See all parts that fit your 2014 C-Max

Image Dynamics CX62 v.2

6-1/2" 2 ohm CX v.2 Chameleon Series Mid Bass Drivers

Image Dynamics
Shop all Image Dynamics
Product videos
highlight-star-icon

6.5" CX Chameleon Series Midbass Drivers • Midbass Drivers • 2 ohm Impedance • NBR Surround • Removable Phase Plug • 90db Sensitivity

Learn more about the cx62v2

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

P132 main

Rockford Fosgate Punch P1 P132

80W Peak (40W RMS) 3.5” Punch Series 2 Way Coaxial 4-ohm Speakers

47
T1650 main

Rockford Fosgate Power T1 T1650

300W Peak (150W RMS) 6.5" Power Series 2 Way Coaxial 4-ohm Speakers

10

Product Highlights


6.5" CX Chameleon Series Midbass Drivers • Midbass Drivers • 2 ohm Impedance • NBR Surround • Removable Phase Plug • 90db Sensitivity

Description


Image Dynamics brand icon

Authorized dealer

  • 6-1/2" CX Chameleon Series Midbass Drivers
  • Power Handling:
    • Peak: 500 watts per set / 250 watts each side
    • RMS: 250 watts per set / 125 watts each side
    • Recommended RMS Power Range: 25-125 watts each side
  • Multi-layered carbon fiber cone
  • Nitrile Butadiene Rubber (NBR) surround
  • Silk dome tweeter composition
  • Edge wound aluminum voice coil design
  • Heavy duty removable center phase plug
  • 2 ohm impedance
  • Top-mount depth: 3-1/16"
  • Sensitivity: 90 dB
  • Frequency Response: 65-25,000 Hz
  • Also available in a 4 ohm model: Image Dynamics CX64V.2
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Priced Per Pair of Midbass Drivers.


Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

59
-19.05%

$339.99

List price $420.00

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

AVH-3500NEX main

Pioneer AVH-3500NEX

7" Single DIN Flip-Out Touchscreen CD/DVD Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

9
-10.75%

$829.99

List price $930.00

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Limited time!
DMX709S main

Kenwood eXcelon DMX709S

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

39
-33.50%

$399.00

List price $600.00

Limited time!
iLX-W670-M main

Alpine iLX-W670-M

6.75" Double DIN Touchscreen Digital Multimedia Receiver with iDataLink Maestro Support, Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

126
-30.01%

$349.95

List price $500.00

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99


Best selling similar products

46CSC654 small

Kicker CSC65 (46CSC654)

• 300 watts Peak Each, 100 watts RMS Each
• 1/2" PEI (Polyetherimide) Balanced Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 90 dB

(254)

$79.96

List price $119.99

Club 622 small

JBL Club 622

• 180 watts Peak Each, 60 watts RMS Each
• Silk Edge Driven Dome tweeters with 0dB or -3dB adjustable output levels
• UV-Resistant Polypropylene cone material with Plus One woofer cone architecture
• Impedance: 3 ohm
• Sensitivity: 93 dB

(5)

$99.95

List price $139.95

DB652 small

Polk Audio DB652 (DB 652)

• 300 watts Peak Each, 100 watts RMS Each
• 3/4" Silk Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 92 dB

(214)

$109.00

List price $119.99

Specifications & Details


Speaker Specifications
Speaker Size
6-1/2"
Design
Mid-range
Tweeter Design
Soft Dome
Tweeter Composition
Silk
Woofer Composition
Woven Carbon Fiber
Woofer Surround
Nitrile Butadiene Rubber NBR
Peak Power Handling
250 watts
RMS Power Handling
125 watts
Sensitivity
90 dB
Frequency Response
65 - 25,000 Hz
Impedance (Per Voice Coil)
2 ohm
Shallow Mount Installation
No
Top-Mount Depth (Mounting Depth)
3-1/16"
Bottom-Mount Depth
3-3/16"
Cutout Dimensions
5-3/4" x 5-3/4"
General specifications
Speaker Grilles
Yes
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

CX62V.2

Weight:

8.50lbs

Internal SKU:

cx62v2

Internal Product ID:

22326
