Product Highlights


X-Program 2-Channel Class D Car Amplifier • 560W RMS • Variable Bass Boost • Speaker-Level Inputs • Preamp RCA Outputs • Variable Low/High-Pass Filters • 3-Way System Protection Circuitry • Fully Variable Phase Shift

Description


DLS brand icon

Authorized dealer

X-Program by DLS: Born to Play

The DLS X-Program was designed for those that love their music and love to listen at high levels. This specialized line from DLS has everything you need for a high-end, audiophile sound system. With precise engineering, these items still offer complete control of your audio and help you preserve the sound quality. The X-Program from DLS is a Sonic Electronix exclusive and is the perfect blend of performance and price. Just like the rest of the DLS products, the X-Program is designed and engineered by DLS in Sweden.

Born with Extreme Technology

X-Program amplifiers use class D technology that is either all on or all off, so these amplifiers have low heat build-up in idle positions and are nearly 90% efficient. These full range digital class D amplifiers produce incredible power from a compact package so you can fit them almost anywhere, even under your front seat! All X-Program amplifiers are 4-ohm and 2-ohm stable so you can maximize you’re wiring options for speakers or subwoofers. Low-pass and high-pass filters allow you to tune your system just right by feeding your speakers only the frequencies they can handle, which reduces distortion. Phase shift of 180 degrees allows you to keep your subwoofer in phase with your speakers for the best tonal accuracy. Wrapping everything up, the silver finned heat sink is elegant and efficient removing any harmful heat generated from intense musical sessions. X-Program amplifiers were born to play rough, don’t let their compact size fool you.

  • X-Program 2-Channel Class D Car Amplifier
  • RMS Power Rating (14.4V):
    • 4 ohm: 180 watts x 2 chan.
    • 2 ohm: 280 watts x 2 chan.
    • Bridged, 4 ohm: 560 watts x 1 chan.
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Variable Bass Boost (0 to +18 dB bass boost)
  • Soft Start Turn-on
  • 2/1 channel operation
  • Speaker-level inputs with signal sensing for automatic turn-on
  • Preamp RCA outputs to daisy chain multiple amps
  • 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Gold-plated RCA level inputs
  • Gold-plated screw terminals
  • Input sensitivity:
    • Level: 300mV-6V
  • Variable high-pass filter (50-150 Hz)
  • Variable low-pass filter (50-500 Hz)
  • Phase Shift: 0-180°
  • Damping factor: >100
  • Frequency response: 10-35,000 Hz
  • Dimensions: 11-13/16"L x 2"W x 10"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 1-year Manufacturer's warranty

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3

Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
180 watts x 2 channel
RMS Power @ 2 ohms
280 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
560 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
2-Channel
Total RMS Power Output
560 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
15 - 150 Hz
Low-Pass Crossover Frequency
50 - 500 Hz
Signal-to-Noise Ratio
>100 dB
Bass Boost
0 - 18 dB
Remote bass/level controller
No
Fuse Rating
25A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

DLS

Model Number:

X-D25

Weight:

9.01lbs

Internal SKU:

xd25

Internal Product ID:

26100
