AudioControl MATRIX PLUS

General Features:

• High signal voltage capability: 13 volts peak output
• 24dB of gain
• Six channels of input and output
• Balanced differential inputs
• Low-impedance outputs
• Optional Remote Level Control (ACR-1)
• PFM Subsonic filter
• Coated pcb for increased resistance to the elements
• Optimum voltage indicator LED’s
• Wired remote level control compatible

Specifications:

• Preamp Inputs: 3 (6 channels), Input Gain: 24dB, Input Impedance: 20kΩ
• Preamp Outputs: 3 (6 channels), Maximum Output Level: 9.5Vrms, Output Gain: -12dB to +24dB, Output Impedance: 50Ω
• Total Harmonic Distortion: 0.005%
• Frequency Response: 10Hz-100kHz ±1dB
• Signal to Noise: >110dB
• Transformer Isolated PWM
• Current Draw: 250mA
• Recommended Fuse Rating: 1A
• Dimensions: 4.6"W x 7.1"D x 1.2"H
