Kenwood X301-4 Open Box Complete

600W Max X-Series Bridgeable 4-channel Amplifier

Kenwood
Shop all Kenwood
highlight-star-icon

• Item Condition: Open Box Complete
• 50 Watts RMS x 4 @ 4 ohm
• 75 Watts RMS x 4 @ 2 ohm
• Total Peak Power: 600 Watts
• CEA-2006 Compliant
• Variable low-pass and high-pass filter: 50 - 200Hz, 24 dB/octave
• Variable Bass Boost: 0 to +18 dB bass boost at 40Hz
• Speaker-level (high-level) inputs

Learn more about the ls-x3014-obc6

We apologize

This item has been discontinued

Description


Kenwood brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Very Good Condition:
A Very Good Open Box used product represents a well-cared-for product that has seen only brief installation and/or limited use, but remains in great condition. The item is complete, unmarked, and undamaged, but may show some limited signs of wear. Original packaging, paperwork or protective wrapping may be missing or slightly damaged from the item being opened. Product works perfectly. Warranty details are included in the item description or comments.

General Features:

  • Kenwood eXcelon X-Series X301-4
  • Class-D 2-Ohm Stable Monoblock Amplifier
  • RMS Power Rating:
    • 4 ohm: 50 watts x 4 chan.
    • 2 ohm: 75 watts x 4 chan.
    • Bridged @ 4 ohm: 150 watts x 2 chan.
  • Total power output: 600 watts
  • CEA-2006 Compliant Amplifier
  • Pulse Width Modulated MOSFET power supply
  • 4/3/2 channel operation
  • Speaker-level (high-level) inputs with signal sensing turn on
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Input sensitivity:
    • Low level: 4V-12V
    • High level: 0.2V-5V
  • Frequency Response: 20 - 50kHz
  • Total Harmonic Distortion (THD): <1.0%
  • Signal to Noise Ration: 80dB
  • Variable low-pass filter: 50 - 200Hz, 12 dB/octave
  • Variable high-pass filter: 50 - 200Hz, 12 dB/octave
  • Variable Bass Boost: 0 to +18 dB bass boost at 40Hz
  • 4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
  • Dimensions: 6 11/16"W x 7 3/8"L x 2 3/16"H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
Check out the X301-4 Owner's Manual

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
50 watts x 4 channel
RMS Power @ 2 ohms
75 watts x 4 channel
Bridged RMS Power
150 watts x 2 channel
Power Specifications - Full Range Channels
Peak Power @ 4 ohms
100 watts x 4 channel
Peak Power @ 2 ohms
150 watts x 4 channel
Bridged Peak/Max Power
300 watts x 2 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
4-Channel
Total Peak Power Output
600 watts
Total RMS Power Output
300 watts
THD at Rated RMS Power
<1.0%
Speaker Level Inputs
Yes
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
50 - 200 Hz
Low-Pass Crossover Frequency
50 - 200 Hz
Signal-to-Noise Ratio
80 dB
Bass Boost
0 - 18 dB
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

X301-4 Open Box Complete

Weight:

2.87lbs

Internal SKU:

ls-x3014-obc6

Internal Product ID:

132675
