See all parts that fit your 1997 C3500

American Bass SQ-6

300W Peak (150W RMS) 6.5" Single 8-Ohm High Performance SQ Midrange Driver

highlight-star-icon

• 150W RMS
• 300W Max
• Paper Cone
• Pressed Foam Suspension Surround
• Sealed Stamped Steel Basket
• 1.5" 2-Layer Copper Voice Coil
• 30 oz. Magnet Motor Structure

Learn more about the sq6

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
70-1858-1 main

Metra 70-1858-1 Wiring Harness

Install a New Car Stereo in select 1987-2008 vehicles from GMC, Chevrolet, Pontiac

-35.02%

$12.99

List price $19.99

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

XBAF65 main

NVX XBAF65

Universal 6.5" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

117
-37.15%

$21.99

List price $34.99

GX608C main

JBL GX608C (GX608CAM)

420W Peak (140W RMS) 6.5” GX Series 2 Way 2.3-ohm Component Speaker System

7
Limited time!
46CSC464 main

Kicker CSC46 (46CSC464)

300W Peak (100W RMS) 4x6” CS Series 2 Way Coaxial 4-ohm Speakers

88
-29.45%

$59.96

List price $84.99

C1-650 main

JL Audio C1-650

100W RMS 6.5" C1 Series 2 Way Component 4-ohm Car Speakers

31

Description


American Bass brand icon

Authorized dealer

General Features:

  • 6.5" Single 8-Ohm SQ Series Midrange Driver
  • Power Handling:
    • Peak: 300 watts
  • Recommended power range: 10 - 75 watts RMS
  • Paper Cone
  • Pressed Foam Suspension Surround
  • Sealed Stamped Steel Basket
  • 8 Ohm Impedance
  • 1.5" 2-Layer Copper Voice Coil
  • 30 oz. Magnet Motor Structure
  • Frequency Response: 500 - 5,000Hz
  • Top-mount depth: 2.4"
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • Priced Individually


Loading...

Fits 1988-98 Chevy Silverado/GMC Sierra Single Loaded Subwoofer Box DB 1042 DVC

Under-Seat Loaded Subwoofer Enclosure for select 1988-1999 vehicles from Chevrolet, GMC

15
-18.33%

$195.99

List price $239.98

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
AVH-3500NEX main

Pioneer AVH-3500NEX

7" Single DIN Flip-Out Touchscreen CD/DVD Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

9
-10.75%

$829.99

List price $930.00

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

28
-17.08%

$199.00

List price $240.00

DEH-S7200BHS main

Pioneer DEH-S7200BHS

Single DIN CD Receiver with Bluetooth, HD Radio and SiriusXM Ready

2
-10.72%

$249.99

List price $280.00

XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28

Best selling similar products

GX608C small

JBL GX608C (GX608CAM)

• 210 watts Peak Each, 70 watts RMS Each
• 1-13/16" Edge Driven Dome tweeters
• Polypropylene cone material
• Impedance: 2.3 ohm
• Sensitivity: 92 dB

(7)

$119.95

List price $119.95

PNW-65CS2 small

AudioControl PNW-65CS2

• 125 watts Peak Each, 100 watts RMS Each
• 3/4" rear-dampened Hybrid Silk Dome tweeters
• Rigid Poly Mica cone material
• Impedance: 3 ohm
• Sensitivity: 88.8 dB

(4)

$319.00

List price $339.00

MPK 163.3 small

Hertz MPK163.3

• 300 watts Peak Each, 150 watts RMS Each
• Tetolon Soft Dome tweeters
• Pressed Pulp Fiber cone material
• Impedance: 4 ohm
• Sensitivity: 92 dB

(2)

$999.99

List price $1175.00

Reference 6530CX small

Infinity Reference REF-6530cx (REF6530CXAM)

• 270 watts Peak Each, 90 watts RMS Each
• 3/4" Textile Edge Driven Dome tweeters
• Polypropylene cone material
• Impedance: 3 ohm
• Sensitivity: 93 dB

(14)

$108.99

List price $249.95

T2652-S small

Rockford Fosgate Power T2 T2652-S

• 200 watts Peak Each, 100 watts RMS Each
• 1" Aluminum Dome tweeters with integral suspension
• Carbon Fiber Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 89 dB

(42)

$449.99

List price $449.99

Stadium 62CF small

JBL Stadium 62CF (JBLSPKSD62CFAM)

• 330 watts Peak Each, 110 watts RMS Each
• 3/4" Aluminum Edge Driven Dome Tweeters
• Glass Fiber cone material
• Impedance: 3 ohm
• Sensitivity: 93 dB

(2)

$449.95

List price $479.95

MS1-216C small

MB Quart MS1-216C

• Front Speaker Upgrade for select 2019-2026 Sprinter 3500XD / 2500 / 3500 / 1500
• 100 watts Peak Each, 50 watts RMS Each
• Includes 6.5" component speakers and a 3" center dash speaker
• Impedance: 4 ohm (component)
• Sensitivity: 92 dB (component)

$379.99

List price $399.99

VSP65KIT small

NVX VSP65KIT

• 375 watts Peak Each, 125 watts RMS Each
• 1" Silk Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 88 dB
• Mounting Depth: 2.51"

(84)

$119.99

List price $143.99

XQS65KITv2 small

NVX XQS65KIT Version 2 (XQS65KITv2)

• 300 watts Peak Each, 150 watts RMS Each
• 1-1/8" Silk Dome tweeters
• Carbon Fiber cone material
• Impedance: 4 ohm
• Sensitivity: 93 dB

(9)

$399.99

List price $499.99

C2-650 small

JL Audio C2-650

• 60 watts RMS Each
• 3/4" Silk Dome tweeters
• Mica Injected Polypropylene - MIPP cone material
• Impedance: 4 ohm
• Sensitivity: 91 dB

(21)

$254.99

List price $329.99

Specifications & Details


Speaker Specifications
Series
SQ Series
Priced Per
Each Speaker
Number of Speakers
1
Speaker Size
6-1/2"
Design
Mid-range
Woofer Composition
Paper
Woofer Surround
Foam
Peak Power Handling
300 watts
Sensitivity
101 dB
Frequency Response
500 - 5000 Hz
Impedance (Per Voice Coil)
8 ohm
Shallow Mount Installation
Yes
Top-Mount Depth (Mounting Depth)
2.4"
Cutout Dimensions
6.56"
General specifications
Speaker Grilles
Yes
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

SQ-6

Weight:

4.40lbs

Internal SKU:

sq6

Internal Product ID:

90822
