For 24V systems only: M-Series 8-channel Class D Full-Range Marine Amplier
• 800W RMS
• Preamp RCA outputs
• 3-Way System Protection Circuitry
• Variable High/Low-Pass Filter
• Remote Bass Level Input
• Total Amplifier Efficiencies Exceed 80%
This potent 8-Channel amplifier employs JL Audio's high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output in an ultra-compact chassis. Don't let the small size fool you, though... this amplifier is capable of serious power, delivering a full 800W of continuous total power into a 2 ohm load (28.8V, 1% THD). Targeted specifically for an audiophile-grade system, the M800/8-24V includes a variable mode low-pass/high-pass filter with a continuously variable cutoff frequency selection from 50-500 Hz. With the M800/8-24V, you have lots of great options.
With the addition of an HD-RLC remote level control (sold separately), you can control the volume of one, two or all three channel pairs of the M800/8-24V from the front of the vehicle or boat. This amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.
JL Audio's signature Advanced Thermal Rollback protection system eliminates annoying thermal shutdown events to keep the music playing, even under the most demanding conditions. Should the amplifier reach an unsafe operating temperature, a special circuit rolls back peak power output, without changing gain, until the amplifier cools down to a safe operating temperature. The red "Thermal" LED will light to indicate this condition has been reached. Once the amplifier cools down, the circuit restores full peak power output and the red "Thermal" indicator reverts to its normal state. The operation of Advanced Rollback Protection is inaudible in most cases.
From the same minds that gave us the technology found in the 'Slash' amplifiers, JL Audio has taken the simple fixed PWM design approach and enhanced it with a very high switching frequency. Full-range NexD™ amplifiers and channels feature a variable, ultra-high speed version of the NexD™ technology (switching at well over 400 kHz). In these designs, a self-oscillating modulator with "feed-forward" sends information about the instantaneous power supply voltage to the modulator, combining this with the input signal to cancel out any distortion due to supply voltage fluctuation. This reduces distortion prior to applying feedback, simplifying the overall feedback loop design.
JL Audio M800/8-24V
For 24V systems only: M-Series 8-channel Class D Full-Range Marine Amplier
Quantity: 1
$150 e-Gift Card at Sonic Electronix
Digital e-Gift Card for value of $150 applies electronically to account
Quantity: 1
Manufacturer:
Model Number:
M800/8-24V, 150EGIFT
Weight:
10.01lbs
Internal SKU:
m8008_24v_150egift
Internal Product ID:
183679
Suck
I did not receive this credit they told me I'll get it after 60 day of my purchase
26
found this helpful.great value
sonic electronix honored the 150 dollar gift card with ease. thank you very much guys
27
found this helpful.Best selling similar products
