Cerwin-Vega H4124D

250W 12" HED Series Dual 4 Ohm Car Subwoofer

Product videos
highlight-star-icon

• Peak Power: 1200W
• RMS Power: 250W
• One Piece Parabolic Cone
• Unimount Gasket Surround
• Mounting Depth: 5.35
• Sensitivity: 87

Learn more about the h4124d

We apologize

This item has been discontinued

Product Highlights


• Peak Power: 1200W
• RMS Power: 250W
• One Piece Parabolic Cone
• Unimount Gasket Surround
• Mounting Depth: 5.35
• Sensitivity: 87

Description


Cerwin-Vega brand icon

Authorized dealer

General Features:

  • 12" Dual 4 Ohm HED Series Car Subwoofer
  • Power Handling:
    • Peak: 1200 watts
    • RMS: 250 watts
  • Impedance: 4 ohm
  • One piece parabolic cone
  • Unimount gasket surround
  • Single stitched rubber surround
  • Proprietary HED basket frame
  • Bumped back plate for maximum excursion
  • Top-mount depth: 5.35"
  • Mounting Diameter: 10.82
  • Sensitivity: 87 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Product history:

Cerwin-Vega H4124D thumbnail
(newest, current model)
Cerwin-Vega HED3124D thumbnail
(previous model, replaced by Cerwin-Vega H4124D)

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Cerwin-Vega H4124D Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Cerwin-Vega H4124D Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Cerwin-Vega H4124D Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Cerwin-Vega H4124D Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

Marine Club 12 small

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

VCW124v3 small

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

SQW124 small

NVX SQW124

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.51"
• Sensitivity: 84 dB

$299.99

List price $359.99

12W6v3-D4 small

JL Audio 12W6v3-D4

• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Mineral-Filled Polypropylene Cone
• Butyl Rubber Surround
• Mount depth: 7.52"
• Sensitivity: 85.4 dB

(25)

$949.99

List price $949.99

VCW122v3 small

NVX VCW122 Version 3 (VCW122v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(94)

$239.99

List price $287.99

SRX1240 small

Memphis SRX1240

• Peak Power: 500 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 4.92"
• Sensitivity: 85 dB

$79.99

List price $139.95

SW-M12D2 small

Sundown Audio M-12 D2 12" (M12D2)

• Peak Power: 4000 watts
• RMS Power: 2000 watts
• Impedance: Dual 2 ohm
• Polypropylene Cone
• High Roll Foam Surround
• Mount depth: 10.88"
• Sensitivity: 80.6 dB

(2)

$599.99

List price $719.99

Stage 122 small

JBL Stage 122 (JBLSUBST122AM)

• Peak Power: 1000 watts
• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 6"
• Sensitivity: 91 dB

$109.95

List price $129.95

YSW122 small

NVX YSW122

• Peak Power: 1600 watts
• RMS Power: 800 watts
• Impedance: Dual 2 ohm
• Enhanced Pressed Paper Cone
• High Roll Foam Surround
• Mount depth: 6.5"
• Sensitivity: 85 dB

(3)

$149.99

List price $227.99

12TW3-D4 small

JL Audio 12TW3-D4

• RMS Power: 400 watts
• Impedance: Dual 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 3.5"
• Sensitivity: 84.11 dB

(20)

$569.99

List price $569.99

Specifications & Details


Subwoofer Specifications
Series
HED Series
Subwoofer Size
12"
Peak Power Handling
1200 watts
RMS Power Handling
250 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Sensitivity
87 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Surround
Rubber
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
1.25 cubic feet
Optimum Ported Box Volume
1.50 cubic feet
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

H4124D

Weight:

12.20lbs

Internal SKU:

h4124d

Internal Product ID:

76889

Product and How-to Videos


Customer Ratings & Reviews


Cerwin-Vega H4124D thumbnail image

5 star
80%
4 star
20%
3 star
0%
2 star
0%
1 star
0%



Durability
4.8
Value
5
Features
4.8
Design
4.6
Usability
4.6

Customer Reviews

Sort by:

Loading...

Best bang for the buck subwoofer.

Solid construction, tight bass with excellent response. I love the sewn ring and lack of dust cover. The terminals are easy to hook speaker wires into. The only negative is the user manual. There was no wiring diagram, so if you don't know how to hook up a dual voice coil sub, you'll have to turn to the internet for instructions.

By MilChad on November 3, 2014

34 found this helpful


Awesome sub!

For the money spent this woofer rocks. I took another competitors woofer out and dropped this one in and it was instantly louder with out doing anything else! Good lows and tight fast response for a 12 inch woofer is hard to do with some of the junk that is out there....No problem for the HED Subwoofer H4124D. Good buy!

By Big B on August 21, 2014

34 found this helpful


Worth having for the price!!

I honestly didn't expect much from these very cost effective subs. I was very very surprised! The look good, they have a nice design, sound GREAT, and durability seems to be very strong too! I have been working on blowing them and nothing yet! I have them running on at 425 rms and they do love it. They do distort at high volume when they are being over powered. But that's kinda normal. Overall, I am definitely a fan. Ive have between 25-30 different pairs of subs. Ive had strokers, mmats, kove audio, splw12, diamond audio, kicker, Rockford, MA Hippos, MTX 8512 and etc. Im no where near and expert but I have experience. Ive owned these since July 2014

By C.Houston on December 5, 2014

27 found this helpful


awsome speakers

Product is good, sounds good, an handles good, ill be lookn to buy more

By nick on June 21, 2015

10 found this helpful


Best bump for your buck...period

I have 2 of these in my living room in custom built triport boxes powered by a crown xls 1000 amp, and they will rattle the pics off the wall of my neighbors house. I put them in my buddies car with about 600w a piece to them in vented boxes and WOW! I cannot believe u can get something that sounds and looks this good for $69. Been pounding them for about a yr now and they sound like day 1.

By Chongdigga on November 1, 2015

4 found this helpful
