DLS CAT 31

570W, 24V 2-Channel Class AB Classic Series Car Amplifier for Trucks and Buses (10-30231)

DLS
Shop all DLS
Product videos
highlight-star-icon

Performance Series 24V 3-Channel Class A/B Car Amplifier • 570W RMS • Dual Speaker Terminals • 3-Way System Protection Circuitry • Preamp RCA Outputs • Speaker-Level Inputs • Variable High/Low Pass Filters

Learn more about the dlscat31

We apologize

This item has been discontinued


Loading...
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth (SiriusXM Ready)

43
-16.69%

$149.95

List price $180.00

GTO629 main

JBL GTO629

360W Peak (120W RMS) 6.5" GTO Series 2-Way Full Range Coaxial 3-ohm Car Speakers

35
-34.45%

$117.99

List price $180.00

Product Highlights


Performance Series 24V 3-Channel Class A/B Car Amplifier • 570W RMS • Dual Speaker Terminals • 3-Way System Protection Circuitry • Preamp RCA Outputs • Speaker-Level Inputs • Variable High/Low Pass Filters

Description


DLS brand icon

Authorized dealer

  • Performance Series 24V 3-Channel Class A/B Car Amplifier
  • RMS Power Rating (24V):
    • 4 ohm: 75 watts x 2 chan. + 170 watts x 1 chan.
    • 2 ohm: 145 watts x 2 chan. + 280 watts x 1 chan.
    • 1 ohm: 210 watts x 2 chan.
    • Bridged, 4 ohm: 280 watts x 1 chan.
  • Pulse Width Modulated MOSFET power supply
  • LED power (green) and protect (red) indicators
  • 24V Use for trucks and buses
  • Soft Start Turn-on
  • 3/2/1 channel operation
  • Speaker-level inputs with signal sensing for automatic turn-on
  • 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink sink for extreme heat dissipation
  • Gold-plated RCA level inputs
  • Gold-plated screw terminals
  • Input sensitivity:
    • Low level: 250mV-5V
  • Variable high-pass filter (15-150 Hz, 24 dB/octave)
  • Variable low-pass filter (50-120 Hz, 24 dB/octave)
  • Fixed subsonic filter (25 Hz)
  • Phase Shift: 0-180°
  • Damping factor: >100
  • Frequency response: 10-35,000 Hz
  • Dimensions: 14-5/8"L x 2-15/16"W x 10-9/16"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00


Best selling similar products

MX600/3 small

JL Audio MX600/3

• 75 watts x 2 channel + 250 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 400 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 400 watts x 1 channel @ 2 ohm
• Total RMS Power: 600 watts
• Class D 2 ohm Stable 3-Channel Amplifier

(4)

$579.99

List price $579.99

XDM500/3 small

JL Audio XDM500/3

• 75 watts x 2 channel + 180 watts x 1 channel @ 4 ohm
• 100 watts x 2 channel + 300 watts x 1 channel @ 2 ohm
• Bridged: 200 watts x 1 channel @ 4 ohm + 300 watts x 1 channel @ 2 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 3-Channel Amplifier

$679.99

List price $679.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
75 watts x 2 channel
RMS Power @ 2 ohms
145 watts x 2 channel
RMS Power @ 1 ohm
210 watts x 2 channel
Bridged RMS Power
280 watts x 1 channel
Power Specifications - Subwoofer Channel
RMS Power @ 4 ohms
170 watts x 1 channel
RMS Power @ 2 ohms
280 watts x 1 channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
3-Channel
Total RMS Power Output
570 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
1 ohm
Minimum Impedance Bridged
4 ohms
Speaker Level Inputs
Yes
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
15 - 150 Hz
Low-Pass Crossover Frequency
50 - 120 Hz
Subsonic Filter
25 Hz
Signal-to-Noise Ratio
>100 dB
Remote bass/level controller
No
Fuse Rating
20A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

DLS

Model Number:

CAT 31

Weight:

9.00lbs

Internal SKU:

dlscat31

Internal Product ID:

26584
