Alphasonik PMZ3002A

Alphasonik
Shop all Alphasonik
Product videos
highlight-star-icon

2-Channel class A/B bipolar amplifier • 100 watts x 2 at 4 ohm • 150 watts x 2 at 2 ohm • 300 watts bridged at 4 ohm • Built in crossover • 4-way protection circuitry • RCA input and output jacks

Learn more about the pmz3002a

We apologize

This item has been discontinued


Loading...
72-4568 main

Metra 72-4568

Install New Speakers in select 1990-2021 vehicles from Chevrolet, GMC, Buick

120
-33.36%

$9.99

List price $14.99

GM1583B main

Scosche GM1583B Dash Kit

Install a new Single-DIN car stereo in select 1992-2012 vehicles from Chevrolet, GMC, Buick (Black)

150
-12.54%

$13.95

List price $15.95

82-3021 main

Metra 82-3021

6-6.75 inch speakers - Front door for select 2002-2009 vehicles from Chevrolet, GMC, Buick

5
-42.87%

$15.99

List price $27.99

82-3022 main

Metra 82-3022

6-6.75 inch speaker adapters for select 1998-2009 Envoy and TrailBlazer and Bravada

-10.00%

$26.99

List price $29.99

82-3023 main

Metra 82-3023

Mounting adapter for aftermarket dash tweeters for select 2002-2009 Envoy and TrailBlazer and Bravada

1
-10.72%

$24.99

List price $27.99

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

Limited time!

Rockford Fosgate Prime R165X3

180W Peak (90W RMS) 6.5" Prime Series 3 Way Coaxial 4-ohm Speakers

154
-12.50%

$69.99

List price $79.99

P1650 main

Rockford Fosgate Punch P1 P1650

220W Peak (110W RMS) 6.5" Punch P1 Series 2 Way Coaxial 4-ohm Speakers

61
Limited time!
DMH-241EX main

Pioneer DMH-241EX

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth and Built-in Alexa

20
-35.00%

$194.99

List price $300.00

C2-650X main

JL Audio C2-650x

120W RMS 6.5" C2 Series 2-Way Coaxial 4-ohm Car Speakers

26

Product Highlights


2-Channel class A/B bipolar amplifier • 100 watts x 2 at 4 ohm • 150 watts x 2 at 2 ohm • 300 watts bridged at 4 ohm • Built in crossover • 4-way protection circuitry • RCA input and output jacks

Description


  • 2-channel class A/B bipolar amplifier
  • RMS Power ratings:
    • 100 watts x 2 chan. (4 ohm stereo)
    • 150 watts x 2 chan. (2 ohm stereo)
    • 300 watts x 1 chan. (4 ohm mono)
  • Bridgeable
  • Tiffany-style input and output RCA jacks
  • RCA and speaker level inputs
  • MOSFET high speed switching power supply
  • THD: 0.04%
  • Signal-to-noise ratio: >100dB
  • Frequency response: 5Hz - 50kHz
  • Built in Crossover:
    • Variable High Pass Filter: 50Hz - 250Hz, 18dB/Octave
    • Variable Low Pass Filter: 50Hz - 250Hz, 18dB/Octave
    • Variable Subsonic Filter: Off - 20Hz, 18dB/Octave
  • Variable bass boost at 45 HzL 0 - +18dB/Octave
  • Variable phase shift: 0 - 180 degrees
  • Input sensitivity: High 1V - 10V / Low 200mV - 8V
  • Input impedance: 10K ohm
  • 4-way protection circuitry: Thermal, Short Circuit, Overload, and DC Offset
  • Direct input terminal / PCB connect
  • Dimensions: 9-1/4" W x 2" H x 11-2/5"
  • Optional Accessories:
    • Remote digital voltmeter (PMA 100V)
    • Remote bass control (PMA 10B)

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00


Best selling similar products

ATOM-900.2 PRO small

Deaf Bonce Apocalypse ATOM-900.2 PRO

• 350 watts x 2 channel @ 4 ohm
• 510 watts x 2 channel @ 2 ohm
• 900 watts x 2 channel @ 1 ohm
• Bridged: 1020 watts x 1 channel @ 4 ohm
• 1000 watts @ 2 ohm
• Total RMS Power: 900 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

$229.90

List price $229.90

MFA 2.420 small

Deaf Bonce MFA 2.420

• 420 watts x 2 channel @ 4 ohm
• 630 watts x 2 channel @ 2 ohm
• Bridged: 1260 watts x 1 channel @ 4 ohm
• Total RMS Power: 1260 watts
• Class D 2 ohm Stable 2-Channel Amplifier

$229.90

List price $229.90

ATOM-700.2 PRO small

Deaf Bonce Apocalypse ATOM-700.2 PRO

• 230 watts x 2 channel @ 4 ohm
• 480 watts x 2 channel @ 2 ohm
• 700 watts x 2 channel @ 1 ohm
• Bridged: 960 watts x 1 channel @ 4 ohm
• 14000 watts @ 2 ohm
• Total RMS Power: 700 watts
• Class D 1 ohm Stable 2-Channel-Channel Amplifier

(1)

$199.90

List price $199.90

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
100 watts x 2 channel
RMS Power @ 2 ohms
150 watts x 2 channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
300 watts x 1 channel
Amplifier Specifications
Number of Channels
2-Channel
Total RMS Power Output
300 watts
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.04%
Speaker Level Inputs
No
Preamp Outputs
1 pair
High-Pass Crossover Frequency
50 - 250 Hz
Low-Pass Crossover Frequency
50 - 250 Hz
Subsonic Filter
Off - 20 Hz
Signal-to-Noise Ratio
98 dB
Bass Boost
0 - 18 dB
Fuse Rating
20A

Item Details


Manufacturer:

Model Number:

PMZ3002A

Weight:

14.00lbs

Internal SKU:

pmz3002a

Internal Product ID:

2848
