Alpine PSS-TSLA-223

Product Details:

• System includes two 6.5" front door speakers, two 4" midrange rear door speakers, three 4" midrange center dash speakers
• Also includes 10" sealed subwoofer, 12-channel DSP, and harnesses
• Designed and engineered to match and compliment the factory fit and finish
• Plug-and-play design for easy installation, no drilling or cutting required
• Sound system pre-tuned and optimized for the Tesla Cabin Environment
• Features high resolution audio certified
• Compatible with select 2022-2023 Model 3
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty

Alpine EV-65CF-T 6.5" Front Door Speakers:

• 6.5" 2-way component midrange speakers and 1" tweeters
• Power Handling:
• Peak: 400 watts per pair / 200 watts each
• RMS: 100 watts per pair / 50 watts each
• Carbon fiber hybrid cone
• High amplitude multi-roll (HAMR) surround
• Strontium ferrite woofer magnet
• Neodymium tweeter magnet
• Gold-plated terminals
• Frequency Response: 65 - 20000 Hz
• Sensitivity: 89 dB
• MFR #: EV-65CF-T

Alpine EV-40MR-T 4" Dashboard Speakers:

• 4" 2-way component midrange speakers and 1" tweeter
• Power Handling:
• Peak: 320 watts per pair / 160 watts each
• RMS: 80 watts per pair / 40 watts each
• Carbon fiber hybrid cone
• High amplitude multi-roll (HAMR) surround
• Strontium ferrite woofer magnet
• Neodymium tweeter magnet
• Gold-plated terminals
• Frequency Response: 100 - 18000 Hz
• Sensitivity: 90 dB
• MFR #: EV-40MR-T

Alpine EV-40M-T 4" Rear Door Speakers:

• 4" 2-way component midrange speakers
• Power Handling:
• Peak: 320 watts per pair / 160 watts each
• RMS: 80 watts per pair / 40 watts each
• Carbon fiber hybrid cone
• High amplitude multi-roll (HAMR) surround
• Strontium ferrite woofer magnet
• Neodymium tweeter magnet
• Gold-plated terminals
• Frequency Response: 100 - 18000 Hz
• Sensitivity: 90 dB
• MFR #: EV-40M-T

Alpine EV-100SW3-T 10" Subwoofer:

• 10" subwoofer in sealed custom-fit enclosure
• Power Handling:
• Peak: 1200 watts
• RMS: 200 watts
• Carbon fiber hybrid cone
• High amplitude multi-roll (HAMR) surround
• Strontium ferrite woofer magnet
• Neodymium tweeter magnet
• Gold-plated terminals
• Frequency Response: 25 - 300 Hz
• Sensitivity: 86 dB
• MFR #: EV-100SW3-T

Alpine PXE-X121-12EV 12-Channel DSP:

• 12-channel Sound Processor for Tesla vehicles
• Power Specifications
• Peak: 100 watts (Channels 1-6), 50 watts (Channels 7-10), 200 watts (Channels 11-12)
• RMS: 50 watts (Channels 1-6), 25 watts (Channels 7-10), 100 watts (Channels 11-12)
• Bridged (Channels 11-12): 400 watts Peak / 200 watts RMS
• High-resolution audio certified
• 12-channel high-level inputs and 10-channel outputs
• 2-channel low-level (RCA) inputs and outputs
• 31-Band Parametric or Graphic Equalizers
• High-pass / Low-pass / Band-pass crossover filters per channel
• Controllable via PC software or Alpine music application
• Frequency Response: 20 - 40000 Hz
• Input Connections: HD Bluetooth / Optical / Coaxial / USB (DAC)
• Sampling Rate: 96000 Hz / 24 bit
• MFR #: PXE-X121-12EV
