JL Audio MicroSub+ ACP112LG-TW1

400 Watt RMS Single 12" 12TW1-0.25 Subwoofer Loaded in a Slot-Ported MicroSub Enclosure

JL Audio
Shop all JL Audio
Only 2 Left!
Product videos
highlight-star-icon

• Built-in DCD™Class D amplifier
• Automatic turn-on capable
• CNC-Cut High-Grade MDF
• Steel mesh grille mounted with driver
• Wrapped with Automotive-grade vehicle carpet
• Enclosure Dimensions: 9.25" D x 23.75" W x 15.75" H

Learn more about the acp112lgtw1
Thanks , You Pay:

$749.99

 with warranty

Heads up

We confirm fitment and offer accessories for speakers. Please set your vehicle first if you would like to purchase more than one acp112lgtw1.

Set your vehicle or Return to product page
shipping truck icon Free shipping in USA. Provide zip for delivery date.
Dollar Icon
VIP Product Get $75.00 in rewards to spend later
Quantity
In Stock. Only 2 Left!
Brand new

Buy it now

Open box icon Open box $637.49

Acima Logo

No Credit Option

Flexible Lease Payments

Early Purchase Options

Quick Approval Decision

Allstate logo

Keep your product protected longer! Extend the warranty after the manufacturer warranty expires.

  • Mechanical, electrical and product failure covered! 100% parts and labor covered. (Coverage starts after Mfr. warranty)
  • Easy online management! Zero hassle claim service, available 24/7
Swoosh Icon Icon of Swoosh

For over 23 years, we've been your X-Factor – the team dedicated to having the biggest impact on your shopping experience!

Award winning icon
Award-Winning Service
Shipping icon
FREE Shipping Orders $49+
60 days return policy icon
60-Day Easy Returns
lowest price guarantee icon
Guaranteed Lowest Price
inHouseExpert
In-House Experts

Product Highlights


• Built-in DCD™Class D amplifier
• Automatic turn-on capable
• CNC-Cut High-Grade MDF
• Steel mesh grille mounted with driver
• Wrapped with Automotive-grade vehicle carpet
• Enclosure Dimensions: 9.25" D x 23.75" W x 15.75" H

Description


JL Audio brand icon

Authorized dealer


JL Audio MicroSub+ Amplified Subwoofer Systems

JL Audio MicroSub+ bass solutions feature thin-wall construction with extensive internal bracing that optimizes the proprietary loaded subwoofer, and maximizes the enclosure's internal air space. In order to achieve its outstanding output and low frequency response, the MicroSub+ is offered as a Ported Enclosure. With a flared design at the entry and exit, the port wraps around two walls to produce the necessary low tuning frequency that ensures excellent low end extension and smoothness. The Microsub+ enclosure is pre-loaded with a JL Audio TW1 driver, that is specifically chosen for its astonishing bass output when in an extremely small air space.

All MicroSub enclosures are hand built in JL Audio's Florida factory using CNC-Cut High Grade MDF materials, and wrapped in top-quality automotive carpet, to ensure that the system meets the standards that we all have become accustomed to with JL Audio products. The systems arrive to you wired, loaded and ready to connect and also include a steel mesh grille to protect the subwoofer.

JL Audio MicroSub+™ Amplified Subwoofer Systems
JL Audio DCD™ Amplifier Technology

DCD Amplifier Technology

JL Audio's Direct Conversion Class-D Technology (DCD™) is purpose-engineered to be the most efficient subwoofer amplifier on the market while delivering extraordinary output with minimal current draw and heat. DCD amplifiers do away with the losses associated with a traditional "switching power supply", allowing the amplifier to achieve total power efficiencies in the 91 - 94% range. What this means to you is very little heat, ultra-compact size and enough power to fill in the low end of any modest car audio setup. Along with the specifically engineered, low-impedance TW1 driver the system extracts astonishing overall output with unprecedented efficiency.

JL Audio TW1 (Thin-Line) Driver

JL Audio TW1 (Thin-Line) Driver

The TW1 subwoofers offer an unparalleled combination of superb performance and extremely small enclosure requirements, making them an outstanding choice for the MicroSub+ systems. The driver achieves this level of shallow-depth plus performance by compressing the architecture of the TW1 using a "concentric tube" structure that supports the oversized voice coil and the suspension attachments. This permits placing the large motor structure much further forward in the speaker than with conventional designs, while maintaining excellent linear excursion capability and mechanical stability. The enclosure's slot-ported design and precise tuning of the TW1 make for the Perfect match.




General Features:









  • Single 12" Vented Subwoofer Enclosure with Built-In Amplifier
  • Power Output:
    • RMS: 400 Watts Total
  • Preloaded with single 12" TW1 Series Subwoofer Driver - 12TW1-0.25
  • Built-in DCD Class D amplifier
  • Vented enclosure with carpet finish
  • Authorized Internet Dealer
  • 2 Year Manufacturer's Warranty

Subwoofer Features:

  • Injection molded, mica-filled polypropylene cone
  • Rubber surround
  • Cast alloy frame
  • Long linear excursion capability (0.40 in / 10 mm, one-way)
  • DMA-optimized motor design
  • Patented "concentric tube" architecture
  • Patented "floating cone attach method" technology
  • Steel mesh grille included

Amplifier Features:

  • Class D amplifier
  • Input Voltage Range @ RCA Inputs: 70 mV - 1.40 V RMS
  • Input Voltage Range @ High-Level Inputs: 280 mV - 5.4 V RMS
  • 12 dB per octave filter slope
  • Low-pass filter: 50 - 200 Hz
  • Selectable output polarity (i.e. Phase): 0 / 180°
  • Selectable turn-on modes: Sig / DC / REM
  • Automatic turn-on (via signal sensing or DC offset sensing)
  • High level speaker input, w/ molex connection harness
  • Optional bass remote available, sold separately: JL Audio RBC-1
  • Fuse Rating: 30A x 1
  • 8 gauge OFC power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.

Enclosure Features:

  • V-Groove MDF Construction
  • Flared port entry and exit
  • Automotive-grade vehicle carpet
  • CNC-Cut High-Grade MDF
  • Silver "JL AUDIO Built In USA" embroidery on front baffle
  • Steel mesh grille mounted with driver
  • Enclosure Dimensions: 9.25" D x 23.75" W x 15.75" H

Check out the JL Audio ACP112LG-TW1 Owner's Manual

Specifications & Details


Subwoofer Amplifier Power Specifications
RMS Power @ 2 ohms
400 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
1 - Mono
Maximum Input Gauge Size
8 AWG
Speaker Level Inputs
Yes - with included adapter
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
50 - 200 Hz
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
30A x 1
Subwoofer Specifications
Subwoofer Size
12"
Woofer Surround
Rubber
Woofer Composition
Injection Molded Polypropylene - IMPP
Voice Coil(s)
Single
Impedance (Per Voice Coil)
0.25
Frequency Response
26 - 200 Hz
Subwoofer Design
Round / Circle
Enclosure Specifications
Box Type
Ported
Number of Subwoofers
1
Box Style/Shape
Square/Rectangle
Height
15.75"
Width
23.75"
Depth
9.25"
Number of Terminals
1
Terminal Type
Binding posts
Box Exterior Color
Black
Box Finish
Carpet
Warranty and Return Policy
Parts Warranty Duration
2 years
Labor Warranty Duration
2 years
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

ACP112LG-TW1

Weight:

45.30lbs

Internal SKU:

acp112lgtw1

Internal Product ID:

93406
