(2) Kicker L7T124 12" Solo-Baric L7T Dual 2-ohm Shallow Subwoofer

Description

Authorized dealer

Kicker L7T122 (46L7T122)

1200W Peak (600W RMS) 12" Solo-Baric L7T Series Dual 2-ohm Shallow Car Subwoofer
Quantity: 2

Product Details:

12" Dual 2 ohm Solo-Baric L7T Series Subwoofer
Power Handling:

Peak: 1200 watts
RMS: 600 watts

ANSI/CTA-2031-A Compliant
SoloKon Polypropylene Cone with 360-degree back bracing
Ribbed Santoprene Surround
Compatible with sealed or ported enclosure
Square design moves 20% more air than round subwoofers
Easily mounts under or behind the seat
Bumped top plate for more excursion and smoother performance
UniPlate solid pole piece and backplate for excellent heat dissipation
Made with steel basket for added durability
10.25 mm Xmax
Frequency Response: 25 - 100 Hz
Resonance Frequency (Fs): 26.3 Hz
Sensitivity: 86.54 dB
Recommended sealed box volume: .55 cubic feet - 1.25 cubic feet
Recommended ported box volume: 1.75 cubic feet - 2.25 cubic feet
Top-mount depth: 4-1/8"
Cutout diameter: 11-1/16"
Mesh grille: Kicker 52GL712 (sold separately)
Grille insert: Kicker GL712 (sold separately)
Authorized Internet Dealer
1-year Manufacturer's Warranty

Sold Individually

Kicker 46L7T122 owner’s manual

Subwoofer Wiring Guide

Wiring Guide to Wire 1 Kicker L7T122 (46L7T122) - Pair Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Kicker L7T122 (46L7T122) - Pair Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Kicker L7T122 (46L7T122) - Pair Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 Kicker L7T122 (46L7T122) - Pair Subwoofers

2 Channel Amp

4 Channel Amp

Similar Products

Best selling similar products

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

NVX SQW124

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.51"
• Sensitivity: 84 dB

$299.99

List price $359.99

JL Audio 12W6v3-D4

• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Mineral-Filled Polypropylene Cone
• Butyl Rubber Surround
• Mount depth: 7.52"
• Sensitivity: 85.4 dB

(82)

$949.99

List price $949.99

Kicker CWRT124 (48CWRT124)

• Peak Power: 1000 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• UV-Treated Polypropylene Cone
• UV-resistant Santoprene Surround
• Mount depth: 3-3/4"
• Sensitivity: 85.5 dB

(18)

$199.96

List price $279.99

NVX VCW122 Version 3 (VCW122v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(95)

$239.99

List price $287.99

Memphis SRX1240

• Peak Power: 500 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 4.92"
• Sensitivity: 85 dB

$79.99

List price $139.95

JBL Stage 122 (JBLSUBST122AM)

• Peak Power: 1000 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 6"
• Sensitivity: 91 dB

$109.95

List price $129.95

NVX YSW122

• Peak Power: 1600 watts
• RMS Power: 800 watts
• Impedance: Dual 2 ohm
• Enhanced Pressed Paper Cone
• High Roll Foam Surround
• Mount depth: 6.5"
• Sensitivity: 85 dB

(3)

$149.99

List price $227.99

JL Audio 12TW3-D4

• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 3.5"
• Sensitivity: 84.11 dB

(20)

$569.99

List price $569.99

Specifications & Details

Subwoofer Specifications

Series

Solo-Baric L7T Series

Subwoofer Size

12"

Peak Power Handling

1200 watts

RMS Power Handling

600 watts

Voice Coil(s)

Dual

Impedance (Per Voice Coil)

2 ohm

Frequency Response

25 - 100 Hz

Sensitivity

86.54 dB

Xmax (millimeters)

10.25 mm

Subwoofer Design

Square

Main Cone Color

Black

Woofer Composition

SoloKon Polypropylene

Woofer Surround

Ribbed Santoprene

Subwoofer Grille

Optional (Accessory required and sold separately)

Re-Cone Kit Available

CTA-2031 Compliant

Yes

Recommended Enclosure Specifications

Recommended Enclosure Type

Ported / Vented
Sealed

Minimum Sealed Box Volume

.55 cubic feet

Maximum Sealed Box Volume

1.25 cubic feet

Minimum Ported Box Volume

1.75 cubic feet

Maximum Ported Box Volume

2.25 cubic feet

Top-Mount Depth (Mounting Depth)

4-1/8"

Cutout Diameter

11-1/16"

Shallow Mount Installation

Yes

T/S Parameters (Electromechanical)

Free-Air Resonance (Fs)

26.3 Hz

Equivalent Compliance (Vas)

88.85 liters

Total Speaker Q Value (Qts)

0.597

Electrical Q Value (Qes)

0.641

Electrical Resistance of Voice Coil (Re)

7.14 ohm

Mechanical Q Value (Qms)

8.7605

What is in the box?

Paperwork

User manual
Brand sticker/decal

WITB: Subwoofers

Subwoofer

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
