Infinity Reference REF1200S with Ported Enclosure

1000W Peak (250W RMS) 12" Reference Series Single 4-Ohm Car Subwoofer

Infinity
Shop all Infinity
highlight-star-icon

• Peak Power: 1000W
• RMS Power: 250W
• Selectable Impedance Switch
• Polypropylene Cone with Rubber Surround
• Includes Ported Enclosure

Learn more about the ref1200s_1sv12b
Was $379.94 Details
Thanks , You Pay:

$184.94

 with warranty

Heads up

We confirm fitment and offer accessories for speakers. Please set your vehicle first if you would like to purchase more than one ref1200s_1sv12b.

Set your vehicle or Return to product page
shipping truck icon Free shipping in USA. Provide zip for delivery date.
Quantity
In Stock
Brand new

Buy it now


Acima Logo

No Credit Option

Flexible Lease Payments

Early Purchase Options

Quick Approval Decision

Allstate logo

Keep your product protected longer! Extend the warranty after the manufacturer warranty expires.

  • Mechanical, electrical and product failure covered! 100% parts and labor covered. (Coverage starts after Mfr. warranty)
  • Easy online management! Zero hassle claim service, available 24/7
Swoosh Icon Icon of Swoosh

For over 23 years, we've been your X-Factor – the team dedicated to having the biggest impact on your shopping experience!

Award winning icon
Award-Winning Service
Shipping icon
FREE Shipping Orders $49+
60 days return policy icon
60-Day Easy Returns
lowest price guarantee icon
Guaranteed Lowest Price
inHouseExpert
In-House Experts

Description


Infinity brand icon

Authorized dealer

Selectable Smart Impedance Technology

Infinity’s latest Reference subwoofers offer incredible installation flexibility. Their low-profile design allows them to fit perfectly into even the most shallow of enclosure. Polypropylene woofer cones deliver exceptional bass response at frequencies as low as 27Hz. But what makes these subs really stand out is their Harman-proprietary SSITM (Selectable Smart Impedance), which allows the subwoofer to present the amplifier with either a 2 or 4 ohm load at the flip of a switch.

Infinity Reference 1200S (REF1200S)

1000W Peak (250W RMS) 12" Reference Series Selectable Impedance Car Subwoofer
Quantity: 1

Product Details:

  • 12" Single 2 or 4 ohms Reference Series Subwoofer
  • Power Handling:
    • Peak: 1000 watts
    • RMS: 250 watts
  • Polypropylene Cone
  • Rubber Surround
  • Shallow-mount subwoofer
  • Harman-proprietary SSI™ (Selectable Smart Impedance)
  • OEM-level reliability testing
  • 2" High Temperature Voice coil
  • 7.65 mm Xmax
  • Frequency Response: 27 - 175 Hz
  • Resonance Frequency (Fs): 22.82 Hz
  • Sensitivity: 92 dB
  • Sealed box volume: 0.75 cubic feet
  • Ported box volume: 1.75 cubic feet
  • Top-mount depth: 3.25"
  • Cutout diameter: 11.125"
  • Authorized Internet Dealer
  • Protective subwoofer grille: No
  • 1-year Manufacturer's Warranty

  • Priced Individually

Single 12" Vented MDF Subwoofer Enclosure (Belva 1SV12B)

12-inch Vented Car Sub Box Made with 3/4" MDF and lined w/ Polyfil (1.8 cu ft airspace 1SV12B)
Quantity: 1

Built for Bass

You've got an awesome subwoofer there, pal. But where's it gonna go? You can't just throw that thing in the trunk and call it a day. Don't worry, Belva's got your back. With superior construction, great features and everything you need for bass, you'll be ready to pass up that entry-level box you've been eyeballing.

Belva Subwoofer Boxes are CARB Phase 2 Compliant

You get quality boxes with solid 3/4" MDF because nothing else will do the job right. You want to flex your windshield, not your box's innards. You get polyfill built into the box, making sure your subs perform perfectly. On top of that, you get a box that's CARB Phase 2 Compliant, meaning your box won't emit as much nasty formaldehyde as the competition. Better for your bass and better for you.

Belva MDF 3/4-inch Thickness

Look, nobody buys a subwoofer and says, 'Aw man, I just want a teeny bit of thump.' Naw man, you want something that kicks you in the chest, but you need a box that's gonna put up with it. That's where Belva comes in. While other brands use less-than-optimal 1/2-inch MDF, we've got 3/4-inch MDF to make sure you get all the bass you can handle. Why risk a busted box? Belva's the obvious choice when it comes to giving your sub a good home and giving you the low end you're looking for.

