Rockford Fosgate Punch P2D212 (09P2D212)

12" Dual 2 ohm Punch Stage 2 Subwoofer

Product videos
highlight-star-icon

12" Dual 2 ohm Punch Stage 2 Subwoofer • Power Handling: Peak: 500 watts / RMS: 250 watts • Molded polypropylene cone • Responsive poly-foam surround • "Venturi-effect" design for maximum cooling of motor structure • Frequency Response: 26 Hz - 250 Hz

Learn more about the 09p2d212

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

p2d212 thumbnail

Rockford Fosgate Punch P2D2-12

OUR PRICE: $169.99

View item

Product Highlights


12" Dual 2 ohm Punch Stage 2 Subwoofer • Power Handling: Peak: 500 watts / RMS: 250 watts • Molded polypropylene cone • Responsive poly-foam surround • "Venturi-effect" design for maximum cooling of motor structure • Frequency Response: 26 Hz - 250 Hz

Description


Rockford Fosgate

Authorized dealer

When it comes to car subwoofers, Rockford Fosgate raised the bar in terms of high quality affordable subwoofers. These Punch Stage 2 subwoofers are the perfect combination of price and deep bass. With a RMS power rating of only 250 watts, these subwoofers are designed for lower wattage amplifiers. However, don’t be fooled by the lower power rating. These efficient woofers are fully capable of producing crisp, clean bass that will shake you to the core. As with all of the other Rockford subwoofers, they have packed patented technology into this sub to enhance the performance of the subwoofer. The Venturi-effect cooling system helps to keep the voice coil cool, while the double stacked ferrite magnet help maintain the power. On the face of the woofer is a polypropylene cone and ABS/Acrylic dustcap. A little further out is the half-roll sealed poly-foam surround that assists with the high excursion of the motor assembly. For those that need a low wattage and high output subwoofer, the Rockford Fosgate Punch P2D212 is the choice subwoofer.

  • 12" Dual 2 ohm Punch Stage 2 Subwoofer
  • Power Handling:
    • Peak: 500 watts
    • RMS: 250 watts
  • Impedance: Dual 2 ohm
  • Molded polypropylene cone
  • Responsive poly-foam surround
  • "Venturi-effect" design for maximum cooling of motor structure
  • Frequency Response: 26 Hz - 250 Hz
  • Sensitivity: 86 dB
  • Top-mount depth: 6-7/16"
  • 62 oz. magnet
  • 1-year SonicElectronix.com warranty

Product history:

Rockford Fosgate P2D2-12 thumbnail
(newest, current model)
Rockford Fosgate 09-P2D212 thumbnail
(previous model, replaced by Rockford Fosgate Punch P2D2-12)
Rockford Fosgate P212D2 thumbnail
(previous model, replaced by Rockford Fosgate Punch P2D212 (09P2D212))
Rockford Fosgate P212S4 thumbnail
(previous model, replaced by Rockford Fosgate Punch P212D2)

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Rockford Fosgate Punch P2D212 (09P2D212) Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Rockford Fosgate Punch P2D212 (09P2D212) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Rockford Fosgate Punch P2D212 (09P2D212) Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 Rockford Fosgate Punch P2D212 (09P2D212) Subwoofers

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Subwoofer Size
12"
Peak Power Handling
500 watts
RMS Power Handling
250 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohms
Voice Coil Material
Voice Coil Diameter
Frequency Response
26 - 250 Hz
Sensitivity
86 dB
Xmax (millimeters)
13-3/16 mm
Subwoofer Design
Round / Circle
Main Cone Color
Dark Gray
Woofer Composition
Polypropylene
Woofer Surround
Poly-Foam
Magnet Structure
Magnet weight
Magnet Type
Subwoofer Grille
No
Re-Cone Kit Available
No
CTA-2031 Compliant
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
.7 cubic feet
Optimum Sealed Box Volume
Maximum Sealed Box Volume
1.80 cubic feet
Minimum Ported Box Volume
1.79 cubic feet
Optimum Ported Box Volume
Maximum Ported Box Volume
1.79 cubic feet
Top-Mount Depth (Mounting Depth)
6-3/8"
Cutout Diameter
11-1/8"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
Equivalent Compliance (Vas)
Total Speaker Q Value (Qts)
Electrical Q Value (Qes)
Electrical Resistance of Voice Coil (Re)
Mechanical Q Value (Qms)
Efficiency Bandwidth Product (EBP)
What is in the box?
Paperwork
WITB: Subwoofers
Other Accessory #1
Other Accessory #2
Other Accessory #3
Other Accessory #4
Other Accessory #5
Other Accessory #6
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

09-P2D212

Weight:

16.00lbs

Internal SKU:

09p2d212

Internal Product ID:

8756
