Product highlights

• RMS: 300 x 2 @ 4 ohm, 420W x 2 @ 2 ohm, Bridged 840W x 1 @ 4 ohm
• Total RMS Power: 840W
• CEA-2006 Compliant
• Efficient Full Range Class D Design
• Dimensions: 10.1"W x 5.4"D x 2.0H

Learn more about the ls-vad8402-obc8

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Damaged Packaging Only:
A Brand New with Damaged Packaging product is an untouched, unused product, but has damaged original packaging. While the product should be untouched and perfect condition, select packaging materials, such as original protective wrapping, if any, may be missing or damaged. The original manufacturer warranty, if any, still applies, with warranty details included in the listing description or comments. Instructions are included. Product is suitable for presenting as a gift so long as recipient appreciates a great item, not packaging.

The VAD8402

If you're looking for a powerful, compact amplifier, the VAD8402 is the amplifier for you. This amp delivers up to 420W of true RMS power to two channels, and fits it all in an incredibly compact chassis.

Water & Weather Resistant

The VAD Line of amplifiers include a conformally coated, marine grade circuit board. This allows this amplifier to be installed in nearly any application.

Marine Certified Full Range Class D 2-Channel Amplifier
CEA-2006 Compliant
Peak Power Rating: 1680 Watts
RMS Power Rating:

4 ohm: 300 watts x 2 chan.
2 ohm: 420 watts x 2 chan.
Bridged, 4 ohm: 840 x 1 chan.

LED power (blue) and protect (red) indicators
Conformal Coated Marine grade circuit board
Heavy duty aluminum alloy heat-sink
Platinum-plated RCA level inputs
Platinum-plated screw terminals
Preamp RCA outputs to daisy chain multiple amps
3-way protection circuitry (thermal, overload, and speaker short protection)
Selectable crossover modes: FULL / HPF / LPF
Variable high-pass filter: 40 - 500 Hz, 12 dB/octave
Variable low-pass filter: 40 - 500 Hz, 12 dB/octave
Frequency Range : 20 - 20KHz
Bass Boost: 0 - +12dB boost @ 45Hz
Input Sensitivity: 200mV-6V
Total Harmonic Distortion: <0.3%
Fuse Rating: 40A x 2
Power Wire Gauge: 4 AWG
Speaker Wire Gauge: 8 AWG
Dimensions: 9.2"L x 7.2"W x 2.0"H
Authorized Internet Dealer
1-year Manufacturer's Warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

300 watts x 2 channel

RMS Power @ 2 ohms

420 watts x 2 channel

Bridged RMS Power

840 watts x 1 channel

Power Specifications - Full Range Channels

Peak Power @ 4 ohms

600 watts x 2 channel

Peak Power @ 2 ohms

840 watts x 2 channel

Bridged Peak/Max Power

1680 watts x 1 channel

Amplifier Specifications

Amplifier Class

Number of Channels

2-Channel

Total Peak Power Output

1680 watts

Total RMS Power Output

840 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.3%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

40 - 500 Hz

Low-Pass Crossover Frequency

40 - 500 Hz

Signal-to-Noise Ratio

105 dB

Bass Boost

0 - 18 dB

Remote bass/level controller

Fuse Rating

40A x 2

Total Fuse Rating

Strappable

Sonic Certified Amplifier

Yes

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
