Alpine i509-WRA-JL

Product Details

• Custom Fit In-Dash Bluetooth Digital Multimedia Receiver
• 9" TFT-LCD Monitor Display
• Power Output:
• Peak: 50 watts x 4 channel
• RMS: 16 watts x 4 channel
• Bluetooth hands-free calling and audio streaming
• Includes Alpine Restyle package with all installation parts
• Retains factory rear-view camera and displays engine performance data on touchscreen
• Built-in HD Radio Tuner
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty
• MFR #: i509-WRA-JL

Smartphone Features

• Apple CarPlay and Android Auto compatible (Wired and Wireless)
• Display and control music and other apps with iPhone and Android
• Pandora and Spotify capable
• Siri Eyes Free control for select iPhones
• Tidal integration with custom display (requires a wi-fi connection and Tidal smartphone app)
• Wired phone mirroring for select devices via HDMI (MHL Cable like Alpine KCU-610MH or Rydeen MHL01 required and sold separately)

Playback and Audio Features

• MP3 | WMA | WAV (Hi-Res) | AAC | FLAC (Hi-Res) Audio Playback
• AVC | MP4 | MPEG-1/2/3 | MKV |MOV | FLV | H.263 and H.264 Video Playback
• AM/FM tuner with 18FM/12AM presets
• Equpied with Media Xpander HD to bring out the musical details lost in compressed media, and it is adjustable per source to get the most out of your digital audio media
• MP3 ID3 Tag Display (Title/Artist/Album)
• High and low-pass crossovers
• 13-band Parametric with Bass Engine SQ
• 3 Equalizer Presets

Expandability Options

• Satellite Radio Ready: Requires SiriusXM SXV300V1 and subscription, sold separately
• Steering Wheel Controls maintained via included iDatalink Maestro Module
• Retain your Jeep's factory OEM Alpine Premium Amplified System (if factory equipped) with the Alpine KCX-F200INT
• Add the Alpine KTP-445A Head Unit Power Pack to deliver 45 watts x 4-channel RMS of power
• Add a Alpine RUX-H02 rotary volume knob and subwoofer level controller connected via bluetooth
• Optional Dash Cam: View and record what is going on in front of the vehicle, as well as inside or behind the vehicle via the Alpine DVR-C320R
• HDMI input allows connection to an optional DVD player (Alpine DVE-5300, sold separately)
• Access the latest maps without cell phone or Wi-Fi connection required with Alpine KTX-NS01

Audio/Video Inputs and Outputs

• 3 sets of 4 volts preamp outputs (front, rear, and subwoofer)
• Rear Auxiliary Input: 3.5mm headphone jack allows connection to your mobile device
• Two Rear USB Inputs: USB port allows connection to digital devices such as cellphones, flash drives, portable media players, etc.
• Three Backup Camera Inputs: Used for universal rear view cameras with an RCA composite input
• Rear HDMI input

Bluetooth Features

• Built-in Bluetooth technology for hands-free talking and audio streaming
• Includes a external wired microphone for clear, convenient, distortion-free talking

New Firmware Update Available

Alpine i509-WRA-JL Manual
