DLS CA 31

450W, 3-Channel Class AB Classic Series Car Amplifier (Performance Classic -- 10-30231)

DLS
Shop all DLS
Product videos
highlight-star-icon

Performance Series 3-Channel Class A/B Car Amplifier • 450W RMS • Dual Speaker Terminals • 3-Way System Protection Circuitry • Preamp RCA Outputs • Speaker-Level Inputs • Variable High/Low Pass Filters

Learn more about the dlsca31

We apologize

This item has been discontinued


Loading...
72-8104 main

Metra 72-8104

Install New Speakers in select 1990-2024 vehicles from Toyota, Subaru, Mitsubishi

87
-20.01%

$11.99

List price $14.99

PH654 main

Cerwin-Vega PH654

600W Peak (300W RMS) 6.5" PRO Series Full Range Coaxial 4-ohm Speakers

2
-16.67%

$189.99

List price $227.99

XRM59BT main

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28
DEH-S4220BT main

Pioneer DEH-S4220BT

Single DIN CD Receiver with Bluetooth and Amazon Alexa

9
-11.77%

$149.99

List price $170.00

Lowest price in 30 days
H7694 main

Cerwin Vega H7694

800W Peak (150W RMS) 6x9" HED Series 4-Way Coaxial 4-ohm Speakers

32
-25.93%

$79.99

List price $107.99

Limited time!
46CSC54 main

Kicker CSC5 (46CSC54)

450W Peak (150W RMS) 5.25” CS Series 2 Way Coaxial 4-ohm Speakers

5
-33.36%

$79.96

List price $119.99

JVC KD-T925BTS

Single DIN CD Multimedia Receiver with Bluetooth and Built-in Alexa (SiriusXM Ready)

2
-9.13%

$199.00

List price $219.00

JBL GX9638 (JBLGX9638AM)

600W Peak (200W RMS) 6x9" GX Series 3 Way Coaxial 2.3-ohm Speakers with Dual Tweeters

16
-10.01%

$89.95

List price $99.95

Product Highlights


Performance Series 3-Channel Class A/B Car Amplifier • 450W RMS • Dual Speaker Terminals • 3-Way System Protection Circuitry • Preamp RCA Outputs • Speaker-Level Inputs • Variable High/Low Pass Filters

Description


DLS brand icon

Authorized dealer

  • Performance Series 3-Channel Class A/B Car Amplifier
  • RMS Power Rating (13.8V):
    • 4 ohm: 65 watts x 2 chan. + 170 watts x 1 chan.
    • 2 ohm: 90 watts x 2 chan. + 280 watts x 1 chan.
    • Bridged, 4 ohm: 170 watts x 1 chan.
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • Soft Start Turn-on
  • 3/2/1 channel operation
  • Speaker-level inputs with signal sensing for automatic turn-on
  • 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink sink for extreme heat dissipation
  • Gold-plated RCA level inputs
  • Gold-plated screw terminals
  • Input sensitivity:
    • Low level: 250mV-5V
  • Variable high-pass filter (15-150 Hz, 24 dB/octave)
  • Variable low-pass filter (50-120 Hz, 24 dB/octave)
  • Fixed subsonic filter (25 Hz)
  • Phase Shift: 0-180°
  • Damping factor: >100
  • Frequency response: 10-35,000 Hz
  • Dimensions: 14-5/8"L x 2-15/16"W x 10-9/16"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

SXE-6926S main

Alpine SXE-6926S

280W Peak (90W RMS) 6x9” SXE Series 2-way 4-ohm Coaxial Speakers

13
-20.84%

$56.99

List price $71.99


Best selling similar products

MX600/3 small

JL Audio MX600/3

• 75 watts x 2 channel + 250 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 400 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 400 watts x 1 channel @ 2 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 3-Channel Amplifier

(4)

$579.99

List price $579.99

XDM500/3 small

JL Audio XDM500/3

• 75 watts x 2 channel + 180 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 300 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 300 watts x 1 channel @ 2 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 3-Channel Amplifier

$679.99

List price $679.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
65 watts x 2 channel
RMS Power @ 2 ohms
90 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
170 watts x 1 channel
Power Specifications - Subwoofer Channel
RMS Power @ 4 ohms
170 watts x 1 channel
RMS Power @ 2 ohms
280 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
3-Channel
Total RMS Power Output
450 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
Speaker Level Inputs
Yes
Preamp Outputs
No
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
15 - 150 Hz
Low-Pass Crossover Frequency
50 - 120 Hz
Subsonic Filter
25 Hz
Signal-to-Noise Ratio
>100 dB
Remote bass/level controller
No
Fuse Rating
30A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

DLS

Model Number:

CA 31

Weight:

9.00lbs

Internal SKU:

dlsca31

Internal Product ID:

26581
