Morel Ultimo SC 104

10" Single 4 ohm Ultimo SC Series Subwoofer

Morel
Shop all Morel
Product videos
highlight-star-icon

10" Ultimo SC Series Subwoofer • Single 4 ohm • 2000W Max • 600W RMS • Carbon-Fiber Laminated Paper Cone • Rubber Woofer Surround • Grill Included • Dual Layer, Vented Magnet Motor Structure

Learn more about the ultimosc104

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
REF507CF_2_MET-825601_2 main

2 Infinity REF507CF (INFSPKRF507CFUS) w/ Adapter Plates

390W Peak (130W RMS) 5.25" Reference Series 2-way 3-ohm Component Speaker System with Speaker Adapter Plates

3
-28.32%

$389.88

List price $543.88

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

59
-19.05%

$339.99

List price $420.00

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

214
-9.16%

$109.00

List price $119.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

72
-10.53%

$84.99

List price $94.99

Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

Product Highlights


10" Ultimo SC Series Subwoofer • Single 4 ohm • 2000W Max • 600W RMS • Carbon-Fiber Laminated Paper Cone • Rubber Woofer Surround • Grill Included • Dual Layer, Vented Magnet Motor Structure

Description


True Audiophile Bass

Searching for one of the finest subwoofers out there? Look no further than the Morel Ultimo SC series. The company’s founder, Meir Mordechai set out in 1975 to create the perfect speaker for audio enthusiasts. This mission continues today with the handcrafted and tested Ultimo SC.

The Ultimo SC is a new member of the Ultimo series subwoofers. The Ultimo is more than just the deep, loud bass common to most subwoofers it produces a synergy of tight, clean musical and life-like bass reproduction qualities like no other, delivering the ultimate bass experience.

For audiophiles who expect more, the Ultimo SC uses the latest in speaker technology to produce a perfect sound quality that is second to none. Such as a gigantic 5.1” Hexatech External Voice coil, a hexagonal-shaped aluminum coil wire (2-3 times thicker than standard subwoofers) that is used for accurate music reproduction and for superior durability and power handling. A highly efficient magnet system Double Magnet ferrite Motor that maximizes the magnetic field at over 90% efficiency.

General Features:

  • 10" Single 4 ohm Ultimo SC Series Subwoofer
  • Power Handling:
    • Peak: 3000 watts
    • RMS: 1000 watts
  • Impedance: 4 ohm
  • Carbon-fiber laminated paper cone
  • Rubber woofer surround type
  • Grill included
  • Gigantic 5-1/8” Hexatech External Aluminum voice coil
  • Dual layer, vented magnet motor structure
  • Frequency response: 10 - 900 Hz
  • Resonance Frequency (Fs): 29 Hz
  • Top-mount depth: 5-1/4"
  • Bottom-mount depth: 5-9/16"
  • Sensitivity: 86.5 dB
  • 1-year SonicElectronix.com Warranty

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Morel Ultimo SC 104 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Morel Ultimo SC 104 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Morel Ultimo SC 104 Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 Morel Ultimo SC 104 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

SQW104 small

NVX SQW104

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.23"
• Sensitivity: 83 dB

$249.99

List price $299.99

10W0v3-4 small

JL Audio 10W0v3-4

• RMS Power: 300 watts
• Impedance: Single 4 ohm
• Mount depth: 4.90"
• Sensitivity: 84.07 dB

(89)

$139.99

List price $139.99

10TW3-D4 small

JL Audio 10TW3-D4

• RMS Power: 400 watts
• Polymer/Mica Composite Cone
• Rubber Surround
• Impedance: Dual 4 ohm
• Mount depth: 3.25"
• Sensitivity: 82.10 dB

(29)

$519.99

List price $519.99

Specifications & Details


Subwoofer Specifications
Series
Ultimo SC
Subwoofer Size
10"
Peak Power Handling
3000 watts
RMS Power Handling
1000 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
5-1/4"
Frequency Response
10 - 900 Hz
Sensitivity
86.5 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Carbon Graphite Aramid Fiber
Woofer Surround
Rubber
Magnet Structure
Double Stacked
Subwoofer Grille
Yes - Included
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.459 cubic feet
Maximum Sealed Box Volume
1.059 cubic feet
Minimum Ported Box Volume
0.67 cubic feet
Maximum Ported Box Volume
1.412 cubic feet
Top-Mount Depth (Mounting Depth)
5-1/4"
Cutout Diameter
9-1/8"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

Ultimo SC 10

Weight:

18.00lbs

Internal SKU:

ultimosc104

Internal Product ID:

45427
