Name: Alpine BBX-F1200 (open box complete)
Brand: Alpine
SKU: ls-bbxf1200-obc8
Price: 143.95 USD
Availability: Discontinued
Rating: 4.6000 (10 reviews)

Shop all Alpine

by Alpine

About
Specs & Details
Reviews
Add-ons
Recently Viewed
Related Searches

Product highlights

• 50 Watts RMS x 4 @ 4 ohm
• 70 Watts RMS x 4 @ 2 ohm
• 130 Watts RMS x 2 @ 4 ohm
• Total Peak Power: 600 Watts
• High and Low Pass Filters
• 0-12dB Bass Boost
• Aluminum Heatsink
• Dimensions: 9.4" W x 12.9" L x 2" H

Learn more about the ls-bbxf1200-obc8

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Damaged Packaging Only:
A Brand New with Damaged Packaging product is an untouched, unused product, but has damaged original packaging. While the product should be untouched and perfect condition, select packaging materials, such as original protective wrapping, if any, may be missing or damaged. The original manufacturer warranty, if any, still applies, with warranty details included in the listing description or comments. Instructions are included. Product is suitable for presenting as a gift so long as recipient appreciates a great item, not packaging.

Alpine BBX-F1200

600W Peak (280W RMS) BBX Series 4-Channel Class-A/B Amplifier
Quantity: 1

Product Details:

BBX Series Class A/B 2 ohm Stable 4-Channel Amplifier
RMS Power Rating:

4 ohm: 50 watts x 4 channel
2 ohm: 70 watts x 4 channel
Bridged: 130 watts x 2 channel @ 4 ohm

Total power output: 280 watts
LED Power/Protect Light
3-way protection circuitry (Over-Current, Over-Voltage, and Thermal Protection)
Input sensitivity: 0.2 - 8 volts
Frequency Response: 5 - 50 Hz
Total Harmonic Distortion (THD): 1%
Signal to Noise Ratio: 95 dB
Variable high-pass filter: 50 - 500 Hz
Variable low-pass filter: 50 - 500 Hz
Variable Bass Boost: 0 - 12 dB
Fuse Rating: 40A
8 AWG gauge amplifier wiring kit is recommended for installation
Dimensions: 13" L x 9.45" W x 2.05" H
Authorized Internet Dealer
1-year Sonic Electronix Warranty
MFR #: BBX-F1200

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

50 watts x 4 channel

RMS Power @ 2 ohms

70 watts x 4 channel

Bridged RMS Power

130 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total Peak Power Output

600 watts

Total RMS Power Output

280 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

<1%

Speaker Level Inputs

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

50 - 500 Hz

Low-Pass Crossover Frequency

50 - 500 Hz

Signal-to-Noise Ratio

95 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Fuse Rating

40A x 1

Total Fuse Rating

Strappable

Sonic Certified Amplifier

Not Tested

Amp Bluetooth Connectivity

Hi-Res Certified

What is in the box?

Paperwork

User manual

WITB: Amplifiers

Amplifier

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Sonic Electronix

Customer Ratings & Reviews

Alpine BBX-F1200 (open box complete) thumbnail image

Overall rating distribution

5 star		60%
4 star		40%
3 star		0%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		4.9
Value		5
Features		4.9
Design		4.8
Usability		4.9

Customer Photos & Videos

Customer Reviews

Sort by:

Good amp for the price

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

This amp is good for the budget conscious individual who is looking to power speakers but not wake up the neighborhood loud door speakers

By Anonymous on May 31, 2019 Checkmark Icon

Verified purchase

49 found this helpful

Report abuse

Works as should.

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

Installed this amp in my wife's car pushing 4 infinity kapa speakers. Amp is rated at 70 watts rms at 2 ohm the speakers are 2.7 ohms as i recall and it was able to push the speakers to point of bottoming them out. So it does rated power. Zero complaints for the price, Not the smallest amp and the rca/speaker connections are not in the best location though.

By Jed on November 15, 2021

46 found this helpful

Report abuse

High quality amplifier

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

It brought life to my car audio. Had 4 speakers installed without an amp they sounded okay, but after installing the amp both power and fidelity increased.

By Rigo on October 10, 2020 Checkmark Icon

Verified purchase

46 found this helpful

Report abuse

Alpine BBX-F1200

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

Good product and great delivery time from sonic......sleek design on the amp.

By Casey on March 22, 2020 Checkmark Icon

Verified purchase

51 found this helpful

Report abuse

Alpine BBX-F1200 Clean signal to speakers

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

I have this amp running my tweeters and midrange in my 3way front stage, and I have nothing bad to say of the sound the amp produce. My gripe with this amp is where the RCA and speaker terminals are located. The top RCA control the bottom speaker output, and the bottom RCA controls the top speaker output. Why not have the top RCA control the speaker terminal right across and vice versa for the bottom.

By kevin on October 29, 2020 Checkmark Icon

Verified purchase

43 found this helpful

Report abuse

So far so good

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

Well it's been a while and no issues with this amp.

By Steve on September 3, 2020 Checkmark Icon

Verified purchase

40 found this helpful

Report abuse

Alpine amp

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

This is a great amplifier my other Alpine amplifier is 25 years old and still kicking. This one is the replacement for my old one I think it does an even better job. My 12-inch subwoofer is being works hard by this amplifier it's a good price at a hundred and twenty bucks

By Jeff on April 1, 2020 Checkmark Icon

Verified purchase

43 found this helpful

Report abuse

Great amp

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

I wanted an amp to pair with my OEM radio and some Focal speakers. This one is perfect since Focal speakers are very efficient. I like the end covers on the amp to cover connections and easily mounted the amp in the cargo area of my Rogue.

By Anthony on September 29, 2022 Checkmark Icon

Verified purchase

39 found this helpful

Report abuse

Awesome sound plus awesome price

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

The difference this amplifier makes is only comparable to the first time someone put ice in a glass of water.....I am running all four channels with Cerwin Vega 6.5 component sets. This amp really makes them come alive. After setting gains with my multimeter, I can turn the head unit up to 80% without the sound getting distorted and still keep up with the 15" trying to escape my trunk!

By Reggie on February 9, 2023 Checkmark Icon

Verified purchase

36 found this helpful

Report abuse

Great product

The following review is for BBX-F1200, which is a part of the bundle you are viewing.

No cons all pros try this if your looking for something affordable and good quality

By Isaiah on July 2, 2023 Checkmark Icon

Verified purchase

34 found this helpful

Report abuse
