Cadence CVL64MBX

500W 6.5" CVL Series Midbass Speaker Driver

Cadence
Shop all Cadence
highlight-star-icon

• Peak Power: 500W
• RMS Power: 250W
• 2" High Temperature CCAR Voice Coil
• Mounting Depth: 3.42"
• Kevlar Reinforced Black Paper Cone & Treated Cloth, Accordion Style Surround

Learn more about the cvl64mbx

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
70-1858-1 main

Metra 70-1858-1 Wiring Harness

Install a New Car Stereo in select 1987-2008 vehicles from GMC, Chevrolet, Pontiac

-35.02%

$12.99

List price $19.99

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

254
-33.36%

$79.96

List price $119.99

XBAF65 main

NVX XBAF65

Universal 6.5" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

117
-37.15%

$21.99

List price $34.99

GX608C main

JBL GX608C (GX608CAM)

420W Peak (140W RMS) 6.5” GX Series 2 Way 2.3-ohm Component Speaker System

7
Limited time!
46CSC464 main

Kicker CSC46 (46CSC464)

300W Peak (100W RMS) 4x6” CS Series 2 Way Coaxial 4-ohm Speakers

88
-29.45%

$59.96

List price $84.99

C1-650 main

JL Audio C1-650

100W RMS 6.5" C1 Series 2 Way Component 4-ohm Car Speakers

31

Description


Cadence brand icon

Authorized dealer

General Features:

  • 6.5" CVL Series Midbass Speaker Driver
  • Power Handling:
    • Peak: 500watts
    • RMS: 250watts
  • Kevlar Reinforced Black Paper Cone
  • Treated Cloth, Accordion Style Surround
  • Impedance: 4 Ohm
  • Oversize 2" High Temperature CCAR Voice Coil
  • 70oz Magnet Motor Structure
  • Top-mount depth: 3.42"
  • Cutout Dimensions: 5.75"
  • Frequency Response: 90- 9,000Hz
  • Sensitivity: 99dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

TS Parameters

  • FMS: 147.9 Hz
  • QMS: 5.81
  • QES: 0.88
  • QTS: 0.76
  • RES: 12.5 Ohm
  • RMS: 1.9 kg/s
  • CMS: 0.10 mm/N
  • MMS: 11.8 gr
  • NREF: 0.86%
  • BL: 6.1
  • SPL: 99 db
  • VAS: 2.4 l
  • RE: 3.0 Ohm
  • RP: 8.1 Ohm
  • LP: 3.0 mH
  • CP: 869.0 uF
  • LE: 0.3 mH

For more information on the Thiele and Small Parameters, visit our T/S Parameters Article
