Name: Rockford Fosgate Punch P500-1BD Open Box
Brand: Rockford Fosgate
SKU: LS-09-p500-1bd-OB
Price: 229.99 USD
Availability: Discontinued

by Rockford Fosgate

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

Rockford Fosgate Punch P500-1BD Open Box Image 1 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box Image 2 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box Image 3 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box Image 4 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box Image 5 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box Image 6 — Rockford Fosgate Punch P500-1BD Open Box

Rockford Fosgate Punch P500-1BD Open Box-video

Product videos

Product highlights

Punch Series Monoblock Class BD Car Amplifier • 200W x 1 Chan. @ 4 Ohm • 400 x 1 Chan. @ 2 Ohm • 500 Watts x 1 Chan. • MOSFET Power Supply • RCA Pass-Thru Outputs • Custom Designed TO-247 MOSFETs • Built-In NOMAD Computer

Learn more about the LS-09-p500-1bd-OB

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Punch Series Monoblock Class BD Car Amplifier
RMS Power Rating:

4 ohm: 200 watts x 1 chan.
2 ohm: 400 watts x 1 chan.
1 ohm: 500 watts x 1 chan.

MOSFET power supply
Remote bass level input (remote level control sold separately)
LED power, thermal, and protect indicators
Tuned Bass EQ (0-18 dB bass boost at 45 Hz or 0-12 dB bass boost at 12 kHz depending on crossover selection)
On-board differential inputs eliminates noise picked up by the signal cable
Mono channel operation
RCA Pass-thru outputs
Featured custom designed TO-247 MOSFETs have 60% more metal tab area providing more power handling capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in most competitor's amps.
Built-in NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedance.
MEHSA3 reduces MOSFET temperatures, lowers distortion, and increases durability
Cast aluminum heatsink evenly distributes excess heat across entire amplifier heatsink
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Variable low-pass filter (35-250 Hz, 12 dB/octave)
Selectable infrasonic filter (28 Hz, 12dB/octave)
CEA-2006 compliant amplifier
Frequency response: 20-250 Hz
Dimensions: 10-1/4"L x 7-5/8"W x 2-1/4"H
4-gauge power and ground leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
1-year SonicElectronix.com warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

200 watts x 1 channel

RMS Power @ 2 ohms

400 watts x 1 channel

RMS Power @ 1 ohm

500 watts x 1 channel

Amplifier Specifications

Amplifier Class

Number of Channels

1 - Mono

Total RMS Power Output

500 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

1 ohm

Minimum Impedance Bridged

Not Bridgeable

THD at Rated RMS Power

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)

Low-Pass Crossover Frequency

35 - 250 Hz

Signal-to-Noise Ratio

100 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Rockford Fosgate PEQ

Fuse Rating

100A x 1

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Sonic Electronix
