Rockford Fosgate HD14-SBSUB

General Features:

• Loaded Dual 10" Saddlebag Subwoofer Kit
• Compatible with select 2014-2023 vehicles from Harley Davidson
• Rotomolded HDPE enclosure material
• Plug-and-play design for easy installation
• Klippel Verified certification
• Enclosure designed for dual air space keeping 6x9" speakers rom 10" subwoofers
• Subwoofer kit includes grille sealing plug if enclosures need to be removed for touring
• RATS (Rockford Automated Testing System) proprietary quality & performance tested
• IPX6 marine rating
• Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
• No fasteners needed to keep enclosures in place
• Power Handling:
• Peak: 1200 watts
• RMS: 300 watts
• Final Impedance: 4-ohm
• Includes one Rockford Fosgate M5-800X4 4-channel amplifier
• Vehicle Specific enclosure
• Authorized Internet Dealer
• 2 Year Manufacturer's Warranty

Rockford Fosgate M1D2-10B 10" M1 Series Subwoofer Details:

• Injection Molded Polypropylene with UV Protection cone
• Santoprene Rubber surround
• Optically clear UV stable RGB Lighting Encapsulation
• Ultra-bright wide-angle Color Optix RGB LEDs (Rockford Fosgate PMX-RGB controller sold separately)
• RF Connect App is available to download on iPhone and Android
• Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
• 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environments
• Integrated Deutsch/Amphenol connectors make wiring connections simple and error proof
• VAST vertical attach surround technique increases effective radiating cone area up to 25%
• VERSA impedance switch quickly allows series or parallel configuration without additional wiring
• Fully insulated silicone tinsel leads
• Vented motor design with water-repelling nano coated mesh screen
• Zinc Nickel-plated Marine grade brass connection terminals
• Linear Synthetic Fiber Blend Spiders
• 2" high temperature voice coil
• 7mm Xmax
• 47.70 oz. Double Stacked magnet motor structure
• Frequency Response: 20 - 750 Hz
• Resonance Frequency (Fs): 34 Hz
• Sensitivity: 91.5 dB
• IP67 Certified

Rockford Fosgate M5-800X4 4-Channel Marine Amplifier Details

• Class-AD technology
• PRESET removes the need to set-up and tune the amp when used with Rockford Fosgate UTV audio kits
• Element Ready design with integrated harness & panel seals
• OEM and aftermarket radio integration inputs
• Remote-Out feature when using high level inputs
• Top mounted control panel with Element Ready smoked lens cover
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Power Specifications
• 4 ohm: 125 watts x 4 channels
• 2 ohm: 200 watts x 4 channels
• Bridged @ 4 ohm: 400 watts x 2 channels
• Total RMS power output: 800 watts
• Frequency Response: 10 - 50000 Hz
• Total Harmonic Distortion (THD): <0.25%
• Variable low-pass filter: 50 - 250 Hz
• Variable high-pass filter: 50 - 250 Hz
• MFR #: M5-800X4

Enclosure Features:

• 10" Enclosure
• Total Box Volume:
• Tuning Frequency:
• Box Finish: Black HDPE Composite
