Hifonics BX2200D

2200W, Brutus Series Monoblock Class-D Car Amplifier

Hifonics
Shop all Hifonics
Product videos
highlight-star-icon

Brutus Series Monoblock Car Amplifier • 550W x 1 chan @ 4 Ohm • 1100W x 1 chan @ 2 Ohm • MOSFET Power Supply • Aluminum Alloy Heatsink • Bass Remote Included • Adjustable Accu-Cross Crossovers

Learn more about the bx2200d

We apologize

This item has been discontinued


Loading...
Limited time!
DMH-241EX main

Pioneer DMH-241EX

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth and Built-in Alexa

20
-35.00%

$194.99

List price $300.00

Product Highlights


Brutus Series Monoblock Car Amplifier • 550W x 1 chan @ 4 Ohm • 1100W x 1 chan @ 2 Ohm • MOSFET Power Supply • Aluminum Alloy Heatsink • Bass Remote Included • Adjustable Accu-Cross Crossovers

Description


Hifonics brand icon

Authorized dealer

  • Hifonics Brutus Series Monoblock Class-D Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 550 watts x 1 chan.
    • 2 ohm: 1100 watts x 1 chan.
    • 1 ohm: 2200 watts x 1 chan.
  • MOSFET power supply
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Illuminated Hifonics Badge
  • Illuminated Maxxsonics M
  • Bass Remote with blue LED power on and diagnostic indicator included
  • SPC - Simpatico Coil Design
  • Additional MOSFET Output Devices
  • HSMD - Hifonics Surface Mount Design
  • Fully Adjustable Accu-Cross Crossovers
  • Soft Start
  • 4-Way protection (DC, short, thermal, overload)
  • Line Output
  • XLR Mini DIN Sockets for Balanced Line Input
  • Variable Bass EQ: 0-18 dB
  • Variable low-pass filter (35-250 Hz, 24 dB/octave)
  • Sub-Sonic Filter: 15-35 Hz
  • Variable Input Level: 200mV-9V
  • Dimensions: 20-1/2"L x 2-5/8"W x 10-3/8"H
  • 2-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 1-year SonicElectronix.com warranty

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

BMV62W main

Belva BMV62W

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto and Phone Mirroring

28
-66.67%

$89.99

List price $269.99

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

KW-M560BT main

JVC KW-M560BT

6.8" Double-DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

10
Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth (SiriusXM Ready)

43
-16.69%

$149.95

List price $180.00


Best selling similar products

NDA12001 small

NVX NDA12001

• 500 watts x 1 channel @ 4 ohm
• 850 watts x 1 channel @ 2 ohm
• 1200 watts x 1 channel @ 1 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(13)

$169.99

List price $239.99

ATOM 1300.1 PRO small

Deaf Bonce Apocalypse ATOM 1300.1 PRO

• 490 watts x 1 channel @ 4 ohm
• 780 watts x 1 channel @ 2 ohm
• 1300 watts x 1 channel @ 1 ohm
• Total RMS Power: 1300 watts
• Class D 1 ohm Stable Monoblock Amplifier

$199.90

List price $199.90

VAD17001v2 small

NVX VAD17001 v2 (VAD17001v2)

• 800 watts x 1 channel @ 4 ohm
• 1350 watts x 1 channel @ 2 ohm
• 1700 watts x 1 channel @ 1 ohm
• Total RMS Power: 1700 watts
• Class D 1 ohm Stable Monoblock Amplifier

(35)

$259.99

List price $335.99

JD1000/1 small

JL Audio JD1000/1

• 600 watts x 1 channel @ 4 ohm
• 1000 watts x 1 channel @ 2 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable Monoblock Amplifier

(22)

$429.99

List price $429.99

VAD10001v2 small

NVX VAD10001 v2 (VAD10001v2)

• 420 watts x 1 channel @ 4 ohm
• 760 watts x 1 channel @ 2 ohm
• 1000 watts x 1 channel @ 1 ohm
• Total RMS Power: 1000 watts
• Class D 1 ohm Stable Monoblock Amplifier

(37)

$209.99

List price $227.99

VADM1 small

NVX VADM1 v2 (VADM1v2)

• 240 watts x 1 channel @ 4 ohm
• 400 watts x 1 channel @ 2 ohm
• 600 watts x 1 channel @ 1 ohm
• Total RMS Power: 600 watts
• Class D 1 ohm Stable Monoblock Amplifier

(16)

$189.99

List price $239.99

JD500/1 small

JL Audio JD500/1

• 250 watts x 1 channel @ 4 ohm
• 500 watts x 1 channel @ 2 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable Monoblock Amplifier

(12)

$299.99

List price $299.99

R2-1200X1 small

Rockford Fosgate Prime R2 R2-1200X1

• 400 watts x 1 channel @ 4 ohm
• 800 watts x 1 channel @ 2 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(23)

$449.99

List price $449.99

Reference 10001A small

Infinity Reference 10001A (AMPRF10001AAM)

• 600 watts x 1 channel @ 4 ohm
• 1000 watts x 1 channel @ 2 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable Monoblock Amplifier

$499.95

List price $569.95

NDA15001 small

NVX NDA15001

• 670 watts x 1 channel @ 4 ohm
• 1100 watts x 1 channel @ 2 ohm
• 1500 watts x 1 channel @ 1 ohm
• Total RMS Power: 1500 watts
• Class D 1 ohm Stable Monoblock Amplifier

(14)

$199.99

List price $287.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
550 watts x 1 channel
RMS Power @ 2 ohms
1100 watts x 1 channel
RMS Power @ 1 ohm
2200 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
1 - Mono
Total RMS Power Output
2200 watts
Minimum Impedance Unbridged
1 ohm
Minimum Impedance Bridged
Not Bridgeable
THD at Rated RMS Power
0.1%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
35 - 250 Hz
Subsonic Filter
15 - 35 Hz
Signal-to-Noise Ratio
95 dB
Bass Boost
0 - 18 dB
Remote bass/level controller
Yes
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

BX2200D

Weight:

15.00lbs

Internal SKU:

bx2200d

Internal Product ID:

3121

Product and How-to Videos


Customer Ratings & Reviews


Hifonics BX2200D thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
4.7
Usability
4.7

Customer Reviews

Sort by:

Loading...

I love this thing

I have 2 of these, got my second one from Sonic Electronix for cheaper than Hifonics would have sold me one (this was before Sonic Electronix bought them all from Hifonics, I've been looking for another one of these for 2 years to power my 2 Hifonics Olympus 2412. Just one will power both of these behemoths fine, but reducing the stress on the amp will have it last a long time.

By Sean on May 11, 2011

4 found this helpful


Lotta Power

I really like this amplifier. I purchased this amplifer to power a Solo X 12. I like the sleek look of this amplifier. This amp is very powerful and can handle a 1 ohm load. Most amps dont put out near the amount of power that they say they do but this amp puts out a true 2200 watts rms (4400 peak). It is also built very well.
I recently blew my Solo X because of the tremendous power of this amp. I reccomend this amp for anyone that needs alot of power for multiple subwoofers.

By Jordan on February 17, 2006

1 found this helpful


Sick

My buddy had this amp hooked up to 2 dual 4 ohm RE SX 15's. Wow, played a couple bass mekanik tracks, I had to get out, I thought I was gonna be sick. If you want some serious power at a good price, this is that amp for you.

By Ryan on March 7, 2005

1 found this helpful
