See all parts that fit your 1994 Shadow

DLS X-D30

730W RMS, X-Program 3-Channel Class D Amplifier (12-31030)

DLS
Shop all DLS
EXCLUSIVE
Product videos
highlight-star-icon

X-Program 3-Channel Class D Car Amplifier • 730W RMS • Variable Bass Boost • Speaker-Level Inputs • Preamp RCA Outputs • Variable Low/High-Pass Filters • 3-Way System Protection Circuitry • Fully Variable Phase Shift

Learn more about the xd30

We apologize

This item has been discontinued


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95

Product Highlights


X-Program 3-Channel Class D Car Amplifier • 730W RMS • Variable Bass Boost • Speaker-Level Inputs • Preamp RCA Outputs • Variable Low/High-Pass Filters • 3-Way System Protection Circuitry • Fully Variable Phase Shift

Description


DLS brand icon

Authorized dealer

X-Program by DLS: Born to Play

The DLS X-Program was designed for those that love their music and love to listen at high levels. This specialized line from DLS has everything you need for a high-end, audiophile sound system. With precise engineering, these items still offer complete control of your audio and help you preserve the sound quality. The X-Program from DLS is a Sonic Electronix exclusive and is the perfect blend of performance and price. Just like the rest of the DLS products, the X-Program is designed and engineered by DLS in Sweden.

Born with Extreme Technology

X-Program amplifiers use class D technology that is either all on or all off, so these amplifiers have low heat build-up in idle positions and are nearly 90% efficient. These full range digital class D amplifiers produce incredible power from a compact package so you can fit them almost anywhere, even under your front seat! All X-Program amplifiers are 4-ohm and 2-ohm stable so you can maximize you’re wiring options for speakers or subwoofers. Low-pass and high-pass filters allow you to tune your system just right by feeding your speakers only the frequencies they can handle, which reduces distortion. Phase shift of 180 degrees allows you to keep your subwoofer in phase with your speakers for the best tonal accuracy. Wrapping everything up, the silver finned heat sink is elegant and efficient removing any harmful heat generated from intense musical sessions. X-Program amplifiers were born to play rough, don’t let their compact size fool you.

  • X-Program 3-Channel Class D Car Amplifier
  • RMS Power Rating (14.4V):
    • 4 ohm: 120 watts x 2 chan. + 220 watts x 1 chan.
    • 2 ohm: 200 watts x 2 chan. + 330 watts x 1 chan.
    • Bridged, 4 ohm: 310 watts x 1 chan.
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Variable Bass Boost (0 to +18 dB bass boost)
  • Soft Start Turn-on
  • 3/2/1 channel operation
  • Speaker-level inputs with signal sensing for automatic turn-on
  • 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Gold-plated RCA level inputs
  • Gold-plated screw terminals
  • Input sensitivity:
    • Level: 300mV-6V
  • Variable high-pass filter (50-500 Hz)
  • Variable low-pass filter (30-150 Hz)
  • Fixed subsonic filter (25 Hz)
  • Phase Shift: 0-180°
  • Damping factor: >100
  • Frequency response: 10-35,000 Hz
  • Dimensions: 13-5/16"L x 2"W x 10"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 1-year Manufacturer's warranty

Best selling similar products

MX600/3 small

JL Audio MX600/3

• 75 watts x 2 channel + 250 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 400 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 400 watts x 1 channel @ 2 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 3-Channel Amplifier

(4)

$579.99

List price $579.99

XDM500/3 small

JL Audio XDM500/3

• 75 watts x 2 channel + 180 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 300 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 300 watts x 1 channel @ 2 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 3-Channel Amplifier

$679.99

List price $679.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
120 watts x 2 channel
RMS Power @ 2 ohms
200 watts x 2 channel
Bridged RMS Power
310 watts x 1 channel
Power Specifications - Subwoofer Channel
RMS Power @ 4 ohms
220 watts x 1 channel
RMS Power @ 2 ohms
330 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
3-Channel
Total RMS Power Output
730 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
50 - 500 Hz
Low-Pass Crossover Frequency
30 - 150 Hz
Subsonic Filter
25 Hz
Signal-to-Noise Ratio
>100 dB
Remote bass/level controller
No
Fuse Rating
25A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

DLS

Model Number:

X-D30

Weight:

9.90lbs

Internal SKU:

xd30

Internal Product ID:

26101
