Product highlights

• 750 Watts RMS x 1 @ 4 ohm
• 1500 Watts RMS x 1 @ 2 ohm
• 3000 Watts RMS x 1 @ 1 ohm
• Total Peak Power: 3000 Watts
• CEA-2006 Compliant/Preamp Outputs/LPF
• 0 to 12 dB Bass Boost
• Heavy duty aluminum alloy heat-sink

Learn more about the mm30201d

NVX - Worth the Envy - Direct to Consumer Car Audio

Description

Authorized dealer

General Features:

Autotek Mean Machine MM3020.1D
Class-D 1 ohm Stable Monoblock Amplifier
RMS Power Rating:

4 ohm: 750 watts x 1 chan.
2 ohm: 1500 watts x 1 chan.
1 ohm: 3000 watts x 1 chan.
1 ohm: ------------N/A------------
Bridged, 4 ohm: 3000 watts x 1 chan.

Total power output: 3000 watts
Pulse Width Modulated MOSFET power supply
Wired remote bass level control included
LED power (green) and protect (red) indicators
Soft start turn-on
Mono channel operation
Preamp RCA outputs to daisy chain multiple amps
3-way protection circuitry (thermal, overload, and speaker short protection)
Dual speaker terminals simplify the hookup of multiple speakers
Heavy duty aluminum alloy heat-sink
Input sensitivity:

Low level: .6V-2V

Frequency Response: 15 - 150 Hz
Total Harmonic Distortion (THD): <0.10%
Signal to Noise Ratio: >95 dB
Variable low-pass filter: 40 - 300 Hz, 12 dB/octave
Subsonic filter: 10 - 40 Hz
Variable Bass Boost: 0 to +12 dB bass boost
Fuse Rating: 80A x 1
4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
Authorized Internet Dealer
1-year Manufacturer's Warranty

Specifications & Details

Power Specifications - Subwoofer Channel

Peak Power @ 4 ohm

750 watts x 1 channel

Peak Power @ 2 ohms

1500 watts x 1 channel

Peak Power @ 1 ohm

3000 watts x 1 channel

Amplifier Specifications

Series

Mean Machine Series

Amplifier Class

Number of Channels

1 - Mono

Total Peak Power Output

3000 watts

Total RMS Power Output

3000 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

.1%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
Subsonic

Low-Pass Crossover Frequency

40 - 300 Hz

Subsonic Filter

10 - 40 Hz

Signal-to-Noise Ratio

>95 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Yes

Fuse Rating

80A x 1

Total Fuse Rating

Strappable

Yes

Sonic Certified Amplifier

Not Tested

Amp Bluetooth Connectivity

Hi-Res Certified

What is in the box?

Paperwork

User manual

WITB: Amplifiers

Amplifier
Wired gain knob (wire attached)

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer

Customer Ratings & Reviews

Autotek MM3020.1D (MM30201D) thumbnail image

Overall rating distribution

5 star		67%
4 star		0%
3 star		33%
2 star		0%
1 star		0%

Filter by Star Rating

Show only Verified Purchases

By feature average rating

Durability		3.7
Value		4.4
Features		5
Design		4.7
Usability		4.7

Customer Reviews

Sort by:

Great while it lasted!

The mean machine looked nice, but you get what you pay for and it only lasted 3 months. The sound wasn't bad, but the way they hype it up, I just knew I had found a hidden gem. Anywho, the amp burned out and melted the power wire. Guess it couldn't handle that 1ohm load.

By Michael on August 30, 2021 Checkmark Icon

Verified purchase

7 found this helpful

Report abuse

Good entry level amp

Sounds good in my extended cab truck under back seat down firing 2 12 inch planet audio anarchy.

By Roy on November 20, 2020

8 found this helpful

Report abuse

Great purchase

Put this amp in my car it sounds amazing. Bass sounding better than ever

By William on October 13, 2020 Checkmark Icon

Verified purchase

7 found this helpful

Report abuse
