Alphasonik PMA1200DA R/B

Factory Refurbished Class D Monoblock Amplifier

Alphasonik
Shop all Alphasonik
Product videos
highlight-star-icon

Class D Mono-Block Amplifier • 2470W x 1 @ 1 • Protective Acrylic Cover • RCA Outputs • Variable Crossovers

Learn more about the LS-pma1200da-RB

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Product Highlights


Class D Mono-Block Amplifier • 2470W x 1 @ 1 • Protective Acrylic Cover • RCA Outputs • Variable Crossovers

Description


Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

  • 1-Channel Class D Mono-Block Power Amplifier
  • RMS power Rating:
    • 1200 watts x 1 @ 4 ohm mono
    • 2000 Watts x 1 @ 2 ohm Mono
    • 2470 Watts x 1 @ 1 ohm Mono
  • Bridgeable with Second Identical Model
  • Heavy Duty One-piece Extruded Aluminum Heat Sink
  • Variable Low Pass Filter: 50Hz~150Hz, 24dB/Octave
  • Variable Subsonic Filter: 15Hz~40Hz, 24dB/Octave
  • Variable Bass Boost at 45Hz: 0~+ 18dB
  • Variable Phase Shift: 0~180°
  • Input Impedance: 10K ohm
  • Variable Input Sensitivity: 300mV ~ 8V
  • Beveled Clear Acrylic Protective Cover
  • Tiffany-Style Input and Output RCA Jacks
  • Parallel Line-out RCA Jacks
  • Removable Covers Conceal Control and Terminal Panels
  • MOSFET High Speed Switching Power Supply
  • Milspec Double-Sided Glass Epoxy Circuit Board with Through-hole Plating
  • Heavy 4 oz. Pure Copper PC Traces at All Preamp and Amplification Stages
  • Internally Mounted Fan-Cooled Power Supply
  • Solid Brass Nickel-plated Terminal Blocks (4-gauge Power, 8-gauge Speaker)
  • Terminal Blocks are Compression Type and Soldered Directly to the PCB
  • 4-Way Protection Circuitry: Thermal, Short Circuit, Overload and DC Offset
  • Dimensions: 20-7/8” L x 9-1/8” W x 2 1/2” H
  • 1-year SonicElectronix.com warranty
Note: Bass remote and voltage meter not included

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
1200 watts x 1 channel
RMS Power @ 2 ohms
2000 watts x 1 channel
RMS Power @ 1 ohm
2470 watts x 1 channel
Bridged RMS Power
Not Bridgeable
Amplifier Specifications
Amplifier Class
D
Number of Channels
1 - Mono
Total RMS Power Output
2470 watts
Minimum Impedance Unbridged
1 ohm
Minimum Impedance Bridged
Not Bridgeable
THD at Rated RMS Power
0.08%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
50 - 150 Hz
Subsonic Filter
15 - 40 Hz
Signal-to-Noise Ratio
100 dB
Bass Boost
0 - 18 dB
Remote bass/level controller
No

Item Details


Manufacturer:

Model Number:

PMA1200DA-RB

Weight:

24.00lbs

Internal SKU:

LS-pma1200da-RB

Internal Product ID:

12363
