Name: Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)
Brand: Rockford Fosgate
SKU: ls-pbr300x2-obc6
Price: 135.99 USD
Availability: Discontinued

by Rockford Fosgate

About
Specs & Details
Reviews
Add-ons
Related Searches

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 1 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 2 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 3 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 4 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 5 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 6 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used) Image 7 — Rockford Fosgate PBR300X2 Open Box Complete (Very Good, Used)

Product highlights

• Item Condition: Open Box
• RMS 100W x 2 @ 4 ohm, 150W x 2 @ 2 ohm, 300W x 1 @ 4 ohm Bridged
• Features Rockford Fosgate's Class-BR Topology
• CEA-2006 Compliant
• Ultra Compact Chassis
• Boosted Rail Design
• Dimensions: 6.75"L x 4.25"W x 1.53"H

Learn more about the ls-pbr300x2-obc6

Description

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Open Box (Complete): Item was previously installed and used. Item is in good condition and has been tested to be fully functional. Nonessential accessories (screws, etc) may have been replaced with generic parts.

General Features:

Punch Series BR Monoblock Car Amplifier
RMS Power Rating:

4 ohm: 100 watts x 2 chan.
2 ohm: 150 watts x 2 chan.
4 ohm Bridged: 300 watts x 1 chan.

Features Rockford Fosgate's Class-BR Topology
CEA-2006 compliant amplifier
Ultra compact chassis
MOSFET output stage
Boosted Rail amp technology
Convection cooling design
Extruded aluminum heat sink
Low level RCA input connection
High level speaker input connection
Detachable Compression Terminals
12dB / Octave Butterworth crossover
Selectable crossover mode: LP/AP/HP
LED power (blue) and protect (red) indicators
Variable 4-6 volt hi level DC offset voltage input turn-on control
Features MEHSA3 (Maximum Efficiency Heat Sink Application - gen. 3)
Perfect for smaller stealth installations
Great for motorcycles and recreational vehicles
Optional Remote Punch EQ provides 0dB to +18dB @ 45Hz
Wiring w/ Mounting Plate for Harley-Davidson Motorcycles Available: Rockford Fosgate RFKHD9813
16 Gauge speaker wire output terminals
10 gauge OFC power and ground wiring is recommended for installation.
1-year Manufacturer's Warranty

Get a 1 Year Extended Warranty by adding a qualifying amp kit to order:

Amplifier Specifications:

Input sensitivity:

Low level: 150mV - 4V
High level: 400mV - 11V

Operating voltage: 9 - 16 VDC
Recommended fuse rating: 50 A x 1
(not included)
Max. current draw (13.8V Sinewave): 45 A
Average current draw (13.8V Music): 23 A
Frequency response: 20 - 20,000 Hz, +/- 3 dB
Total harmonic distortion: <1.0%
Signal to Noise Ratio: ≥100 dB
CMRR: >55 dB @ 1 kHz
Damping Factor: >200
High-Pass: 50Hz - 500Hz @ 12dB/Octave
Low-Pass: 50Hz - 500Hz @ 12dB/Octave
CEA-2006 Power Rating: 100W x 2 @ 4Ω ≤1.0% THD+N
Weight: 2.76 lbs
Dimensions: 6.75"L x 4.25"W x 1.53"H

Check out the Rockford Fosgate Punch PBR300X2 Owner's Manual

Check out the Class-BR Amplifier Installation Advisory From Rockford Fosgate

Specifications & Details

Power Specifications - Full Range Channels

RMS Power @ 4 ohms

100 watts x 2 channel

RMS Power @ 2 ohms

150 watts x 2 channel

Bridged RMS Power

300 watts x 1 channel

Amplifier Specifications

Series

Punch BR Series

Amplifier Class

Number of Channels

2-Channel

Total RMS Power Output

300 watts

Maximum Input Gauge Size

10 AWG

Minimum Impedance Unbridged

2 ohm

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power

<1.0%

Speaker Level Inputs

Yes

Preamp Outputs

Built-in Crossover

Low-Pass (LP)
High-Pass (HP)
Full (AP)

High-Pass Crossover Frequency

50 - 500 Hz

Low-Pass Crossover Frequency

50 - 500 Hz

Signal-to-Noise Ratio

100 dB

Remote bass/level controller

Optional (Accessory required and sold separately)

Rockford Fosgate PEQ

Fuse Rating

50A X 1 In-Line Fuse Recommended

Strappable

Sonic Certified Amplifier

Not Tested

Warranty and Return Policy

Parts Warranty Duration

1 year

Labor Warranty Duration

1 year

Warranty Provider

Manufacturer
