Pioneer TS-A301D4

1600W Peak (500W RMS) 12" Champion Series Dual 4-ohm Car Subwoofer

Pioneer
Shop all Pioneer
highlight-star-icon

• Peak Power: 1600 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• Carbon and Mica Reinforced Injection Molded Polypropylene Cone
• Elastic Polymer Surround
• Mount depth: 6.125"
• Sensitivity: 92 dB

Learn more about the tsa301d4
Was $165.00 Details
Thanks , You Pay:

$140.00

 with warranty

Heads up

We confirm fitment and offer accessories for speakers. Please set your vehicle first if you would like to purchase more than one tsa301d4.

Set your vehicle or Return to product page
shipping truck icon Free shipping in USA. Provide zip for delivery date.
Quantity
In Stock
Brand new

Buy it now


Acima Logo

No Credit Option

Flexible Lease Payments

Early Purchase Options

Quick Approval Decision

Extend logo

Keep your product protected longer! Extend the warranty after the manufacturer warranty expires.

  • Hassle-free immediate replacement within minutes!
  • Easy online claims 24/7
  • Covers product breakdowns and failures
Swoosh Icon Icon of Swoosh

For over 24 years, we've been your X-Factor – the team dedicated to having the biggest impact on your shopping experience!

Award winning icon
Award-Winning Service
Shipping icon
FREE Shipping Orders $49+
60 days return policy icon
60-Day Easy Returns
lowest price guarantee icon
Guaranteed Lowest Price
inHouseExpert
In-House Experts

Current Promotions (1 offer)


Get a Free roll of Belva 16 Gauge Speaker Wire. Simply click the "Add Both to Cart" button and you will see your savings at checkout. This offer cannot be combined with any other coupons or offers.

Pioneer TS-A301D4

100% off


Priced separately $152 99

Promo Savings of $12 99

Total price:

$140 00

Description


Pioneer brand icon

Authorized dealer


TS-A301D4

The Champion Series subwoofers have evolved from Pioneer’s award-winning “SPL Champion Edition” lineup, known for its deep and powerful bass production. The TS-A301D4 12” dual-voice coil component subwoofer features a re-designed large and powerful motor assembly for improved efficiency and sensitivity. The subwoofer baskets are optimized using a reinforced structure design for added strength and reduced vibration to deliver excellent sound quality. This subwoofer has a continuous power of 500 watts with a maximum peak of 1,600 watts. It features an advanced 2-piece cone designed with a highly rigid and durable Honeycomb IMPP™ composite cone structure plus a rigid drive cone to deliver high output levels with reduced distortion.


Product Details:

  • 12" Dual 4 ohm Champion Series Subwoofer
  • Power Handling:
    • Peak: 1600 watts
    • RMS: 500 watts
  • Carbon and Mica Reinforced Injection Molded Polypropylene Cone
  • Elastic Polymer Surround
  • Cellulose Fiber Drive Cone Material
  • Steel basket material
  • 3" High Temperature Copper Voice coil
  • 11.3 mm Xmax
  • 90 oz. Double Stacked Ferrite magnet motor structure
  • Frequency Response: 20 - 1600 Hz
  • Resonance Frequency (Fs): 38 Hz
  • Sensitivity: 92 dB
  • Recommended sealed box volume: 0.85 cubic feet - 1.75 cubic feet
  • Recommended ported box volume: 1.25 cubic feet - 2 cubic feet
  • Top-mount depth: 6.125"
  • Cutout diameter: 11.125"
  • CTA-2031 Compliant
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconPioneer TSA301D4 owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Pioneer TS-A301D4 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Pioneer TS-A301D4 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Pioneer TS-A301D4 Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Pioneer TS-A301D4 Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Champion Series
Subwoofer Size
12"
Peak Power Handling
1600 watts
RMS Power Handling
500 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Material
Copper
Voice Coil Diameter
3"
Frequency Response
20 - 1600 Hz
Sensitivity
92 dB
Xmax (millimeters)
11.3 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Carbon and Mica Reinforced Injection Molded Polypropylene
Woofer Surround
Elastic Polymer
Magnet Structure
Double Stacked
Magnet weight
90 oz.
Magnet Type
Ferrite
Subwoofer Grille
No
Re-Cone Kit Available
No
CTA-2031 Compliant
Yes
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.85 cubic feet
Optimum Sealed Box Volume
1.25 cubic feet
Maximum Sealed Box Volume
1.75 cubic feet
Minimum Ported Box Volume
1.25 cubic feet
Optimum Ported Box Volume
1.5 cubic feet
Maximum Ported Box Volume
2 cubic feet
Top-Mount Depth (Mounting Depth)
6.125"
Cutout Diameter
11.125"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
38 Hz
Equivalent Compliance (Vas)
37.7 liters
Total Speaker Q Value (Qts)
0.73
Electrical Q Value (Qes)
0.79
Mechanical Q Value (Qms)
9.58
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

TS-A301D4

Weight:

15.20lbs

Internal SKU:

tsa301d4

Internal Product ID:

194649
