Name: Hifonics EAGLE HF R/B
Brand: Hifonics
SKU: LS-eaglehf-RB
Price: 59.99 USD
Availability: Discontinued

by Hifonics

About
Specs & Details
Product Videos
Reviews
Add-ons
Recently Viewed
Related Searches

Product videos

Product highlights

Warrior Series 4-Channel Class A/B Car Amplifier • 320W RMS • 2 Variable High-Pass Filters • 3-Way System Protection Circuitry • VersaCross Open Architecture Crossovers • Symmetrical Signal Amplification

Learn more about the LS-eaglehf-RB

Product Highlights

Description

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

Warrior Series 4-Channel Class A/B Car Amplifier
RMS Power Rating (14.4V):
- 4 ohm: 45 watts x 4 chan.
- 2 ohm: 80 watts x 4 chan.
- Bridged, 4 ohm: 150 watts x 2 chan.
RMS Power Rating (12.0V):
- 4 ohm: 35 watts x 4 chan.
- 2 ohm: 55 watts x 4 chan.
- Bridged, 4 ohm: 110 watts x 2 chan.
Pulse Width Modulated efficient MOSFET power supply
Fully complementary topology in the amplifier block
Symmetrical signal amplification resulting in audiophile sound quality
VersaCross open architecture active crossover system allows easy configuration
LED power (green) and protect (red) indicators
Soft Start Turn-on
4/3/2 channel operation
3-Way System Protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heatsink for extreme heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Input sensitivity:
- Level: 100mV-2.4V
2 Variable high-pass filters (10-1,000 Hz and 45-5,300 Hz, 12 dB/octave)
Variable low-pass filter (45-5,300 Hz, 12 dB/octave)
Damping factor: >120
Frequency response: 10-30,000 Hz
Dimensions: 9-15/16"L x 7"W x 1-13/16"H
8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
Authorized Internet Dealer
90-day Manufacturer's warranty

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

45 watts x 4 channel

RMS Power @ 2 ohms

80 watts x 4 channel

RMS Power @ 1 ohm

Not Stable

Bridged RMS Power

150 watts x 2 channel

Amplifier Specifications

Amplifier Class

A/B

Number of Channels

4-Channel

Total RMS Power Output

320 watts

Maximum Input Gauge Size

8 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

0.1%

Speaker Level Inputs

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

10-1,000 Hz and 45-5,300 Hz

Low-Pass Crossover Frequency

45 - 5,300 Hz

Signal-to-Noise Ratio

105 dB

Remote bass/level controller

Fuse Rating

20A x 1

Warranty and Return Policy

Parts Warranty Duration

90 days

Labor Warranty Duration

90 days

Warranty Provider

Manufacturer
