HFi Series 4-Channel Class A/B Car Amplifier • 200W x 4-Chan. @ 2 Ohm • 100W x 4-Chan. @ 4 Ohm • Tri-Mode Speaker Operation • 4-Way System Protection Circuitry • Preamp RCA Outputs • Blue Illuminated Hifonics Badge

Learn more about the LS-hfi1004-OB

Product Highlights

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

HFi Series 4-Channel Class A/B Car Amplifier
Item Condition: Open Box
RMS Power Rating:
- 4 ohm: 100 watts x 4 chan.
- 2 ohm: 200 watts x 4 chan.
- Bridged, 4 ohm: 400 watts x 2 chan.
Max power output: 800 watts
Pulse Width Modulated (PWM) MOSFET power supply
LED power (blue) and protect (red) indicators
Variable Bass Boost (0 to +12 dB bass boost at 45 Hz)
Blue illuminated Hifonics badge
Soft start sound function
4/3/2 channel operation
Preamp RCA outputs to daisy chain multiple amps
4-Way System Protection circuitry (thermal, overload, DC, and speaker short protection)
Tri-mode speaker operation
Heavy duty aluminum alloy vented heatsink for maximum heat dissipation
Silver nickle-plated RCA level inputs
Silver nickle-plated screw terminals
Input sensitivity:
- Variable level: 200mV-6V
Variable high-pass filter (60-12,000 Hz, 12 dB/octave)
Variable low-pass filter (30-250 Hz, 12 dB/octave)
Damping factor: >180
Frequency response: 30-12,000 Hz
Dimensions: 16-1/4"L x 8-13/16"W x 2-7/16"H
4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Authorized Internet Dealer
1-year Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 4 channel

RMS Power @ 2 ohms

200 watts x 4 channel

Bridged RMS Power

400 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total RMS Power Output

800 watts

Maximum Input Gauge Size

4 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.05%

Speaker Level Inputs

Preamp Outputs

1 pair

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

60 - 12,000 Hz

Low-Pass Crossover Frequency

30 - 250 Hz

Signal-to-Noise Ratio

90 dB

Channel Separation

80 dB

Bass Boost

0 - 12 dB

Remote bass/level controller

Fuse Rating

30A x 2

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
