Deaf Bonce AAB-500.1D ATOM

568W RMS Class D Apocalypse Series Monoblock Car Amplifier

Deaf Bonce
Shop all Deaf Bonce
highlight-star-icon

• 205 watts x 1 channel @ 4 ohm
• 331 watts x 1 channel @ 2 ohm
• 568 watts x 1 channel @ 1 ohm
• Total RMS Power: 568 watts
• Class D 1 ohm Stable Monoblock Amplifier

Learn more about the aab5001atom

We apologize

This item has been discontinued


Loading...
KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

Limited time!
TS-G4620S main

Pioneer TS-G4620S

400W Peak (60W RMS) 4x6" G-Series 2-way 4-ohm Coaxial Car Speakers

6
-41.25%

$38.19

List price $65.00

Description


Deaf Bonce brand icon

Authorized dealer

Product Details:

  • Apocalypse Series Class D 1 ohm Stable Monoblock Amplifier
  • RMS Power Rating:
    • 4 ohm: 205 watts x 1 channel
    • 2 ohm: 331 watts x 1 channel
    • 1 ohm: 568 watts x 1 channel
    • 1 ohm: 502 watts x 2 channel (12V)
  • Total RMS power output: 568 watts
  • LED Power/Protect Light
  • Wired bass level remote control (sold separately)
  • Mono output of pre-amp outputs
  • Input sensitivity: 0.2 - 6 volts
  • Frequency Response: 15 - 180 Hz
  • Total Harmonic Distortion (THD): 1%
  • Signal to Noise Ratio: >100 dB
  • Variable low-pass filter: 35 - 180 Hz
  • Subsonic filter: 15 - 50 Hz
  • Variable Bass Boost: 0 - 12 dB
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 6.30" L x 4.92" W x 2.5" H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • MFR #: AAB-500.1 ATOM
