Name: JL Audio 1000/1 R/B
Brand: JL Audio
SKU: LS-jl10001-RB
Price: 499.99 USD
Availability: Discontinued
Rating: 5.0000 (1 reviews)

Shop all JL Audio

by JL Audio

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

Product videos

Product highlights

1000 watts, MonoBlock Class D Amplifier • Differential-Balanced Inputs • Fully Variable On-Board Crossover • 2-Channel Preamp Outputs • Fully Variable Infrasonic Filter • Output Polarity Reversal Switch

Learn more about the LS-jl10001-RB

Product Highlights

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

General Features:

1 pair of Differential-Balanced Inputs
Fully variable on-board crossover: (40Hz - 200Hz), selectable-slope LP (12 or 24 dB per octave)
2-channel Preamp Outputs: independent active filter, parallel with amp filter or full-range
Bass EQ that is parametric with variable bass boost up to 15dB and you can use a Remote Bass Control (optional RBC-1)
Fully variable Infrasonic Filter: 24dB/octave from 15-60Hz
Output Polarity Reversal switch allows instant output polarity reversal
Dual mono speaker output connections that accepts up to 8 gauge wire
12 volt and Ground connections accept 4 gauge wire or 2 gauge or 1/0 gauge

Specifications:

Rated Power: 1000 watts RMS at 1.5 ohm - 4 ohm (at 11V-14.5V)
THD at RMS Power: <0.05% @ 4 ohm
S/N Ratio: >95dB below rated power
Frequency Response: 5Hz - 500 Hz
Damping Factor: >500 at 4 ohm /50Hz
Input Range switchable from 200mV-2V RMS
to 800mV-8V RMS
Dimensions: 19.7"L x 9.25"W x 2.36"H

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

1000 watts x 1 channel

RMS Power @ 2 ohms

1000 watts x 1 channel

RMS Power @ 1 ohm

(at 1.5 ohms) 1000 watts x 1 channel

Amplifier Specifications

Amplifier Class

Number of Channels

1 - Mono

Total RMS Power Output

1000 watts

Maximum Input Gauge Size

2 AWG

Minimum Impedance Unbridged

1.5 ohm

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

40 - 200 Hz

Low-Pass Crossover Frequency

40 - 200 Hz

Signal-to-Noise Ratio

95 dB

Bass Boost

0 - 15 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

JL Audio RBC-1

Fuse Rating

100A x 1

Customer Ratings & Reviews

Overall rating distribution

5 star		100%
4 star		0%
3 star		0%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		5
Value		5
Features		5
Design		5
Usability		4

Customer Reviews

Sort by:

Great amp from a Great company

One of my favorite amps that I've ever seen. Clean power that can push any subwoofer to its fullest potential. I've never heard a bad comment on this amp. It may be a little pricey but every dollar spent on this amp is well worth it.

By Ryan on March 16, 2006
