Audiobahn A1502DP

True Digital Series 2-Channel Amplifier

Audiobahn
Shop all Audiobahn
Product videos
highlight-star-icon

1 ohm stereo stable, 2 ohm bridged • True Digital Circuitry • Dual Cooling Fans • HP/LP Crossovers • Bass Boost • Cobalt Blue Illumination • 150/300/450 watts x 2 ch. (@ 4/2/1 ohm)

Learn more about the a1502dp

We apologize

This item has been discontinued


Loading...
72-5602 main

Metra 72-5602

Install New Front Kick Panel Speakers in select 2009-2024 vehicles from Ford, Mazda, Lincoln

43
-20.01%

$11.99

List price $14.99

82-5606 main

Metra 82-5606

6x9" Front Door Speaker Bracket for select 2015-2025 vehicles from Ford, Lincoln

15
-48.62%

$16.95

List price $32.99

82-FD1 main

Metra 82-FD1

Ford 2011-2020 Speaker Adapter Kit - Front or Rear

10
-38.81%

$20.80

List price $33.99

82-5602 main

Metra 82-5602

6X9" Speaker Adapter for select 2011-2020 Explorer and F-Pace

2
-47.51%

$20.99

List price $39.99

82-5603 main

Metra 82-5603

6" to 6-3/4" Speaker Adapter for select 2011-2019 Explorer

2
-50.01%

$19.99

List price $39.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

XBAF69 main

NVX XBAF69

Universal 6x9" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

47
-42.51%

$22.99

List price $39.99

R169X2 main

Rockford Fosgate Prime R169X2

260W Peak (130W RMS) 6x9" Prime Series 2 Way Coaxial 4-ohm Speakers

49
NSP69 main

NVX NSP69

900W Peak (300W RMS) 6x9" N-Series 2 Way Coaxial Car Speakers

53
-16.67%

$89.99

List price $107.99

TWPZ main

DS18 TWPZ

80W Peak (40W RMS) 1" Slim Dome Super Tweeters

6

Product Highlights


1 ohm stereo stable, 2 ohm bridged • True Digital Circuitry • Dual Cooling Fans • HP/LP Crossovers • Bass Boost • Cobalt Blue Illumination • 150/300/450 watts x 2 ch. (@ 4/2/1 ohm)

Description


  • Class D, True Digital Circuitry 2-Channel Car Amplifier
  • RMS Power Rating:
    • 150 watts x 2 chan. @ 4 ohm
    • 300 watts x 2 chan. @ 2 ohm
    • 450 watts x 2 chan. @ 1 ohm
    • Bridged, 300 watts x 1 chan. @ 4 ohm
    • Bridged, 600 watts x 1 chan. @ 2 ohm
  • Preamp Outputs
  • Cobalt Blue LED Illuminated Heat Sink Design (on/off switch for your preference)
  • Dual Cooling Fans
  • Chrome Flame Cooling Fan Grill Covers Included (other optional designs available and sold separately)
  • Double Sided Glass Epoxy Circuit Board
  • High Gloss Chrome Plated Finish
  • Optional Remote-mount Digital Volt-meter Display (Audiobahn ADM100T sold separately)
  • 4-Way Protection Circuitry: Thermal, Short Circuit, Overload, DC Offset
  • Variable Bass Boost: 0-12dB
  • Variable High-Pass Crossover: 50-250Hz
  • Variable Low-Pass Crossover: 50-250Hz
  • Signal-to-Noise Ratio: 100dB
  • Frequency Response: 20Hz-20kHz
  • THD: 0.05%
  • Input Sensitivity: 200mV - 8V
  • 4-gauge power and groud leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
  • Dimensions: 9-15/32" L x 8-1/2" W x 2-1/16" H
  • 1-year SonicElectronix.com warranty

Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

3
-19.05%

$339.99

List price $420.00

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00


Best selling similar products

VADM4v2 small

NVX VADM4 v2 (VADM4v2)

• 80 watts x 4 channel @ 4 ohm
• 125 watts x 4 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(41)

$209.99

List price $239.99

NDA6004 small

NVX NDA6004

• 100 watts x 4 channel @ 4 ohm
• 160 watts x 4 channel @ 2 ohm
• Bridged: 320 watts x 2 channel @ 4 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(14)

$159.99

List price $215.99

NDA12001 small

NVX NDA12001

• 500 watts x 1 channel @ 4 ohm
• 850 watts x 1 channel @ 2 ohm
• 1200 watts x 1 channel @ 1 ohm
• Total RMS Power: 1200 watts
• Class D 1 ohm Stable Monoblock Amplifier

(13)

$169.99

List price $239.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
150 watts x 2 channel
RMS Power @ 2 ohms
300 watts x 2 channel
RMS Power @ 1 ohm
450 watts x 2 channel
Bridged RMS Power
900 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
2-Channel
Total RMS Power Output
900 watts
Minimum Impedance Unbridged
1 ohm
Minimum Impedance Bridged
2 ohms
THD at Rated RMS Power
0.05%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
50 - 250 Hz
Low-Pass Crossover Frequency
50 - 250 Hz
Signal-to-Noise Ratio
100 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
No
Fuse Rating
30A x 1

Item Details


Manufacturer:

Model Number:

A1502DP

Weight:

14.00lbs

Internal SKU:

a1502dp

Internal Product ID:

2304

Product and How-to Videos


Customer Ratings & Reviews


Audiobahn A1502DP thumbnail image

5 star
50%
4 star
50%
3 star
0%
2 star
0%
1 star
0%



Durability
4.5
Value
5
Features
4.8
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

Low Amp

I own this amp and for starers it made my 2 10L5S hit pretty good but now it doesn't sound that loud. The does put out some serious bass if u turn it up all the way. the filter level really doesn't do anything for the amp or subs. Then you have the level which is gain, u turn that up and the subs hit hard. Overall it is a really good amp for the price and wattage. My only problem is that I can't feel the full sound out of my subs from it. The sol-barics should hit harder than they are with the amp but they aren't. It looks great I haven't had it shut down at all and i put a lot of power to it. Sonic has it for the cheapest price. It looks sweet with that blue neon at night. I gave a 4 overall because it should be making my system hit harder and it isn't.

By cory on April 20, 2006

4 found this helpful


Buy It

It is extremly worth the price and it easy to setup up. I had it in my car for 5 months and no problems. Buy it

By Andy on November 27, 2005

4 found this helpful


great amp

for a little over two hundred bucks this amp is very good. It pushes my subs perfectly. Se never seems to fail with great deals.

By jimmy on February 2, 2006

2 found this helpful


pretty good buy

for a while now this amp has been really good to me. I have it powering a pioneer premier ts-w3004spl(1000 rms) and this amp makes it hit really hard. this past weekend though i was going around a turn and a car was stopped dead so i had to slam on my brakes. i has just re-wired my subwoofer so i didnt screw it back down and my subwoofer slid forward and hit the amp pretty hard. The amp cuts off in certain positions now so i have to keep it at a certain angle for it to stay on. I mean its my fault my subwoofer slid into it thats not the amps fault so overall this amp has been pretty good to me since a 100 pound box doesnt even break it

By trillium on March 3, 2009
