NVX XAD41 (Like New (Open Box))

1200W RMS X-Series Full-Bridge Class D 1-Ohm Stable 4-Channel Amplifier

NVX
Shop all NVX
Product videos
highlight-star-icon

• 100 watts x 4 channel @ 4 ohm
• 150 watts x 4 channel @ 2 ohm
• 300 watts x 4 channel @ 1 ohm
• Total RMS Power: 1200 watts
• CEA-2006 Compliant

Learn more about the ls-xad41-u9

We apologize

This item has been discontinued

Product Highlights


• 100 watts x 4 channel @ 4 ohm
• 150 watts x 4 channel @ 2 ohm
• 300 watts x 4 channel @ 1 ohm
• Total RMS Power: 1200 watts
• CEA-2006 Compliant

Description


NVX brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)

4 Channel Class D Amplifier
1 Ohm Stable Bridgeable Down to 1 Ohm Small Chassis
Mosfet Power Supply

Product Details:

  • NVX X Series Series XAD41
  • Class D 1 ohm 4-Channel Amplifier
  • RMS Power Rating:
    • 4 ohm: 100 watts x 4 channel
    • 2 ohm: 150 watts x 4 channel
    • 1 ohm: 300 watts x 4 channel
    • Bridged, 4 ohm: 300 watts x 2 channel
    • Bridged, 2 ohm: 600 watts x 2 channels
  • Total power output: 1200 watts
  • CEA-2006 Compliant Amplifier
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Soft start turn-on
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Dual speaker terminals simplify the hookup of multiple speakers
  • Input sensitivity: 200mV
  • Frequency Response: 10Hz - 20kHz
  • Total Harmonic Distortion (THD): 1%
  • Signal to Noise Ratio: 100 dB
  • Variable high-pass filter: 40 - 500 Hz, 24 dB/octave
  • Variable low-pass filter: 40 - 500 Hz, 24 dB/octave
  • Variable Bass Boost: 0 to +12 dB bass boost at 50 Hz
  • 4 AWG gauge power and ground wiring is recommended for installation.
  • Dimensions: 7.375"W x 8.75"L x 2.5"H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
pdf icon Check out the NVX X-Series 4-Channel Amplifiers Owner's Manual

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 4 channel
RMS Power @ 2 ohms
150 watts x 4 channel
RMS Power @ 1 ohm
300 watts x 4 channel
Bridged RMS Power
300 watts x 2 channel
Power Specifications - Full Range Channels
Peak Power @ 4 ohms
200 watts x 4 channel
Peak Power @ 2 ohms
300 watts x 4 channel
Peak Power @ 1 ohm
600 watts x 4 channel
Bridged Peak/Max Power
600 watts x 2 channel
Amplifier Specifications
Series
X Series
Amplifier Class
D
Number of Channels
4-Channel
Total Peak Power Output
2400 watts
Total RMS Power Output
1200 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
1 ohm
Minimum Impedance Bridged
2 ohms
THD at Rated RMS Power
1%
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
40 - 500 Hz
Low-Pass Crossover Frequency
40 - 500 Hz
Signal-to-Noise Ratio
100 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
No
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Amplifiers
Amplifier
Wired gain knob (wire separate)
Gain knob wire
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

NVX

Model Number:

XAD41-3

Weight:

7.00lbs

Internal SKU:

ls-xad41-u9

Internal Product ID:

225271
