1 channel @ 2 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable Monoblock Amplifier

Learn more about the ls-cluba1000-u7

We apologize

This item has been discontinued

Description


JBL brand icon

Authorized dealer

Item Condition - Open Box, Good:

This product is used, but it will work like new and is in overall good condition. It will show signs of wear that can include scuffing, scratches, fingerprints, dents, and worn corners or installation marks. May be missing non-essential parts, accessories or original packaging.


JBL Club A1000

New high performance JBL Club amplifiers deliver world class JBL power from a compact chassis built to fit in more vehicles, even when space is tight. Club amps feature variable crossovers and bass boost for precise control and tuning, plus high-level and low-level inputs that let them integrate with most car stereos. A wired remote bass level control is included and can be mounted for convenient volume adjustment from driver seat.


Product Details:

  • Club Series Class D 2 ohm Stable Monoblock Amplifier
  • RMS Power Rating:
    • 4 ohm: 600 watts x 1 channel
    • 2 ohm: 1000 watts x 1 channel
  • Total RMS power output: 1000 watts
  • LED Power/Protect Light
  • Wired bass level remote control included
  • Speaker-level (high-level) inputs
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Compact size with low-profile chassis
  • Full on-protection circuitry (short-circuit, high-temperature, overvoltage and undervoltage
  • Input sensitivity:
    • Low level: 200mV - 2 volts
    • High level: 2 - 20 volts
  • Frequency Response: 10 - 320 Hz
  • Total Harmonic Distortion (THD): 1%
  • Signal to Noise Ratio: >80 dB
  • Variable low-pass filter: 32 - 320 Hz
  • Variable Bass Boost: 0 - 12 dB
  • Phase Shift - 0 - 180 degrees
  • Fuse Rating: 105A
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 12-5/8" L x 7-1/8" W x 2-1/16" H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • MFR #: AMPCBA1000AM

Specifications & Details


Key Features
Amplifier Key Features
Bass Boost
Compact Design
Speaker Level Inputs
Power Specifications - Subwoofer Channel
RMS Power @ 4 ohms
600 watts x 1 channel
RMS Power @ 2 ohms
1000 watts x 1 channel
Amplifier Specifications
Series
Club Series
Amplifier Class
D
Number of Channels
1 - Mono
Total Peak Power Output
2000 watts
Total RMS Power Output
1000 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
Not Bridgeable
Frequency Response
10 - 320 Hz
THD at Rated RMS Power
1%
Speaker Level Inputs
Yes
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
32 - 320 Hz
Signal-to-Noise Ratio
>80 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
Yes
Fuse Rating
35A x 3
Total Fuse Rating
105
Sonic Certified Amplifier
Not Tested
Amp Bluetooth Connectivity
No
Hi-Res Certified
No
Low-Level Input Sensitivity
200mV - 2 volts
High-Level Input Sensitivity
2 - 20 volts
What is in the box?
Paperwork
User manual
WITB: Amplifiers
Amplifier
Wired gain knob (wire separate)
Mounting screws (6)
Three spare fuses
Adhesive brand badge
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

JBL

Model Number:

AMPCBA1000AM-2

Weight:

8.00lbs

Internal SKU:

ls-cluba1000-u7

Internal Product ID:

220323
