Name: Memphis 16-PR4.50 R/B
Brand: Memphis
SKU: LS-16pr450-RB
Price: 109.99 USD
Availability: Discontinued
Rating: 5.0000 (1 reviews)

Shop all Memphis

by Memphis

About
Specs & Details
Product Videos
Reviews
Add-ons
Related Searches

Product videos

Product highlights

Power Reference Series 4-Channel Class AB Car Amplifier • 50W x 4 chan. @ 4 ohm • 70W x 4 chan. @ 2 ohm • 200W Max x 4 chan. Max • LED power and protection indicators • Bridgeable operation

Learn more about the LS-16pr450-RB

Product Highlights

Power Reference Series 4-Channel Class AB Car Amplifier • 50W x 4 chan. @ 4 ohm • 70W x 4 chan. @ 2 ohm • 200W Max x 4 chan. Max • LED power and protection indicators • Bridgeable operation

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

Power Reference Series 4-Channel Class AB Car Amplifier
RMS Power Rating:

4 ohm: 50 watts x 4 chan.
2 ohm: 70 watts x 4 chan.
Bridged, 4 ohm: 140 watts x 2 chan.

Max power output: 200 watts x 4 chan.
Remote bass level input (remote level control sold separately)
LED power and protection indicators
Tuned Bass EQ (0-18 dB bass boost at 45 Hz)
Speaker-level inputs
Preamp RCA outputs
Internal cooling-fan
RCA level inputs
Variable high-pass filter (40-400 Hz, 24 dB/octave)
Variable low-pass filter (40-400 Hz, 24 dB/octave)
Frequency response: 20-20000 Hz
Dimensions: 15.3"L x 10"W x 2.3"H
1-year SonicElectronix.com warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

50 watts x 4 channel

RMS Power @ 2 ohms

70 watts x 4 channel

RMS Power @ 1 ohm

Not Stable

Bridged RMS Power

140 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total Peak Power Output

800 watts

Total RMS Power Output

280 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Yes

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

40 - 400 Hz

Low-Pass Crossover Frequency

40 - 400 Hz

Bass Boost

0 - 18 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Memphis 16-PRRG

Fuse Rating

30A x 2

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Sonic Electronix

Customer Ratings & Reviews

Overall rating distribution

5 star		100%
4 star		0%
3 star		0%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		5
Value		5
Features		5
Design		5
Usability		5

Customer Reviews

Sort by:

i got this at a great price

wow this amp shocked me it rocked the hell out of my truck, i have one 12 sub jl and two memphis 6 1/2 and this amp was pushing everything and it sounds great all my friends want the same amp, wow wow that all i have to say and thanks

By louie_76_99@yahoo.com on January 26, 2010

4 found this helpful
