RE Audio XX 12D4

1500W 12" XX Series Dual 4 Ohm Subwoofer

RE Audio
Shop all RE Audio
Product videos
highlight-star-icon

• RMS Power: 1500W
• Dual Composite 2-Piece Cone
• Ultra Rubber Surround
• 3" 8-Layer Aluminum Flat Wire Voice Coil
• FEA-Optimized Motor Structure

Learn more about the xx12d4

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

xx12v2d4 thumbnail

RE Audio XX12 V2D4 (XXv2-12D4)

OUR PRICE: $449.99

View item
NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
RVM-35V1 main

MB Quart RVM-35V1

3.5" Touchscreen Multi-Zone Digital Multimedia Receiver with Bluetooth for RV's

-10.38%

$189.99

List price $211.99

RV.R1 main

DS18 RV.R1

Multi-Zone Digital Audio Receiver with Bluetooth Audio Streaming for RV's

55
RVDVD3.0 main

MB Quart RVDVD3.0

Multi-Zone DVD Receiver with Bluetooth for RV's

1
-10.10%

$257.99

List price $286.99

MB Quart RVM2.0

Multi-Zone Digital Audio Receiver with Bluetooth Audio Streaming for RV's

-10.29%

$156.99

List price $174.99

US2-C65A-175 main

SSV Works US2-C65A-175

120W Peak (60W RMS) Cage Mount Speaker Pods with 1.75" Clamp

US2-C65A-200 main

SSV Works US2-C65A-200

120W Peak (60W RMS) Cage Mount Speaker Pods with 2" Clamp

RVM-10V1 main

MB Quart RVM-10V1

10" Touchscreen Multi-Zone Digital Multimedia Receiver with Bluetooth for RV's

-9.09%

$250.00

List price $275.00

220-US2-C65U-150 main

SSV Works US2-C8U-150

Unloaded 8" Cage-Mount Speaker-Pods Enclosure

220-US2-C65U-200 main

SSV Works US2-C8U-200

Unloaded 8" Cage-Mount Speaker-Pods Enclosure

PRO-1.5KP10.4 main

DS18 PRO-1.5KP10.4 (Sold Individually)

3000W Peak (1500W RMS) 10" PANCADÃO Series 4-ohm Mid-bass Speaker

Product Highlights


• RMS Power: 1500W
• Dual Composite 2-Piece Cone
• Ultra Rubber Surround
• 3" 8-Layer Aluminum Flat Wire Voice Coil
• FEA-Optimized Motor Structure

Description


RE Audio brand icon

Authorized dealer

Brutal Power Handling

The XX series are the newest edition to a high-end woofer collection from RE Audio. This woofer borrows a lot the same features as the infamous XXX subwoofer, but for a much more affordable price!

The XX subwoofers use a dual composite 2-piece cone, and a rubber surround. They are housed in a cast aluminum basket and still use the 3” 8-Layer Aluminum Flat Wire Voice Coil that you find the flagship XXX. The XX woofers can be found in 12”, 15”, and 18” sizes, and both dual 2 ohm and dual 4 ohm configurations.

All of the XX subwoofers can handle 1500 watts of RMS power. The XX line-up shares many characteristics with the XXX. In fact, the main feature that separates the XX and the XXX is the magnet size. The XX woofers still use a very large magnet, however. What are you waiting for? Add some insane output to your vehicle today with a XX subwoofer from RE Audio

General Features:

  • 12" Dual 4 Ohm XX Series Subwoofer
  • Power Handling:
    • RMS: 1500 watts
  • Impedance: 4 ohm
  • Dual composite two-piece cone
  • Ultra rubber surround
  • 3" 8-Layer aluminum flat wire voice coil
  • FEA-optimized motor structure
  • Cast aluminum basket with vented magnet system
  • Dual progressive spiders
  • Integrated tinsel leads
  • Cast aluminum gasket
  • Tork-tite terminals
  • Top-mount depth: 10-1/2"
  • Displacement: 0.24 cu. ft.
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • Also found as: RE Audio XX, RE XX, XX12D4, XX12, XX Woofer

Need the Perfect Subwoofer Enclosure?

Check out the RE Audio XX 12D4 Subwoofer Enclosure Guide

Product history:

RE Audio XX12 V2D4 thumbnail
(newest, current model)
RE Audio XX 12D4 thumbnail
(previous model, replaced by RE Audio XX12 V2D4 (XXv2-12D4))

Subwoofer Wiring Guide


Wiring Guide to Wire 1 RE Audio XX 12D4 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 RE Audio XX 12D4 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 RE Audio XX 12D4 Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 RE Audio XX 12D4 Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

Marine Club 12 small

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

VCW124v3 small

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

SQW124 small

NVX SQW124

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.51"
• Sensitivity: 84 dB

$299.99

List price $359.99

CWRT124 small

Kicker CWRT124 (48CWRT124)

• Peak Power: 1000 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• UV-Treated Polypropylene Cone
• UV-resistant Santoprene Surround
• Mount depth: 3-3/4"
• Sensitivity: 85.5 dB

(18)

$199.96

List price $279.99

12W6v3-D4 small

JL Audio 12W6v3-D4

• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Mineral-Filled Polypropylene Cone
• Butyl Rubber Surround
• Mount depth: 7.52"
• Sensitivity: 85.4 dB

(82)

$949.99

List price $949.99

VCW122v3 small

NVX VCW122 Version 3 (VCW122v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(95)

$239.99

List price $287.99

SRX1240 small

Memphis SRX1240

• Peak Power: 500 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 4.92"
• Sensitivity: 85 dB

$79.99

List price $139.95

Stage 122 small

JBL Stage 122 (JBLSUBST122AM)

• Peak Power: 1000 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 6"
• Sensitivity: 91 dB

$109.95

List price $129.95

SW-LCSV212D4 small

Sundown Audio LCS 12 v.2 D4 12" (LCS12V2D4)

• Peak Power: 1000 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• Paper cone
• Foam surround
• Sensitivity: 87.4 dB

(3)

$99.99

List price $209.99

12TW3-D4 small

JL Audio 12TW3-D4

• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 3.5"
• Sensitivity: 84.11 dB

(20)

$569.99

List price $569.99

Specifications & Details


Subwoofer Specifications
Series
XX Series
Subwoofer Size
12"
RMS Power Handling
1500 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
3"
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Dual Composite 2-Piece
Woofer Surround
Rubber
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Top-Mount Depth (Mounting Depth)
10-1/2"
Cutout Diameter
13"
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

XX 12D4

Weight:

64.00lbs

Internal SKU:

xx12d4

Internal Product ID:

68072

Product and How-to Videos


  • RE Audio New Product Line Overview | CES 2015
  • RE Audio XX Subwoofers | New 2013 Car Subwoofer
  • Car Subwoofer Size Buying Guide | What Size of Sub Should I Get?

Customer Ratings & Reviews


RE Audio XX 12D4 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

better than yours

its re audio, what else needs to be said. Regular RE AUDIO 12's are better than your 12's and XX's and XXX's are better than your 18's!!!

By godzilla on December 18, 2013
