PAC C2R-FRD1

Radio Replacement Interface for

PAC
Shop all PAC
highlight-star-icon

• Radio Replacement Interface for Select 2005-Up CAN-bus Ford, Lincoln and Mercury Vehicles
• Enables Factory Features Such As Rear Seat Entertainment, Rear Controls, THXII Amp When The Factory Radio Is Replaced

Learn more about the c2rfrd1

We apologize

This item has been discontinued


Loading...
Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

JS35K main

Jensen JS35K

150W Peak (50W RMS) 3.5" Apex Series 2-Way Coaxial 4-ohm Car Speakers

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

51KSC3504 main

Kicker KSC35 (51KSC3504)

200W Peak (100W RMS) 3.5" KS Series 2 Way Coaxial 4-ohm Speakers

4
-11.11%

$79.99

List price $89.99

Description


PAC brand icon

Authorized dealer

General Features:

  • Radio Replacement Interface [[!afgDescLink]]
  • Enables factory features such as rear seat entertainment, rear controls, and the THXII amp when the factory radio is replaced
  • Also provides RAP accessory power output, vehicle speed, illumination, reverse indication output and parking brake ouput signal to allow easy installation of an aftermarket NAV system
  • 1-year Manufacturer's warranty

Compatibility List:

  • Ford:
    • 2005-2007 Five Hundred
    • 2005-2007 Freestyle
    • 2005-2008 Mustang (Shaker 500 and 1000 inclued)
    • 2006-2008 Explorer
    • 2006-2008 Fusion
    • 2007-2008 Sport Trac
    • 2007-2008 Edge
    • 2007-2008 Expedition
    • 2008 Escape
    • 2008 F-250
    • 2008 F-350
    • 2008 F-450
    • 2008 Taurus
    • Note: Not compatible with F-250/F-350/F-450 with the XL trim package
  • Lincoln:
    • 2007-2008 MKX
    • 2007-2008 MKZ
    • 2007-2008 Navigator
  • Mercury:
    • 2005-2007 Montego
    • 2006-2008 Milan
    • 2006-2008 Zephyr
    • 2006-2008 Mountaineer
    • 2008 Mariner
    • 2008 Sable

Connections:

  • Yellow – 12V Constant
  • Red – 12V Accessory
  • Black - Ground
  • Orange – Dash Light Dimmer/Illumination
  • Green – Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White – Left Front Speaker (+)
  • White with Black Stripe – Left Front Speaker (-)
  • Purple – Right Rear Speaker (+)
  • Purple with Black Stripe – Right Rear Speaker (-)
  • Gray – Right Front Speaker (+)
  • Gray with Black Stripe – Right Front Speaker (-)

Notes:

  • Rear Seat Entertainment (RSE) audio is not retained through the speakers in Ford/Lincoln/Mercury vehicles that are equipped with the Ford SYNC system. The RSE will power up, operate normally and pass audio through the IR headphones; however the audio can not be passed through the aftermarket radio.
  • Does not retain the factory RSE in 2006-2007 Ford Freestyle
  • Does not retain the THX amplifier in the 2006 Lincoln Zephyr

Best selling similar products

70-1817 small

Metra 70-1817 Wiring Harness

• Direct Connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(29)

$5.99

List price $6.99

70-1818 small

Metra 70-1818

• Direct Connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(2)

$18.99

List price $26.99

CWH64A small

PAC CWH64A

• OEM amplifier retention harness for aftermarket stereos
• Compatible with select 1984-2012 vehicles from Dodge, Chrysler, Plymouth
• Connects to the vehicle's factory harness

$17.00

List price $24.00

DKGM-49 small

Crux DKGM-49 Stereo Replacement Interface

• Stereo Replacement Interface with Dash Kit
• Fits select 2006-2020 vehicles from GMC, Chevrolet, Buick Vehicles
• Accommodates ISO Double DIN Mount
• Retain steering wheel controls and chime functions

(41)

$129.60

List price $201.60

70-1761 small

Metra 70-1761 Wiring Harness

• Direct connection to the factory radio harness
• Color coded wires for easy installation
• No cutting or splicing required

(97)

$5.99

List price $6.99

70-1771 small

Metra 70-1771

• Direct Connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(51)

$12.99

List price $6.99

70-5520 small

Metra 70-5520 Wiring Harness

• Direct Connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(56)

$9.95

List price $6.99

RP4-CH11 small

PAC RP4-CH11

• Direct connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(12)

$152.99

List price $379.00

C2R-CHY4 small

PAC C2R-CHY4 Wiring Interface

• Provides 12-Volt accessory power (RAP)
• Designed for non-amplified and amplified models
• Retains balance and fade
• Pre-wired for steering wheel audio controls

(25)

$99.99

List price $299.00

GM02B small

Scosche GM02B Wiring Harness

• Direct Connection to the factory harness
• Color coded wires for easy installation
• No cutting or splicing required

(246)

$7.95

List price $8.99

Specifications & Details


Harness Features
Main Harness Function
Connect/Install an Aftermarket Car Stereo
Additional Harness Features
Provides Parking Brake & Reverse Signals
Provides Vehicle Speed Sense
Retained Accessory Power (RAP) Retention
Retains Rear Seat Entertainment
Premium Harness Features
Compatible Premium Audio Systems
Shaker 1000
Shaker 500
CAN-BUS Compatible
Yes
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

PAC

Model Number:

C2R-FRD1

Weight:

0.75lbs

Internal SKU:

c2rfrd1

Internal Product ID:

18706
