JBL W10GTi-MkII

600W 10" GTi Series Dual 6 ohm Subwoofer

JBL
Shop all JBL
Product videos
highlight-star-icon

• 3000W Peak
• 600W RMS
• Differential Drive Design (DDD) Motor
• Impedance: Dual 6 ohm
• Kevlar-impregnated paper woofer cone
• NBR (Nitrile Butadiene Rubber) surround

Learn more about the w10gtimkii

We apologize

This item has been discontinued


Loading...
MVH-S522BS main

Pioneer MVH-S522BS

Single DIN Digital Media Bluetooth Receiver with Bluetooth and SiriusXM Ready

4
-10.53%

$169.99

List price $190.00

Limited time!
Kappa 693M main

Infinity Kappa 693M (INFSPKKA693MAM)

720W Peak (240W RMS) 6x9” Kappa Series 3 Way Coaxial 3-ohm Speakers

6
-31.43%

$239.95

List price $349.95

REF-5032CFXAM main

Infinity Reference 5032cfx (REF-5032CFXAM)

270W Peak (90W RMS) 5.25" Reference Series 2 Way Coaxial 3-ohm Speakers

-42.32%

$74.99

List price $130.00

Product Highlights


• 3000W Peak
• 600W RMS
• Differential Drive Design (DDD) Motor
• Impedance: Dual 6 ohm
• Kevlar-impregnated paper woofer cone
• NBR (Nitrile Butadiene Rubber) surround

Description


JBL brand icon

Authorized dealer

Ultimate Woofer

If you are in search of the ultimate Woofer, this is it! JBL has leveraged all engineering resources to develop quite simply the best Subwoofer money can buy. Symmetrical Field Geometry ensures linear Cone travel and low Distortion at virtually any level by creating a uniform magnetic Field around the Coil. Die-Cast Basket

General Features:

  • 10" Dual 6 ohm GTi Series Subwoofer with Differential Drive Design (DDD) Motor
  • Power Handling:
    • Peak: 3000 watts
    • RMS: 600 watts
  • Impedance: Dual 6 ohm (3 ohm parallel/12 ohm series)
  • Kevlar-impregnated paper woofer cone
  • NBR (Nitrile Butadiene Rubber) surround
  • Die-cast vented basket
  • Differential Drive Design (DDD) motor: The JBL Differential Drive Design is an important advancement in subwoofer motor technology. This design enables each GTi subwoofer to use a pair of smaller 3"-diameter voice coils. This dual-coil configuration provides significantly higher power handling through increased surface area, and maintains the low-moving mass not possible with larger coils.
  • Progressive spider
  • Symmetrical field geometry ensures linear cone travel and low distortion at virtually any level
  • Vented pole piece
  • 3" Dual 6 ohm voice coil
  • Frequency response: 16-1000 Hz
  • Sensitivity: 92 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Loading...
82-6901,DB6502 main

Polk Audio DB6502 DB+ 6.5" 600 Watt Car Speakers with Free 6" x 9" Adapters

600W Peak (200W RMS) 6.5" DB+ Series 2-way Component Speakers with 6" x 9" Speaker Adapters

47
-9.29%

$211.34

List price $232.98

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

SXE-6926S main

Alpine SXE-6926S

280W Peak (90W RMS) 6x9” SXE Series 2-way 4-ohm Coaxial Speakers

13
-20.84%

$56.99

List price $71.99


Best selling similar products

SQW104 small

NVX SQW104

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.23"
• Sensitivity: 83 dB

$249.99

List price $299.99

10TW3-D4 small

JL Audio 10TW3-D4

• RMS Power: 400 watts
• Polymer/Mica Composite Cone
• Rubber Surround
• Impedance: Dual 4 ohm
• Mount depth: 3.25"
• Sensitivity: 82.10 dB

(29)

$519.99

List price $519.99

HS102D small

Cerwin Vega HS102D

• Peak Power: 800 watts
• RMS Power: 200 watts
• Impedance: Dual 2 ohm
• Polypropylene Cone
• Treated Foam Surround
• Mount depth: 3.54"
• Sensitivity: 83.1 dB

(4)

$99.99

List price $119.99

Specifications & Details


Subwoofer Specifications
Series
GTi Series
Subwoofer Size
10"
Peak Power Handling
3000 watts
RMS Power Handling
600 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
6 ohm
Voice Coil Diameter
3"
Frequency Response
16 - 1000 Hz
Sensitivity
92 dB
Xmax (millimeters)
17.78 mm
Subwoofer Design
Round / Circle
Main Cone Color
Silver
Woofer Composition
Kevlar Impregnated Paper
Woofer Surround
Nitrile Butadiene Rubber NBR
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.75 cubic feet
Maximum Sealed Box Volume
0.75 cubic feet
Minimum Ported Box Volume
1.75 cubic feet
Maximum Ported Box Volume
1.75 cubic feet
Top-Mount Depth (Mounting Depth)
9-1/8"
Cutout Diameter
10-1/2"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
29.11 Hz
Equivalent Compliance (Vas)
35.48 liters
Total Speaker Q Value (Qts)
0.52
Electrical Q Value (Qes)
0.56
Electrical Resistance of Voice Coil (Re)
3.80 ohm
Mechanical Q Value (Qms)
7.67
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

JBL

Model Number:

W10GTi-MkII

Weight:

33.50lbs

Internal SKU:

w10gtimkii

Internal Product ID:

13868

Product and How-to Videos


  • Harman International: The Pursuit of Great Sound
  • Car Subwoofer Size Buying Guide | What Size of Sub Should I Get?

Customer Ratings & Reviews


JBL W10GTi-MkII thumbnail image

5 star
75%
4 star
0%
3 star
0%
2 star
0%
1 star
25%



Durability
4
Value
4.3
Features
4
Design
4
Usability
5

Customer Reviews

Sort by:

Loading...

Awsome

I have 6 of these in my range rover sport in a sealed enclosure on a kicker warhorse amp @ 2ohms with 3 sets of GTI components. With the JBL sound processor. Gets very loud and crystal clear. You will love it!

By Chuck berry on July 19, 2012

8 found this helpful


Dr. Deep

I have (1) one of these. Yes, just one of them in a 2.75 cubic ft. PNR ported enclosure, running it is a Phoenix Gold MS 2125. Hits deep like 15's, with the Audio Control Epicenter. Its all about the enclosure, a damn good sub like this, and an American made old school amp. So just build smart and lets take it back to basics for car audio in the year 2010.

By AudioGuru on February 11, 2010

7 found this helpful


another one bites the dust

I blew this sub up 2 times it sounds good when it works tell it blows, wound get another one, i would go alpine type X hits hard and gives clean sound...
have to love sonice tho #1 prices and tech

By andy on July 13, 2012

6 found this helpful


True SQ sub JBL 10 MKii

I have always wanted this sub from when it first came out years ago, if you are after a real SQ sub , this is the one. I have it wired to 3ohm and feeding it 1000rms all day, even tho its rated at 600rms, it is more than capable. If you are going to buy this sub , please do it justice and sound deaden the inside of the box and use marine ply 18-25mm, sealed. you will not regret buying the MKii range of subs, it goes hard and plays very accurately.
oh i and play D & B , Tech death metal every day for at least 3 hours, JBL = WIN!

By Adam on August 28, 2011

5 found this helpful
