Name: JL Audio MX500/1 - Open Box, Good Condition (Used)
Brand: JL Audio
SKU: LS-mx5001-OBC5
Price: 359.99 USD
Availability: Discontinued

by JL Audio

About
Specs & Details
Reviews
Add-ons
Related Searches

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 1 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 2 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 3 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 4 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 5 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 6 — JL Audio MX500/1 - Open Box, Good Condition (Used)

JL Audio MX500/1 - Open Box, Good Condition (Used) Image 7 — JL Audio MX500/1 - Open Box, Good Condition (Used)

Product highlights

• 300 Watts RMS x 1 @ 4 ohm
• 400 Watts RMS x 1 @ 3 ohm
• 500 Watts RMS x 1 @ 2 ohm
• Total Peak Power: 1000 Watts
• CEA-2006 Compliant/Preamp Outputs/LPF
• Frequency Response: 20 - 12,000 Hz
• Dimensions: 9.33"W x 4.50"D x 1.77"H

Learn more about the LS-mx5001-OBC5

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Good Condition:
A Good Open Box used product shows wear from consistent use, but it remains in good condition and works perfectly. It may be marked, have identifying markings on it, or show other signs of previous use or installation. Original packaging, paperwork or protective wrapping may be missing or not included in its entirety. Warranty details are included in the item description or comments.

General Features:

JL Audio MX300/1 Weatherproof Amplifier
Class-D Monoblock Amplifier
RMS Power Rating:

4 ohm: 300 watts x 1 chan.
3 ohm: 400 watts x 1 chan.
2 ohm: 500 watts x 1 chan.
1 ohm: ------------N/A------------

Total RMS power output: 500 watts
CEA-2006 Compliant Amplifier
Pulse Width Modulated MOSFET power supply
LED power (green) and protect (red) indicators
Soft start turn-on
IPX6 water resistant rating
Mono channel operation
Black powder coat finish
3-way protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heat-sink for extreme heat dissipation
Input sensitivity:

Low level: 250mV - 4V
High level: 750mV - 15V

Frequency Response: 20 - 12,000 Hz
Total Harmonic Distortion (THD): <1%
Signal to Noise Ration: >97 dB
Variable high-pass filter: 20 - 40 Hz, 12 dB/octave
Variable low-pass filter: 20 - 40 Hz, 12 dB/octave
Fuse Rating: 50 A x 1
8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
Dimensions: 9.33"W x 4.50"D x 1.77"H
Remote bass knob sold separately - M-RBC-1.
Authorized Internet Dealer
1-year Manufacturer's Warranty

Check out the MX500/1 Owner's Manual

Specifications & Details

Power Specifications - Subwoofer Channel

RMS Power @ 4 ohms

300 watts x 1 channel

RMS Power @ 2 ohms

500 watts x 1 channel

Amplifier Specifications

Series

MX Series

Amplifier Class

Number of Channels

1 - Mono

Total RMS Power Output

500 watts

Maximum Input Gauge Size

8 AWG

THD at Rated RMS Power

<1%

Built-in Crossover

Low-Pass (LP)

Signal-to-Noise Ratio

>70 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

JL Audio M-RBC-1

Fuse Rating

50A x 1

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