Belva MDF 3/4-inch Thickness

  • Single 12" Vented MDF Enclosure
  • Holds one 12" subwoofer
  • 3/4 MDF (Medium Density Fiberboard) Construction
  • Durable black carpeting
  • Gold Terminals
  • Tuning Frequency: 36Hz
  • Internal Box Volume: 1.8 cubic ft.
  • Dimensions: 13-5/8"H x 17"D x 19-1/4"W
  • 30 Day return policy

Specifications & Details


Subwoofer Specifications
Series
Reference Series
Subwoofer Size
12"
RMS Power Handling
250 watts
Peak Power Handling
1000 watts
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Sensitivity
92 dB
Frequency Response
27 - 175 Hz
Subwoofer Design
Round / Circle
Enclosure Specifications
Box Type
Ported
Number of Subwoofers
1
Box Style/Shape
Square/Rectangle
Wood Thickness
3/4"
Number of Terminals
1
Terminal Type
Binding posts
Box Exterior Color
Gray
Box Finish
Carpet
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

Reference 1200S, 1SV12B

Weight:

47.80lbs

Internal SKU:

ref1200s_1sv12b

Internal Product ID:

195513

Customer Ratings & Reviews



5 star
73%
4 star
19%
3 star
6%
2 star
2%
1 star
1%



Durability
4.7
Value
4.8
Features
4.7
Design
4.7
Usability
4.8

Customer Reviews

Sort by:

Loading...

good

The following review is for 1SV12B, which is a part of the bundle you are viewing.

Pretty well made box. The sub hole was a little too small for my 12" hcca but a little cutting solved that. I didn't have time to make my own box so this suited me realyl well.

By Trevor on October 29, 2014

127

found this helpful.

good product

The following review is for 1SV12B, which is a part of the bundle you are viewing.

Sound really good and looks good. Made fairly good. Would for sure recommend

By Bryan on May 28, 2014

123

found this helpful.

Very very nice, exact specs below.

The following review is for 1SV12B, which is a part of the bundle you are viewing.

Very nice box. The carpet is nice and seems to be glued properly, although it does look like it might rub off in time. Build quality is very nice, feels very sturdy. There are some globs of dried glue on the exterior but nothing I can't get over. It would have been nice to not have the sub cutout so close to the port but that's just nitpicking. Doesn't come with wires internally but the terminals are much nicer than I've seen on other prefab boxes.
Regardless of what Belva has published, this box is not 1.8 ft.

The gross volume is 1.97 ft, but after taking into account port displacement, it's net volume is 1.30 ft. It's also tuned to 34.4 Hz. Determined using the Torres Speaker Box Calculator.

By Alex B. on July 4, 2013

118

found this helpful.

well built box

The following review is for 1SV12B, which is a part of the bundle you are viewing.

For the price it cannot be beat. This box meets the recommended size enclosure for the single sub i ordered, which is the Rockford P2D4. Ported to trick the sub its in a bigger box with poly fill lining. Well built and carpeted in dark gray. I highly recommend it. Hits lows hard and loud.

By Rick on December 19, 2013

114

found this helpful.

Not bad

The following review is for 1SV12B, which is a part of the bundle you are viewing.

So I bought one of the "Sonic Boxes" a couple years back and it was similar to this box but gray. The sonic box was better build quality. This box has a hole cut that is nowhere near center. It's up and to the right a bit, but that's what you get for a 55 dollar box I guess. The carpet around the ported has started to come unglued and the box hasn't had any play time what so ever. It seems to be mdf and 3/4". The dimensions are correct. Port tune is around 35 hz and net box size is around 1.4 cubic ft. The poly fill probably needs to be glued down so I will stay inside the box. The port used to be rounded on the inside with the sonic box now it is not. It is a good box to get by on since it is built pretty well, but I would recommend getting a box built to spec for the woofer you have for optimal sound. For 55 bucks it's not a bad way to get by, just don't expect the best for that price point.

By Luke on December 23, 2013

109

found this helpful.

Great Prefab box

The following review is for 1SV12B, which is a part of the bundle you are viewing.

I would highly recommend this box it sounds like it is tuned between 34-36hz hits lows really good unlike i was expecting since it is vented. I had a rockford fosgate p3 and it sounded amazing in the box and now I have an Alpine type S in there until my new p3 comes back in and the type s even sounds great i didnt think a type s would pound like it did. Good box would def recommend and buy again if need be.

By Christopher on September 23, 2013

108

found this helpful.

Awesome box

The following review is for 1SV12B, which is a part of the bundle you are viewing.

This box sounds great coupled with a Pioneer Champion Series Pro and 1500 watt amp. Very deep bass tones and very loud. Definitely would recommend.

By Bob_D on December 15, 2014

107

found this helpful.

Great product

The following review is for 1SV12B, which is a part of the bundle you are viewing.

Slim and powerful speaker that packs massive power for a great price.

By Ernest on June 8, 2014

110

found this helpful.

Worth the space

The following review is for 1SV12B, which is a part of the bundle you are viewing.

I downgraded from a much larger box to this one and noticed no difference. Saved me some space, though it's still pretty big, and handles the sub perfectly. Feels sturdy and looks good.

By Matthew on May 5, 2014

110

found this helpful.

Belva

The following review is for 1SV12B, which is a part of the bundle you are viewing.

This cost more then the gray one but they both perform the same just that the black exterior looks way better then the gray

By eduardo on February 11, 2015

105

found this helpful.
